Life Gear 97320 Manual de usuario
PACE MAKER PRO
OWNER’S MANUAL
MODEL#97320
The specifications of this product may vary from this photo,
subject to change without notice.
PAGE OF
CONTENTS
ONE YEAR
LIMITED
WARRANTY
Warranty 1
Important Safety
Instructions 2
Overview Drawing 4
Parts List 5
Hardware Packing List 7
Assembly Instructions 8
Operation 11
Folding Up and Setting
Down the Treadmill 12
Manual lncline
Adjustment 13
Console Operation 14
Using Your Treadmill 17
Lubrication and Running
Belt Adjustment 19
Fitness Tip 20
LifeGear Inc. warrants to the
original purchaser that this
product is free from defects in
material and workmanship when
used for the purpose intended,
under the conditions that it has
been installed and operated in
accordance with LifeGear's
Owner's Manual. LifeGear's
obligation under this warranty is
limited to replacing or repairing,
free of charge, any parts which
may prove to be defective under
normal home use. This warranty
does not include any damage
caused by improper operation,
misuse or commercial
application.
From the date of purchase, the
frame is warranted to be free
from defects for 1 (one) year.
This warranty is extended only
to the original owner and is not
transferable. When ordering
replacement parts please have
the following information ready:
1. Owner's Manual
2. Model Number
3. Description of Parts
4. Part Number
5. Date of Purchase
1
IMPORTANT SAFETY INSTRUCTIONS
2
Observe the following prior to use of the treadmill:
DANGER: To reduce the risk of electric shock, please observe the following:
zAlways unplug the treadmill from the electrical outlet immediately after using and before cleaning,
assembling, or servicing.
NOTE: Failure to follow these instructions may lead to personal injury and cause damage to the
treadmill.
WARNING: To reduce the risk of burns, fire, electric shock please observe the following:
zNever leaves the treadmill unattended when plugged in. Disconnect by turning off the master power
switch, and unplugging from outlet.
zNever operate this treadmill if it has a damaged cord or plug is not working properly, if it has been
dropped or damaged, or if it has been exposed to water.
zIf the supply cord is damaged, it must be replaced by the manufacture, its service Agent or similarly
qualified person in order to avoid a hazard.
zDo not attempt any maintenance or adjustments other than those described in this manual. Should
any problems arise, discontinue use and consult an Authorized Service Representative.
zDo not use outdoors.
zDo not operate where aerosol (spray can) products are being used or where oxygen is being
administered.
zDo not pull the treadmill by its power cord or use the cord as a
handle.
zNever operate the treadmill with the air openings blocked. Keep air
openings free of lint, hair, and the like.
zClose supervision is necessary if this treadmill is used by, or near
children, people with disabilities, or pets.
zKeep Dry-do not operates in a wet or moist condition. Save these
instructions.
zDo not operate under a blanket. Excessive heating can occur and
cause fire, electrical shock, or injury to people.
zKeep electrical cord away from heated surfaces.
zNever insert any object into any opening.
zKeep the treadmill on a solid, level surface with sides at least two feet
from any wall. Be sure the area around the treadmill remains clear
during use and has adequate clearance, see illustration below.
WARNING: Connect the treadmill to a properly grounded outlet only.
FRONT
REAR
TOP
VIEW
2 FEET MIN. 2 FEET MIN.
4 FEET MINIMUM
LEFT
SIDE RIGHT
SIDE
zThis product must be grounded. If it should malfunction or break down, grounding provides a path
of least resistance for electric current - reducing the risk of electric shock. This treadmill is
equipped with a cord having an equipment grounding connector and a grounding plug. The plug
must be plugged into an appropriate outlet that is properly installed and grounded in accordance
with all local codes and ordinances.
DANGER: Improper connection of the treadmill grounding connector can result in the risk of
electric shock. Check with a qualified electrician, if you are in doubt as to whether the
product is properly grounded. Do not modify the plug provided with the treadmill. If it
will not fit your outlet, have a properly grounded outlet installed by a qualified
electrician.
zThis unit must be plugged into a nominal 230 volt 50/60 hz, which has a grounding.
zKeep hands clear of all moving parts. Never place hands, feet under the treadmill.
zDo not use the treadmill on a carpet that is greater than 1/2 inch in height.
zBefore each use, check that the running belt is aligned and centered on the treadmill bed and all
visible fasteners on the treadmill are sufficiently tightened and secure.
