Lightolier Calculite CLW7P56D Manual de usuario

19 7/32"

Top View

19 1/8"

1

3/4" Max.

Ceiling Thickness

7 1/2" I.D.

8 29/32" O.D.

12 13/32"

16 1/4"

Ceiling Cutout: 8 1/4" Dia.

Reflector Trim Frame In Kit Lamp

Finish Sel -Flange Polished Sel -Flange White CDF7P56D PAR56 300W 500W

Specular Clear Alzak®LW7CLP LW7CLW

Specular Gold Alzak®LW7GDP LW7GDW

Specular Black Alzak®LW7BKP LW7BKW

Calculite®Incandescent Lensed Wall Washer LW7/CDF7P56D

Page 1 o 2 7 1/2” Aperture PAR56 Lamp

Job Information Type:

Job Name:

Cat. No.:

Lamp(s):

Notes:

Lightolier a Genlyte Thomas Company www.lightolier.com

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710

We reserve the right to change details o design, materials and inish.

Features

1. Housing: Steel .029” (22 ga.), matte black inish. Top Housing: Aluminum,

.050” (16 ga.), matte black inside. Removable or top relamping.

2. Mounting Frame: 0.50 (16 ga.) ormed aluminum suitable or dry or plaster

ceilings.

3. Aperture Cone: Specular Alzak®aluminum, .050 (16 ga.).

4. Lampholder Assembly: Die- ormed .036 (20 ga.) steel provided with ten-

sion springs or ast snap-in, snap-out lamping. Matte black inish. Beam ori-

entation locking provided.

5. Mounting Brackets: Adjust vertically rom inside or outside o ixture.

Durable .059 (16 ga.) steel construction. Use with standard 3/4” or 1 1/2”

lathing channels, or 1/2” (11/16”O.D.) EMT tubing (by others), or Lightolier

accessory mounting bars.

6. Junction Box: 2 7/8” x 3 1/2” x 4”; .063” (14 ga.) galvanized steel, UL

Listed or maximum o 8 No. 12 AWG 90° C through branch circuit wires.

Accessible rom inside and outside o ixture. Outside J-Box door is hinged

or maximum opening. Snap-in plug is provided on inside cover or quick con-

nection with socket harness.

7. Socket Harness: Porcelain socket-mogul end prong base. Pre-wired with

No. 18 ga. SF-1 leads to plastic plug-in connector.

8. Wall Wash Reflector: Andonized aluminum .040”. Designed to e iciently

redirect light toward wall.

9. Spread Lens: Heat resistant tempered glass designed to evenly spread light

on wall.

10.Thermal Protector: Meets NEC and UL requirements.

Options & Accessories

18" Mounting Bars 1950 (set o 2)

27" Mounting Bars 1951 (set o 2)

T Bar Anchor Clips 1956 (set o 4, or 1950 & 1951 bars)

For other re lector inishes, consult actory.

Labels

UL Listed (Suitable or Damp Locations); I.B.E.W.

Fixture is not or residential use. Install with minimum spacings as ollows:

4’-0” between centers o adjacent ixtures; 6” between top o ixture and over-

head building member; 2’-0” between ixture center and side wall.

Alzak®is a registered trademark o ALCOA.

Footcandles on Wall from Multiple Units

Lighting Data

Example: With multiple 500 PAR56 MFL (T-H) units located

3' rom wall and 4' on center, the illumination on the wall

3' down rom the wall 5' down rom the ceiling is 48 .c.

beneath ixtures and 43 .c. between ixtures.

3’ 4’

1’98 9 8 5 8

2’ 19 18 19 16 13 16

3’ 27 26 27 22 18 22

4’ 30 29 30 24 21 24

5’ 30 30 30 24 22 24

6’ 28 28 28 22 21 22

7’ 26 26 26 20 20 20

8’ 24 24 24 18 18 18

9’ 21 22 21 17 17 17

10’ 19 20 19 15 15 15

11’ 18 18 18 14 14 14

12’ 16 16 16 13 13 13

13’ 15 15 15 12 12 12

14’ 14 14 14 11 11 11

Units 3 Feet From Wall

Distance From Ceiling, Ft.

3’ 4’

119 15 19 17 10 17

2’ 37 35 38 31 24 31

3’ 52 50 52 42 35 42

4’ 60 59 61 49 42 49

5’ 60 60 60 48 43 48

6’ 56 56 56 44 41 44

7’ 50 50 50 39 38 39

8’ 44 45 45 34 34 34

9’ 39 40 39 30 30 30

10’ 35 35 35 27 27 27

11’ 31 31 31 24 24 24

12’ 28 28 28 22 22 22

13’ 26 26 28 20 20 20

14’ 24 24 24 19 19 19

Units 3 Feet From Wall

Distance From Ceiling, Ft.

3’ 4’

1’ 43 4 3 2 3

2’ 88 8 7 6 7

3’ 12 12 12 11 9 11

4’ 16 15 16 13 12 13

5’ 17 17 17 14 13 14

6’ 18 17 18 15 14 15

7’ 17 17 17 14 14 14

8’ 17 17 17 14 13 14

9’ 16 16 16 13 13 13

10’ 15 15 15 12 12 12

11’ 14 14 14 12 12 12

12’ 14 14 14 11 11 11

13’ 13 13 13 11 11 11

14’ 13 13 13 10 10 10

Units 4 Feet From Wall

Distance From Ceiling, Ft.

4’ 5’

1’ 76 7 7 4 7

2’ 17 15 17 15 11 15

3’ 24 23 24 21 17 21

4’ 30 29 30 25 22 25

5’ 34 33 34 29 25 29

6’ 35 35 35 30 27 30

7’ 34 34 34 29 27 29

8’ 33 33 33 27 26 27

9’ 30 31 30 25 25 25

10’ 28 28 28 23 23 23

11’ 26 26 26 22 22 22

12’ 25 25 25 20 20 20

13’ 23 23 23 19 19 19

14’ 22 22 22 18 18 18

Units 4 Feet From Wall

Distance From Ceiling, Ft.

48 f.c.



Footcandle values are averaged and rounded o and are based on a minimum o ive units.

For ixture-to-wall distances, other than those shown, use maximum o 1 o 1 spacing (distance

between ixtures not more than distance to wall) or best results.

Calculite®Incandescent Lensed Wall Washer LW7/CDF7P56D

Page 2 o 2 7 1/2” Aperture PAR56 Lamp

Lightolier a Genlyte Thomas Company www.lightolier.com

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710

We reserve the right to change details o design, materials and inish.

Job Information Type:
