LIBHOF B-55 Manual de usuario
B-55/65
User manual
Návod na obsluhu
Руководство пользователя
ХОЛОДИЛЬНИК АВТОМОБИЛЬНЫЙ
КОМПРЕССОРНЫЙ
COMPRESSOR CAR
FRIDGE
CHLADNIČKA S KOMPRESOROM DO AUTA
Contents of delivery:
•Refrigerator - 1 piece
•Operating instructions - 1 piece
•Power cable for car cigarette lighter - 1 piece
•Partition of the internal volume of the refrigerator - 1-2 pieces
(depending on the model)
Please read this operating manual carefully before starting the device. Keep it in a safe
place for future reference. If the device is passed on to another person, this operating
manual must be handed over to the user along with it.
The manufacturer can not be held liable for damage resulting from improper usage or
incorrect operation.
3
English
1. SAFETY INSTRUCTION 5
1.1 General Safety 5
1.2 Operating the cooling device safety 7
2. COOLING DEVICE APPLICATION 8
3. COOLING DEVICE FUNCTION 9
4. DISPLAY ELEMENTS AND OPERATION 10
4.1 Display & control panel 10
4.2 Cooler device switch on/off 10
4.3 Cooling temperature setting 11
4.4 Low voltage protection battery monitor setting 11
4.5 The explanation for the running code shown in the display screen 13
4.6 Energy saving tips 14
5. CONNECTING THE COOLING DEVICE 15
5.1 Using the fused DC plug for device connection 16
6. USING THE COOLING DEVICE 17
6.1 Switch on the cooling device 17
6.2 Switch off the cooling device. 18
6.3 Defrost the cooling device. 18
7. CLEANING AND MAINTENANCE 20
7.1 Replacing the DC plug fuse 20
7.2 Cleaning the cooling device 20
7.3 Storage the cooling device 21
7.4 Transporting the cooling device 21
CONTENT
5
English
1. SAFETY INSTRUCTION
1.1 General Safety
WARNING!
Do not operate the cooling device if it is visibly damaged.
If this cooling device’s power cable is damaged, it must be replaced by the customer
service in order to prevent safety danger.
This cooling device may only be repaired by qualified personnel, improper repair can
lead to considerable danger.
Cleaning and user maintenance must not be carried out by children without
supervision.
Children must be supervised to ensure that they do not play with the cooling device.
Always keep and use the cooling device out of the reach of children under age of 8
years.
Do not store any explosive substances such as spray cans with a flammable
propellant in the cooling device.
6
English
CAUTION!
Disconnect the cooling device from the power supply:
• before each cleaning and maintenance
• after every use
• food may only be stored in its original package or in suitable containers.
NOTICE!
Check that the voltage specification on the rating label corresponds to that of the
power supply.
Only connect the cooling device as follows:
• connect the DC cable to a DC power supply in the vehicle
• or connect the DC cable to an AC adaptor and then connect the AC adaptor to
the AC power supply.
Never pull the plug out of the socket by the cable.
If the cooling device is connected to the DC outlet, disconnect the cooling device
and other power consuming devices from the battery before connecting a quick
charging device.
If the cooling device is connected to the DC outlet, disconnect the cooling device or
switch it off when you turn off the engine. Otherwise you may discharge the battery.
The cooling device is not suitable for transporting caustic material or material
contains solvents.
The insulation of the cooling device contains flammable cyclopentane and requires
special disposal procedures. Deliver the cooling device at the end of its life-cycle to
an appropriate recycling.
7
English
1.2 Operating the cooling device safety
CAUTION!
Before starting the cooling device, ensure that the power supply line and the plug
are dry.
NOTICE!
• Do not use electric device inside the cooling device unless they are
recommended by the manufacturer for the purpose.
• Do not place the cooling device near naked flames or other heat sources
(heaters, direct sunlight, gas ovens etc.)
• Danger of overheating!
• Ensure at all times that there is sufficient ventilation so that the heat arises
during operation does not build up. Make sure the cooling device is sufficiently
far away from walls and other objects so that the air can circulate.
• Ensure that the ventilation openings are not covered.
• Do not fill the inner container with ice or fluid.
• Do not immerse the cooling device into the water.
• Protect the cooling device and the cable against heat and moisture.
8
English
2. COOLING DEVICE APPLICATION
The cooling device is designed to be operated from:
• DC on-board power supply from a vehicle, boat or caravan
• DC external battery
• AC power supply 220V
• AC power supply by AC adaptor.
The refrigerator has two compartments - for cooling and for freezing. Device is intended
to be used in household and similar application such as
• Staff kitchen areas in shops, offices and other working environments.
• Farm houses
• Clients in hotels, motels and other residential type environments.
• Bed and breakfast type environments.
CAUTION! Health danger!
Please check if the cooling capacity of the device is suitable for storing the food or
medicine you wish to cool.
9
English
3. COOLING DEVICE FUNCTION
The cooler device can refrigerate or freeze food products. A fast-acting and efficient
cooling system provides maintenance-free cooling performance with a compressor and
control module. The cooling device is designed for mobile use and it can be used in the
various harsh condition and situation.
Function description:
• 3-level battery monitor for protecting the vehicle battery.
• Display with temperature gauge (switch off automatically at low battery voltage).
• Temperature adjustment (in 1°C or 2°F steps).
10
English
4. DISPLAY ELEMENTS AND OPERATION
NOTICE!
After buying your new cooling device, please keep the new cooling device
horizontally for more than 12 hours before starting.
Before staring your new cooling device for the first time, your should clean it inside and
outside with a damp cloth for hygienic reasons. Please also refer to the chapter «Cleaning
and Maintenance».
4.1 Display & control panel
4.2 Cooler device switch on/off
Switch on: Touch the button «ON/OFF» once lightly by your finger.
Switch off: Keep touching the button «ON/OFF» for about five seconds.
