WASHING MACHINE

SERVICE MANUAL

READ THIS MANUAL CAREFULLY TO DIAGNOSE TROUBLE

CORRECTLY BEFORE OFFERING SERVICE.

website : http: www.LGEservice.com

e-mail : http: LGEservice.com techsup.html

MODEL : WD(M)-80150FB

WD(M)-90150(5)FB

WD(M)-10150(5)FB/WD-10160(5)FB/WD-10164FB

WD(M)-11150(5)FB/WD-11151(6)FB/DWD-11151(6)FB/NWD-11151(6)FB

WD(M)-12150(5)FB/WD-12160(5)FB/WD-12164FB

WD(M)-13150(5)FB/WD-13151(6)FB/DWD-13151(6)FB/NWD-13151(6)FB

WD-1025FB/WD-10150(5)F

CAU ION

Jul. 2002 PRINTED IN KOREA

P No.:3828ER3013D

CON EN S

1. SPECIFICATION............................................................................................................................3

2. FEATURES & TECHNICAL EXPLANATION ................................................................................ 4

3. PARTS IDENTIFICATION ............................................................................................................ 6

4. INSTALLATION............................................................................................................................. 7

5. OPERATION ................................................................................................................................10

6. WIRING DIAGRAM PROGRAM CHART.....................................................................................12

7. TROUBLESHOOTING.................................................................................................................13

7-1.BEFORE PERFORMING SERVICE ....................................................................................13

7-2.TEST MODE ........................................................................................................................13

7-3.HOW TO KNOW THE WATER LEVEL FREQUENCY.........................................................13

7-4.ERROR DISPLAY ................................................................................................................14

8. ERROR DIAGNOSIS AND CHECK LIST ....................................................................................16

8-1. DIAGNOSIS AND ANSWER FOR ABNORMAL OPERATION ...........................................16

8-2. FAULT DIAGNOSIS AND TROUBLESHOOTING ..............................................................19

9. DISASSEMBLY INSTRUCTIONS ...............................................................................................25

10. EXPLODED VIEW .....................................................................................................................32

10-1. THE EXPLODED VIEW OF CABINET ASSEMBLY .........................................................32

10-2. THE EXPLODED VIEW OF CONTROL PANEL & DISPENSER ASSEMBLY..................33

10-3. THE EXPLODED VIEW OF DRUM & TUB ASSEMBLY...................................................34

APPENDIX (Replacement parts list).........................................................................................35

1. SPECIFICATION

ITEM

POWER SUPPLY 220-240V~, 50Hz

PRODUCT WEIGHT 5kg

WASHING

150W

SPIN (800rpm)

300W

DRAIN MOTOR

32W

WASH HEATER

2000W

WASH 45rpm

SPIN WD

(

)

-80150FB 400/500/ 00/800 rpm

(

)

-90150

(

)

FB 400/ 00/800/900 rpm

WD(M)-10150(5)FB / WD-101 0(5)FB / WD-1025FB / WD-101 4FB

400/ 00/800/1000 rpm

WD(M)-11150(5)FB / WD-11151( )FB / DWD-11151( )FB / NWD-11151( )FB

400/ 00/800/1100 rpm

WD(M)-12150(5)FB / WD-121 0(5)FB / WD-121 4FB / WD-10150(5)F

400/800/1000/1200 rpm

WD(M)-13150(5)FB / WD-13151( )FB/DWD-13151( )FB / NWD-13151( )FB

400/800/1100/1300 rpm

OPERATION WATER PRESSURE

0.3-10kgf/cm

(

30-1000kPa

)

CONTROL TYPE Electronic

Synthetic

(

3.5kg

)

, Delicate

(

3.0kg

)

Wool

(

2.0kg

)

, Hand Wash

(

2.0kg

)

, Quick 30

(

2.0kg

)

DIMENSION 00mm

(

)

×00mm

(

)

×850mm

(

)

WASH PROGRAM

Cotton, Synthetic, Delicate, Wool, Hand Wash, Quick 30, Rinse+Spin

OP Bio, Time Save, Rinse +, Pre-Wash, Crease Care, Rinse Hold

DOOR SWITCH TYPE Bi-Metal type

WATER LEVEL 9 steps

(

by sensor

)

RESERVATION From 3 hours to 19 hours

SENSING OF THE LAUNDRY AMOUNT

Adopted

FUZZY LOGIC Adopted

DISPLAY OF THE REMAINING TIME

Adopted

ERROR DIAGNOSIS 10 items

POWER AUTO OFF Adopted

CHILD LOCK Adopted

AUTO RESTART Adopted

ELECTRICITY

CONSUMPTION

REVOLUTION

SPEED

WASH CAPACITY

WD(M)-80150FB, WD(M)-90150(5)FB, WD(M)-10150(5)FB, WD-101 0(5)FB, WD-101 4FB, WD(M)-

11150(5)FB, WD(M)-11151( )FB, DWD-11151( )FB, NWD-11151( )FB, WD(M)-12150(5)FB, WD-121 4FB,

WD(M)-13150(5)FB, WD-13151( )FB, DWD-13151( )FB, NWD-13151( )FB, WD-1025FB, WD-10150(5)F

8.0kg ( WD-10150(5)F )

7.0kg

Jumbo drum

LG’s jumbo drum can wash about 40% more per load than

conventional washing machine. A bigger drum improves the

wash performance.

