Lightmybricks LEGO 40426 Manual de usuario

LEGO® CHRISTMAS WREATH 2-IN-1

#40426 LIGHT KIT

INSTALLATION GUIDE

LEGO CHRISTMAS WREATH 2-IN-1 40426 LIGHT KIT INSTALL GUIDE

INSTALLATION GUIDE 2

Light My Bricks

LEGO® CHRISTMAS WREATH 2-IN-1

#40426 LIGHT KIT INSTALLATION GUIDE

Hi There!

We’re here to help you get started on the LEGO®

Christmas Wreath 2-in-1 (40426) Light Kit.

This PDF details the instructions for the LED light kit only. If

you are wishing to purchase this product, please click here

to view the product page.

If you run into any issues, please refer to the troubleshoot-

ing section towards the end of this guide.

Have fun and enjoy!

LEGO CHRISTMAS WREATH 2-IN-1 40426 LIGHT KIT INSTALL GUIDE

PACKAGE CONTENTS 3

PACKAGE CONTENTS: LEGO PIECES:

4 x White 30cm Bit Light

4 x Red 30cm Bit Light

4 x White 15cm Bit Light

1 x 6 Port Expansion Board

1 x 12 Port Expansion Board

6 x Adhesive Squares 5x5x2mm

• 4 x LEGO Round Plate 1x1 Trans-Red

• 4 x LEGO Round Plate 1x1 Trans-Orange

1 x Flicker Eects Board

2 x 5cm Connecting Cable

1 x Flat Battery Pack

LEGO CHRISTMAS WREATH 2-IN-1 40426 LIGHT KIT INSTALL GUIDE

CONTENTS 4

Contents

Before You Begin 5

Option 1 Instructions 9

Option 2 Instructions 18

Final Product 30

Troubleshooting 31

Contact 36

LEGO CHRISTMAS WREATH 2-IN-1 40426 LIGHT KIT INSTALL GUIDE

BEFORE YOU BEGIN 5

Before You Begin

Laying cables in between

and underneath bricks

Cables can ﬁt in between and underneath

LEGO® bricks, plates, and tiles providing

they are laid correctly between the

LEGO® studs. Do NOT forcefully join

LEGO® together around cables; instead

ensure they are laying comfortably in

between each stud.

CAUTION: Forcing LEGO® to connect over

a cable can result in damaging the cable

and light.

Connecting Cable

Connectors To Expansion

Boards

Take extra care when inserting connectors

to ports of Expansion Boards. Connectors

can be inserted only one way. With the

expansion board facing up, look for the

soldered “=” symbol on the left side of the

port. The connector side with the wires

exposed should be facing toward the

soldered “=” symbol as you insert into the

port. If a plug won’t ﬁt easily into a port

connector, do not force it.

Incorrectly inserting the connector can

can result in bent pins inside the port or

possible overheating of the expansion

board when connected.

LEGO CHRISTMAS WREATH 2-IN-1 40426 LIGHT KIT INSTALL GUIDE

BEFORE YOU BEGIN 6

Before You Begin

Connecting Cable

Connectors To Strip Lights

Take extra care when inserting connectors

to ports on the Strip Lights. Connectors

can be inserted only one way. With the

Strip Light facing up, ensure the side of

the connector with the wires exposed is

facing down. If a plug won’t ﬁt easily into

a port connector, don’t force it. Doing so

will damage the plug and the connector.

Connecting Micro Cable

Connectors To Micro

Expansion Board Ports

Take extra care when inserting the

micro connectors to micro ports of Micro

Expansion Boards. Connecting Micro Bit

Lights to Micro Expansion Boards is similar

to connecting lights and cables to Strip

Lights. With the expansion board facing

up, ensure the side of the connector with

the wires exposed is facing down. If a plug

won’t ﬁt easily into a port connector, do

not force it. Use your ﬁngernail to push the

plastic part of the connector to the micro

port.

LEGO CHRISTMAS WREATH 2-IN-1 40426 LIGHT KIT INSTALL GUIDE

BEFORE YOU BEGIN 7

Before You Begin

Installing Bit Lights Under

Lego® Bricks And Plates

When installing Bit Lights under LEGO®

pieces, ensure they are placed the correct

way up (Yellow LED component exposed).

You can either place them directly on top of

LEGO® studs or in between.

LEGO CHRISTMAS WREATH 2-IN-1 40426 LIGHT KIT INSTALL GUIDE

INSTRUCTIONS 8

INSTRUCTIONS

This section is for the Hanging

Wreath. To light up the Candle

Wreath, click here.

To ensure a smooth installation of

your light kit, please read and follow

each step carefully. If you run into

any issues, please refer to the online

troubleshooting guide.

LEGO CHRISTMAS WREATH 2-IN-1 40426 LIGHT KIT INSTALL GUIDE

INSTRUCTIONS 9

Legend DISCONNECT CONNECT /

RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON

Each letter

represents one

segment of the

wreath. These

will be referred

to throughout the

guide.

White 30cm Bit Light

LEGO CHRISTMAS WREATH 2-IN-1 40426 LIGHT KIT INSTALL GUIDE

INSTRUCTIONS 10

2 3

Legend DISCONNECT CONNECT /

RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON

Red 30cm Bit Light

Trans Red Round Plate 1x1

White 30cm Bit Light