WARNING: BEFORE BEGINNING ANY EXERCISE PROGRAM CONSULT YOUR PHYSICIAN. THIS IS
ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE AGE OF 35 OR PEOPLE WITH PRE-EXISTING
HEALTH PROBLEMS. READ ALL INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. WE
ASSUME NO RESPONSIBILITY FOR PERSONAL INJURY OR PROPERTY DAMAGE SUSTAINED BY OR
THROUGH THE USE OF THIS PRODUCT.
DO NOT OPERATE THIS EXERCISE EQUIPMENT WITHOUT PROPERLY FITTED GUARDS, AS THE
MOVING PARTS CAN PRESENT A RISK OF SERIOUS INJURY TO YOUNG CHILDREN.
CAUTION: Read all instructions carefully before operating this product. Retain this Owner's Manual
for future reference.
3
OVERVIEW DRAWING
4
23
4
5
6
7
8
8
1
9
10
11
12
13
15
14
14
16
17
18
19
21
20
22
23
24
25
27
28
26
29
30
31
32
34
35
36
37
38
39
40
41
43
42
88
44
45
47
47
46
48
48
49
49
50
55
50
52
53
54
55
56
29
69
55
51
56
58
59
60
61
63
64
65
49
62
62
49
64
66
67
68
70
55
55
71
72
75
75
74
74
73
73
66
33
76
77
78
79
80
26
26
21
26
24
26
82
83
84
85
86
87
81
81
81
81
76
88
57
PARTS LIST
5
Part # Description Quantity Part # Description Quantity
1 Main Frame 1
2 Base Frame 1
3 Adjustable Pad 2
4 End Cap for #2 2
5 Move Wheel 2
6 Wheel 2
7 Rod for Move Wheel 2
8 Screw (M4*10) 4
9 Running Deck 1
10 Front Roller, Drive 1
11 Rear Roller, Tension 1
12 Running Belt 1
13 Motor Base 1
14 Bushing 2
15 Axis 1
16 Drive Motor 1
17 Bracket for Drive Motor 1
18 PCB Motor Controller 1
19 Drive Belt 1
20 Sensor 1
21 Bracket for Sensor 2
22 Switch, AC Power 1
23 Rubber Bumper 8
24 Side Rail 2
25 Bolt (M8*60) 2
26 Screw (M4*16) 13
27 Screw (M6*35) 8
28 Nut (M6) 8
29 Nut (M8) 2
30 End Cap (25*50) 2
31 Dust Cover, Up 1
32 Dust Cover, Lower 1
33 Screw (M4*60) 4
34 L-Handrail 1
35 R-Handrail 1
36 Handlebar 1
37 End Cap for Handlebar 2
38 Computer 1
39 Computer Bracket Cover 1
40 Bolt (M5*10) 4
41 Safety Magnet 1
42 Handlebar Adorner 2
43 Bolt (M8*50) 4
44 End Cap (30*60) 2
45 Foam Grip 2
46 Spacer 2
47 Cap Nut 2
48 Bolt (M10*60) 2
49 Nut (M10) 4
50 Bolt (M8*16) 6
51 Nut 1
52 Safety Tube A 1
53 Safety Tube B 1
54 Bolt (M8*40) 1
55 Spring Washer (M8) 11
56 Nylon Washer 2
57 Spring Knob 1
58 Foot Pad 2
59 L-Rear Cap 1
60 R-Rear Cap 1
61 Incline Beam 1
62 Cover for Incline Beam 2
63 Bolt (M10*40) 2
64 Bushing 2
6
Part # Description Quantity
65 Tapping Screw (ST4*10) 4
66 Handpulse Cover-Upper
W/Wire 2
67 Handpulse Cover-Lower 2
68 Screw (M3*20) 4
69 Bolt (M8*35) 1
70 Screw (M8*12) 2
71 Bolt (M8*45) 2
72 Screw (M4*12) 7
73 Sensor Cable I (850 mm.) 1
74 Sensor Cable II (1100 mm.) 1
75 Sensor Cable III (600 mm.) 1
76 Speed Button W/Wire 1
77 End Cap ( 25) 1
78 End Cap ( 20) 1
79 Fuse Box 1
80 Cable, Power Plug 1
81 Nylon Nut (M4) 7
82 Earth Lead 1
83 Cable Switch/PCB 1
84 Wire for Fuse Box 1
85 Inductance (34MH-40MH) 1
86 Wave Filter (06SS4-2DC1) 1
87 Ring for Cable Power 1
88 Mode Button w/Wire 1
HARDWARE
PACKING LIST
7
Part # Description Quantity
43 Bolt (M8*50) ------------------------------------------------------------------------------------------------4
50 Bolt (M8*16) --------------------------------------------------------------------------------------6
55 Spring Washer (M8)----------------------------------------------------------------------------6
NOTE: 1. Above described parts are all the parts you need to assemble this machine. Before
you start to assemble, please check the hardware packing to make sure they are
included.
