Calculite®ProSpec®Linear Downlight PB1A7050

Page 1 o 2 1 Light AR 70 Series B

Job Information Type:

Job Name:

Cat. No.:

Lamp(s):

Notes:

Features

1. Aperture Frame: Provides clean support or lamp holders and overlapping

lange or trimless installation. Extruded aluminum. Rigidly welded together on

all corners.

2. Media Cartridge: Allows convenient loading and removal o up to one

accessory. Easily installed and removed or lamping with a simple twisting

motion. Constructed o ormed aluminum.

3. Adjustable Ring: Allows 360° horizontal and 45° (on width) and 45° (on

length) vertical adjustment.

4. Tortiontite Spring: For easy installation o aperture rame.

5. Housing: Die- ormed 22 ga. steel. Finish: Black.

6. Mounting Brackets: Adjustable vertically rom outside o housing.

7. T ermal Protector: Meets NEC, UL, and CSA requirements.

8. Lamp older: Double contact bayonet base with 250°C #18 gauge Te lon®

leads.

9. Junction Box: 14 ga. steel, 4" x 3 1/2" x 2" box. Allows inspection rom

below.

10.Lamp and Accessory Support: .032" steel, lared or easy entry o Media

Cartridge.

11.Lens Retaining Ring: .093" spring steel rod. Holds accessories in place.

12.Lamp Guard: Heat resistant clear glass. Lamp manu acturers’ requirement.

13.Transformer Housing: Die- ormed 18 ga. steel.

Electrical

Electronic Transformers: O er reliable operation and are accessible rom

below or servicing. 12V Secondary.

Dimming Controls: Use only dimmers speci ically designed or use with

electronic trans ormers. Low Voltage ixtures may produce audible sound when

used with dimmers, which may be objectionable in acoustically critical areas.

UL/cUL Listed or through branch circuit wiring with maximum o (8) no. 12

AWG, 90°C.

Ceiling Cutout: 6 3/16" L x 6 3/16" W

Ordering Information: AR 70 SERIES B

Cat. No. Lamp Ceiling Trim Aperture Finis

PB1A705EBL (1) 50W AR 70 Overlap Black with White Flange

PB1A705EWL (1) 50W AR 70 Overlap White with White Flange

PB1A705EBTL (1) 50W AR 70 Trimless Black

PB1A705EWTL (1) 50W AR 70 Trimless White

Finis

All painted inishes are powder coated baked enamel.

Options and Accessories

Accessories: 2 1/2" dia. series, ilters, lenses, screens and louvers. (2)

accessories maximum, including lamp cover glass. Lamp guard glass may be

replaced with solid glass accessory.

Labels

UL/cUL (Suitable or Damp Location), I.B.E.W.

PB1A705EBL = (Flanged) Black/White

PB1A705EWL = (Flanged) White PB1A705EBTL = (Trimless) Black

PB1A705EWTL = (Trimless) White

17"

13 1/8"

13"

Top View

Flanged Trimless

Te lon®is a registered trademark o E.I. DuPont.

Add a “1” or 120v or “2” or 277v at the end o the catalog number or voltage

Lig tolier a Genlyte Company www.lightolier.com

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710

We reserve the right to change details o design, materials and inish.

Data are based on bare lamp photometrics. Dashed lines in beam spreads

indicate narrow axes o oval shaped beams.

FC is initial ootcandles at center o beam.

L and W are to the point that the candlepower drops to 50% o maximum.

Lig ting Performance Data

Aiming Angle 0° 30° 45° or 60° Horizontal 30° 45° or 60° Vertical

LBeam length

BBeam width

CDistance to center o beam

DDistance

AAiming angle

FC Foot candles

Lamp data shown is typical, and is based

on bare lamp photometrics. Contact lamp

manu acturers or availability and

per ormance.

D FC LW DC FC LW DC FC LW DC FC LW

Lamps Beam Spread CBCP Rated

(To 50% CBCP) Lie (Hrs.)

Lamp 0° Aiming Angle 30° Aiming Angle 45° Aiming Angle 60° Aiming Angle

8’ 234 1.4’ 1.4’

12’ 104 2.1’ 2.1’

16’ 59 2.8’ 2.8’

20’ 38 3.5’ 3.5’

7’ 4.0’ 199 1.6’ 1.4’

10’ 5.8’ 97 2.3’ 2.0’

13’ 7.5’ 58 3.0’ 2.6’

16’ 9.2’ 38 3.7’ 3.2’

3’ 5.2’ 208 2.1’ 1.0’

4’ 6.9’ 117 2.9’ 1.4’

5’ 8.7’ 75 3.6’ 1.7’

6’ 10.4’ 52 4.3’ 2.1’

5’ 5.0’ 212 1.8’ 1.2’

7’ 7.0’ 108 2.5’ 1.7’

9’ 9.0’ 65 3.2’ 2.2’

11’ 11.0’ 44 3.9’ 2.7’