Protection against creases

With the alternate rotation of the drum, creasing in the laundry

is minimized.

More economical by Fuzzy Logic System

FUZZY Logic System detects the amount of load and water

temperature, and then determines the optimum water level

and washing time to minimize energy and water

consumption.

Child-Lock

The Child-Lock system has been developed to prevent

children from pressing any button

(except Power button)

to change the programme during operation.

Low noise speed control system

By sensing the amount of load and balance, automatical

distributes load evenly to minimize the spinning noise level.

Auto Restart

Although the washing machine is turned off by a power failure,

it restarts automatically where it stopped when power is

supplied again. and it will be the same the machine is

unplugged and is plugged in again.

2. FEATURES & TECHNICAL EXPLANATION

2-1.FEATURES

2-2.DETERMINE WASHING TIME BY FUZZY LOGIC

To get the best washing performance optimal time is determined by sensing of water temperature,

selected washing temperature and laundry amount.

2-3.WATER LEVEL CONTROL

This model adopts a pressure sensor which can sense the water level in the tub.

When the water level reaches to the preset level the water supply is stopped, then the washing program proceeds.

Spinning does not proceed until the water in the tub reduces a certain level.

2-4.THE DOOR CAN NOT BE OPENED

While program is operating.

While Door Lock light turns on.

FUZZY

LOGIC

laundry

amount

selected

washing

temperature

water

temperature

washing time

rinse time

spin rhythm, time

the best

washing

performance

SENSING

PROCESSING

DETERMINATION

EFFECT

3. PARTS IDENTIFICATION

Cold (1EA) Wrench

Power plug

Control panel

Door

Lower cover

Adjustable feet

(For detergent and

fabric softener)

Drawer

Drum

Lower cover cap

Drain plug

If the supply cord is damaged,

it must be replaced by the

manufacturer or its service agents

or a similarly qualified person in

order to avoid a hazard.

Drain pump filter

TimeS

ime Save

Crease Cease Carare

ACCESSORIES

Before servicing ask the customer what the trouble is.

Check the adjustment (power supply is 220-240V, remove the transit bolts....)

Check the troubles referring to the troubleshooting.

Decide service steps referring to disassembly instructions.

Then, service and repair.

After servicing, operate the appliance to see whether it works O K or NOT.

STANDARD INSTALLATION

The appliance should be installed as follows.

REMOVE THE TRANSIT INSTALL THE APPLIANCE ADJUST THE

BOLTS ON FLAT AND FIRM SURFACE HORIZONTAL

Remove the transit bolts Turn the adjustable feet to

(4EA: ) with supplied wrench. set the appliance horizontally.

Keep the transit bolts and

wrench for future use.

Insert the 4 caps provided

into the hole.

The appliance goes up by

rotating the feet clockwise.

The appliance comes down by

rotating the feet counter-

clockwise.

4. INSTALLATION

High

Low

HOW TO CONNECT INLET HOSE

Check that the rubber washer is inside of the

valve connector.

Connect the inlet hose firmly to prevent leak.

CONNECT DRAIN HOSE

CONNECT POWER PLUG

Make sure that the hose is not twisted.

The drain hose should be placed under 100cm from the floor.

Connect the power plug to the wall outlet. Avoid connecting several electric devices,

It may be the cause of a fire.

Avoid submerging the end of the hose.

TEST OPERATION

Connect the power plug to In case of cotton program.

the outlet.

Connect the inlet hose.

Preparation for Press the power button. Press

the

START PAUSE

washing. button.

Press both Pre Wash and Time

Delay button simultaneously the

present temperature will be

displayed.

Check if the drum rotates clockwise

and counterclockwise.

Check if water is supplied through

the detergent dispenser.

Power off and then power on.

Check if the door can be

opened after Door Lock lamp

turns off.

Turn off Wash and Rinse lamps

after pressing the Start/Pause

button and start the machine

again.

Check drain and spin.

If SVC is needed during

check, remove

the remaining water by pulling

out the hose cap.

Check the water heating. Check automatic reverse Check the water supply.

turn.

Check drain and spin

Power off and open the

Water removal

door
