LG FH0G7QDNL02 Manual de usuario

WASHING

MA

CHINE

P/NO : MFL67584564

Please read this manual carefully before operating

your washing machine and retain it for future reference.

FH0G7QDNL(0~9)2

FH0G6QDNL(0~9)2

MFL67584564

FH0G7EDNL(0~9)2

FH2G6EDNL(0~9)2

FH4G6TDNL(0~9)2

FH4G6VDNL(0~9)2

Rev. No.: 00_04/03/2017

Copyright © 2017 LG Electronics. All rights reserved.

leg

Adjustable

Lower cover

Door

Drawer

(For detergent and

fabric softener)

Power Plug

Control Panel

Drum

Drain Pump Filter

Drain Plug

Lower Cover Cap

If the supply cord is damaged,

it must be replaced by the

manufacturer or its service agents

order to avoid a hazard.

59kg / 2100W

* Part can be different according to different models.

No Spin/400/600/800/1000 : [FH0G7QDNL(0~9)2/ FH0G6QDNL(0~9)2/

FH0G7EDNL(0~9)2]

No Spin/400/800/1000/1200 : [FH2G6EDNL(0~9)2]

No Spin/400/800/1000/1400 : [FH4G6TDNL(0~9)2/FH4G6VDNL(0~9)2]

7.0kg : [FH0G7QDNL(0~9)2 / FH0G6QDNL(0~9)2]

7.5kg : [FH0G7EDNL(0~9)2/FH2G6EDNL(0~9)2]

8.0kg : [FH4G6TDNL(0~9)2]

9.0kg : [FH4G6VDNL(0~9)2]

carpeted ﬂoor.subjected

in caused

Machine.

5

o

adjustable legs

It is advisable to avoid, the usage of trolley & the movement of Washing Machine after installation.

As it may disturb the levelling of washer, which can create excessive noise & vibration.

6

Part can be different according to different models.

(1.0~10kgf/cm²)

Centre

Two rubber seals are provided

with inlet hose connectors.

These are used to prevent water

leakage.

Make sure the connection to tap

is sufﬁciently tight.

Check rubber seals in inlet hose

connectors. Screw the hose connector onto

water supply tap.

Hose

Connector

Rubber

seal

Break

PE Bags

getting wet

getting wet

/leakage