2. Please find tools in the hardware pack to help you assemble this machine easier.
PLACE WASHER, BOLT S END OR
SCREW ON CIRCLE TO CHECK FOR
CORRECT SIZE.
INCHES
MILLIMETERS
,
THANK YOU ASSEMBLY
INSTRUCTIONS
Thank you for purchasing your
new exercise product. This
exercise machine will help you
enjoy a lifetime of beneficial
exercise providing a
cardiovas-cular and muscle
toning workout in the
convenience of your own home.
This manual is designed to help
you easily assemble, adjust, and
use this machine. Please read
this manual carefully. For the
sake of familiarizing yourself
with the parts identified in the
instructions, please first study
the overview drawing.
Set all parts in a clear area on
the floor and remove the
packing materials. Refer to the
parts list for help to identify the
parts. To assemble the machine,
see the following pages.
8
STEP 1&2
9
Install Handrails
1. Connect the Sensor Cable I (#73) and Sensor Cable II (#74).
2. Fasten the R-Handrail (#35) to the Base Frame (#2)
with three M8*16 Bolts (#50) and M8 Spring Washers (#55).
Repeat this step to assemble L-Handrail (#34). Careful not
to crimp,pinch or otherwise damage the
cable and cable connections.
Install Handlebar
3. Attach the Handlebar (#36) to the top of the Handrails
(#34 & #35) with two Handlebar Adorners
(#42) and four M8*50 Bolts (#43).
4. Connect the Sensor Cable II (#74) and Sensor Cable III (#75).
Place the connection inside of R-Handrail (#35). Careful
not to crimp, pinch or otherwise damage the cable and cable
connections.
1
4
2
2-1
3-1
4-1
3
73
74
35
2
34
36
43
35
75
74
35
42
55 & 50
Este manual sirve para los siguientes modelos
1
Tabla de contenidos
Otros manuales de Rueda de andar de Life Gear
Life Gear
Life Gear 97114 Manual de usuario
Life Gear
Life Gear 97988T Manual de usuario
Life Gear
Life Gear Mentor II Manual de usuario
Life Gear
Life Gear 97875 Manual de usuario
Life Gear
Life Gear POWER TRACK PRO 97370 Manual de usuario
Life Gear
Life Gear 97400 Manual de usuario
Life Gear
Life Gear 97450 Manual de usuario
Life Gear
Life Gear 98820 Manual de usuario
Life Gear
Life Gear Energetic Pro Manual de usuario
Life Gear
Life Gear 97630 Manual de usuario
Life Gear
Life Gear 97640 Manual de usuario
Life Gear
Life Gear MARK X 97582H Manual de usuario
Life Gear
Life Gear CAMINADORA 97001 Manual de usuario
Life Gear
Life Gear Motion capture plus 97920 Manual de usuario
Life Gear
Life Gear 97240 Manual de usuario
Life Gear
Life Gear 97288HP Manual de usuario
Life Gear
Life Gear SYMPHONY PRO 97655 Manual de usuario
Life Gear
Life Gear 97415 Manual de usuario
Life Gear
Life Gear FLIP TRACK II 97270 Manual de usuario
Life Gear
Life Gear STEP MAKER PRO 97340 Manual de usuario
Manuales populares de Rueda de andar de otras marcas
Smooth Fitness
Smooth Fitness EVO 3i Manual de usuario
NordicTrack
NordicTrack NETL81810.0 Manual de usuario
Schwinn
Schwinn 830/Journey 8.0 Manual de usuario
Keys Fitness
Keys Fitness HealthTrainer HT-740T Manual de usuario
Spirit
Spirit XT8 Manual de usuario
NordicTrack
NordicTrack T 14.0 Treadmill Manual de usuario