15000 2000

50W AR70

SP (T-H) 10°

4’ 125 2.1’ 2.1’’

6’ 56 3.2’ 3.2’

8’ 31 4.3’ 4.3’

10’ 20 5.4’ 5.4’

3’ 1.7’ 144 2.2’ 1.9’

5’ 2.9’ 52 3.7’ 3.1’

7’ 4.0’ 27 5.1’ 4.3’

9’ 5.2’ 16 6.6’ 5.6’

1’ 1.7’ 250 2.7’ 1.1’

2’ 3.5’ 63 5.5’ 2.1’

3’ 5.2’ 28 8.2’ 3.2’

4’ 6.9’ 16 10.9’ 4.3’

3’ 3.0’ 79 3.5’ 2.3’

4’ 4.0’ 44 4.6’ 3.0’

5’ 5.0’ 28 5.8’ 3.8’

6’ 6.0’ 20 6.9’ 4.5’

2000 2000

50W AR70

FL (T-H) 30°

8’ 211 1.4’ 1.4’

12’ 94 2.1’ 2.1’

16’ 53 2.8’ 2.8’

20’ 34 3.5’ 3.5’

7’ 4.0’ 199 1.6’ 1.4’

10’ 5.8’ 97 2.3’ 2.0’

13’ 7.5’ 58 3.0’ 2.6’

16’ 9.2’ 38 3.7’ 3.2’

3’ 5.2’ 188 2.1’ 1.0’

4’ 6.9’ 105 2.9’ 1.4’

5’ 8.7’ 68 3.6’ 1.7’

6’ 10.4’ 47 4.3’ 2.1’

5’ 5.0’ 191 1.8’ 1.2’

7’ 7.0’ 97 2.5’ 1.7’

9’ 9.0’ 59 3.2’ 2.2’

11’ 11.0’ 39 3.9’ 2.7’

13500 2000

50W AR70

SP GOLD (T-H) 10°

4’ 125 2.1’ 2.1’’

6’ 56 3.2’ 3.2’

8’ 31 4.3’ 4.3’

10’ 20 5.4’ 5.4’

3’ 1.7’ 144 2.2’ 1.9’

5’ 2.9’ 52 3.7’ 3.1’

7’ 4.0’ 27 5.1’ 4.3’

9’ 5.2’ 16 6.6’ 5.6’

1’ 1.7’ 225 2.7’ 1.1’

2’ 3.5’ 56 5.5’ 2.1’

3’ 5.2’ 25 8.2’ 3.2’

4’ 6.9’ 14 10.9’ 4.3’

3’ 3.0’ 71 3.5’ 2.3’

4’ 4.0’ 40 4.6’ 3.0’

5’ 5.0’ 25 5.8’ 3.8’

6’ 6.0’ 18 6.9’ 4.5’

1800 2000

50W AR70

FL GOLD (T-H) 30°

15’ 222 1.3’ 1.3’

20’ 125 1.7’ 1.7’

25’ 80 2.2’ 2.2’

30’ 56 2.6’ 2.6’

10’ 5.8’ 325 1.2’ 1.0’

15’ 8.7’ 144 1.7’ 1.5’

20’ 11.5’ 81 2.3’ 2.0’

25’ 14.4’ 52 2.9’ 2.5’

8’ 8.0’ 276 1.4’ 1.0’

12’ 12.0’ 123 2.1’ 1.5’

16’ 16.0’ 69 2.8’ 2.0’

20’ 20.0’ 44 3.5’ 2.5’

5’ 8.7’ 250 1.8’ 0.9’

8’ 13.9’ 98 2.6’ 1.4’

11’ 19.1’ 52 3.9’ 1.9’

14’ 24.2’ 32 4.9’ 2.4’

50000 2000

50W AR111

NSP (T-H) 5°

6’ 83 3.2’ 3.2’

8’ 47 4.3’ 4.3’

10’ 30 5.4’ 5.4’

12’ 21 6.4’ 6.4’

5’ 2.9’ 78 3.7’ 3.1’

7’ 4.0’ 40 5.1’ 4.3’

9’ 5.2’ 24 6.6’ 5.6’

11’ 6.4’ 16 8.1’ 6.6’

3’ 3.0’ 118 3.5’ 2.3’

5’ 5.0’ 42 5.8’ 3.6’

7’ 7.0’ 22 8.1’ 5.3’

9’ 9.0’ 13 10.4’ 6.8’

2’ 3.5’ 94 5.5’ 2.1’

3’ 5.2’ 42 8.2’ 3.2’

4’ 6.9’ 23 10.9’ 4.3’

5’ 8.7’ 15 13.7’ 5.4’

3000 2000

50W AR111

FL (T-H) 30°

60°

Calculite®ProSpec®Linear Downlight PB1A7050

Page 2 o 2 1 Light AR 70 Series B

Job Information Type:

Lig tolier a Genlyte Company www.lightolier.com

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710

We reserve the right to change details o design, materials and inish.
