LG M2262D Manual de usuario

www.lg.com

OWNER’S MANUAL

MONITOR TV

MONITOR TV MODELS

Please read this manual carefully before operating

your set and retain it for future reference.

ENGLISH

M2262D

M2362D

M2762D

M2262DP

M2362DP

M2762DP

PREPARATION

FRONT PANEL CONTROLS

■

This is a simp ified representation of the front pane . The image shown may be somewhat different from your

set.

INPUT

Button

INPUT

VOL

ENTER

Button

ENTER

Button

VOLUME

Buttons

CHANNEL

Buttons

Power

Button

Headphone

Jack

IR receiver

(Remote contro er

receiver)

LLiigghhtt SSeennssoorr

This is ens for ight sensor

se ect outside uminance,

when setting AUTO

BRIGHT ON.

PPoowweerr IInnddiiccaattoorr

i uminates b ue when the

set is switched on.

Note:You can adjust

Power indicator in the

OPTION menu.

PREPARATION

BACK PANEL INFORMATION

■

This is a simp ified representation of the back pane . The image shown may be somewhat different from your

set.

AV 1 AV 2

AC IN

VIDEO

COMPONENT

AV-IN

VIDEO

S-VIDEO

AUDIO

RS-232C IN

(CONTROL & SERVICE)

SERVICE

ONLY

RGB IN (PC)

DVI-D IN (PC)

HDMI IN

OPTICAL

DIGITAL

AUDIO OUT

AC IN

AUDIO IN

(RGB/DVI)

ANTENNA/

CABLE IN

AUDIO

(MONO)

910 11

87 12

3 4

Power Cord Socket

This set operates on AC power. The vo tage is indicated

on the Specifications page. Never attempt to operate

the set on DC power.

HDMI Input

High definition inputs. These two inputs accept TV

Video, not PC Video. They a so accept TV Video from a

DVI connection when using an adapter. The HDMI

inputs support video and audio. When using an adapter

for DVI, they on y accept video.

DVI-D Input

Digita PC input.

RS-232C IN (CONTROL & SERVICE) PORT

Seria port used for externa contro or service.

RGB INPUT (PC)

Ana og PC input. A so known as VGA.

S-Video Input

Standard definition (480i), but better qua ity than

standard A/V input.

SERVICE ONLY PORT

RGB/DVI Audio Input

This is the audio input for the RGB and DVI-D video

inputs.

Optica Digita Audio Out

Use this to export audio to an externa amp ifer.

Component Input

High definition ana og input.

Audio/Video Input

Standard definition input.

Antenna Input

Connect over-the-air or cab e signa s to this jack.

PREPARATION

STAND INSTALLATION

■

The image shown may be somewhat different from your set.

Carefu y p ace the product screen side down on a

cushioned surface that wi protect product and

screen from damage.

Insert the SSttaanndd BBaasseeinto the product.

Turn the SSttaanndd BBaassee LLoocckkthrough 90°to fix the stand base to the stand body.

SSttaanndd BBaassee LLoocckk

<<MM22226622DD//MM22336622DD//MM22226622DDPP//MM22336622DDPP>>

SSttaanndd BBaassee

PREPARATION

STAND INSTALLATION

■

The image shown may be somewhat different from your set.

Carefu y p ace the product screen side down on a cushioned sur-

face that wi protect product and screen from damage.

Insert the SSttaanndd BBaasseeinto the product.

Use a CCooiinn on the bottom of the stand base and turn the

screw c ockwise to tighten.

<<MM22776622DD//MM22776622DDPP>>

SSttaanndd BBaassee

CCooiinn

PREPARATION

DETACHING STAND

■

The image shown may be somewhat different from your set.

P ace the set screen side down on a cushion or

soft c oth.

Detach the monitor to the SSttaanndd BBaasseeby

turning the screw to the eft.

Turn the SSttaanndd BBaassee LLoocckkthrough 90°to separate the stand base from the stand body.

Pushing LLaattcchhinside, Take the stand base from stand body.

LLaattcchh

<<MM22226622DD//MM22336622DD//MM22226622DDPP//MM22336622DDPP>>

SSttaanndd BBaassee

PREPARATION

DETACHING STAND

■

The image shown may be somewhat different from your set.

P ace the set screen side down on a cushion or soft c oth.

Detach the stand base from the set by turning the screw to the

eft with a coin.

Pu the stand base.

<<MM22776622DD//MM22776622DDPP>>

SSttaanndd BBaassee

CCooiinn

PREPARATION

<<MM22776622DD//MM22776622DDPP>>

DETACHING STAND BODY

1. Remove the screw 4 point.

2. Pu the stand body.

1. Remove the screw 2 point.

2. Pu the stand body.

■

The image shown may be somewhat different from your set.

■

Remove the Stand Body in the same way as the fo owing when using it as a Wa Hook.

<<MM22226622DD//MM22336622DD//MM22226622DDPP//MM22336622DDPP>>

PREPARATION

DESKTOP PEDESTAL INSTALLATION

For proper venti ation, a ow a c earance of 10 cm on each side and from the wa .

WALL MOUNT: HORIZONTAL INSTALLATION

For proper venti ation, a ow a c earance of 10 cm on each side and from the wa . Fo ow the instructions inc ud-

ed with the wa mount.

1100 ccmm

1100 ccmm1100 ccmm

1100 ccmm

SWIVEL STAND(On y M2762D/M2762DP)

PREPARATION

■

The image shown may be somewhat different from your set.

After insta ing the set, you can adjust the set manua y to the eft or right direction by 179 degrees to suit your

viewing position.

179

POSITIONING YOUR DISPLAY

■

The image shown may be somewhat different from your set.

Adjust the position of the pane in various ways for maximum comfort.

•• TTiitt rraannggee

-5
