Lytecaster®Recessed Downlighting 1102TM1

Page 1 o 1 6 3/4 ” Aperture Low Pro ile 2 Lt. 13W Emergency Fluorescent Frame-In Kit

Features

1. Mounting Frame: .036" (#20 ga.) galvanized steel. Accommodates all

ceilings up to 1" thick. Low pro ile 3 7/8" depth including ceiling material and

re lector trim. For ceilings thicker than 5/8", depth rom inished ceiling will

be ceiling thickness (max. 1") plus 3 1/4". Push-in/twist-out rotoclips hold

re lector lush to ceiling.

2. Junction Box: .063" (#14 ga.) galvanized steel. Rated or 8 #12 AWM

through branch circuit wires suitable or 90° C, or end o run 75° C. Quick

release “L” shaped cover or access to wiring. Integral cable clamps permit

attachment o nonmetallic Romex®or armored cable without need o

additional connectors.

3. Mounting Bars: Die- ormed steel, #16 ga. Four bars, 13" long, extend to

27", permit o -center mounting; bars rotate 90° and lock in both directions;

integral poised nailer or wood joists, locking tabs or T-bar runners.

4. Socket Housing: 22 ga. galvanized spring steel; snap-in quick assembly or

precise lamp location.

5. Socket: Two-pin base, molded thermoplastic; prewired with #18 AWM leads

to 4" x 3 1/2” x 2" junction box.

6. T ermally Protected Ballast: 2 light electromagnetic, encased and potted,

class "P" high power actor. Insulation must be kept 3" away rom ixture

sides and wiring compartment and must not be placed above ixture as to

entrap heat.

7. Emergency Power Pack: Electronic, ully encased and pre-wired nickel

cadmium long li e battery, replaceable rom below. Meets requirements o

National Electric Code and Li e Sa ety Code. Test switch and charge light

included in easy to install recessed switch box with 4 1/2” diameter matte

white cover plate, 24" long lexible cable; may be installed up to 50 eet rom

ixture. One lamp operates at 61% initial output or 90 minutes when power

ails.

Electrical

120V 277V

HPF Input Watts 31 42

Amps 0.28 0.17

Minimum starting time is 32° F.

Options & Accessories

Concealed Spline Ceiling Kit: 1965 - set o (4), 1 1/2” to 2 1/2” Mtg. Ht.

Plaster Ceiling Ring: 1961 - 7/8" depth or wet plaster ceilings.

Labels

UL (Suitable or Damp Locations), I.B.E.W.

Complete Fixture consists of Reflector Trim & Frame-In Kit. Select eac separately.

Frame-In Kit Reflector Trims — See Individual Reflector Trim Specification S eets

Open Downlight

Cone Ba les Cross Blade

1102TM1 HPF 120V 1113TGD 1105T 1132T 1126T 1135T

1102TM2 HPF 277V 1113TCL 1105TWH 1128T

1178T

Enclosed

Di users

Wall

Washer

Romex®is a registered trademark o General Cable Industries Inc.

Job Information Type:

Job Name:

Cat. No.:

Lamp(s):

Notes:

Lig tolier a Genlyte company www.lightolier.com

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710

We reserve the right to change details o design, materials and inish.
