Guides on Using Product Functions

(Windows,Mac)

Please read this manual carefully before operating your set and

retain it for future reference.

P/NO : MFL68001202(1308-REV01)

Printed in Korea

ESP

ENGLISH

 Failing to set the video card to the recommended (optimal) resolution may result in blurred text, a dimmed screen, a

truncated display area, or misalignment of the display.

 The configuration procedure may differ depending on your computer and/or operating system. Also, some video

cards may not support certain resolutions. If this is the case, contact the manufacturer of the computer or video

card for assistance.

 Some video cards may not support 2560x1080 resolution. It is recommended to use a video card that supports

2560 x 1080 resolution. Even when you set the resolution to 2560 x 1080 on your PC, the actual PC output may

not support the resolution. Press the OK button on the monitor to check the current resolution of your PC. (Shown

on the OSD at the top right of the monitor screen.)

Graphics Card Interface OS

DVI-D HDMI DP Win XP Win Vista Win 7 Win 8 Mac

2560 x 1080

Intel HD3000 or higher O O O

No constraintsAMD HD54XX/HD64XX/

HD77XX or higher OOO

NVIDIA GeForce 300 or higher O O O

CAUTION

 The setting method can vary depending on the computer and the O/S. You may not be able to select certain

resolutions depending on the video card performance. In such cases, please refer to the user's manual of the

computer and/or video card.

3Choose the "Settings" menu

and select an optimal resolution.

(2560x1080)

4Click the [Apply] button to

complete resolution setting.

5Select the [Advanced] button.

6Select the [Monitor] tab and set

the vertical frequency to 60Hz in the

"Refresh Rate" column.

7Click the [Apply] button to

complete optimal frequency setting.

[Windows XP]

1Move the mouse pointer to an

empty area on the Windows screen

(with no icons or task bars) and

click the right mouse button.

2When the pop-up menu appears,

click the "Property".

123

Guides on Using Product Functions (Windows)

Precautions for Changing Resolution

System Requirements for Graphics Cards

ESPENGLISH

[Windows Vista]

3Choose the "Display Settings"

menu and select an optimal

resolution.(2560x1080)

Click the [Apply] button to

complete resolution setting.

Select the [Advanced] button.

Select the [Monitor] tab and set

the vertical frequency to 60Hz in the

"Refresh Rate" column.

Click the [Apply] button to

complete optimal frequency setting.

1Move the mouse pointer to an

empty area on the Windows screen

(with no icons or task bars) and

click the right mouse button.

2When the pop-up menu

appears, click the "Personalize".

Personalize Display Settings

3Choose the "Settings" menu

and select an optimal resolution.

(2560x1080)

4Click the [Apply] button to

complete resolution setting.

5Select the [Advanced] button.

6Select the [Monitor] tab and set

the vertical frequency to 60Hz in the

"Refresh Rate" column.

7Click the [Apply] button to

complete optimal frequency setting.

1Move the mouse pointer to an

empty area on the Windows screen

(with no icons or task bars) and

click the right mouse button.

2When the pop-up menu appears,

click the "Screen resolution".

[Windows 7,Windows 8]

Screen resolution

ESP

ENGLISH

Using the Program Guide Function

Confirm the channel information.

You can move up or down by using the ▲and▼buttons.

耉擕湮氢

笑殎

笹築耉擕

瓥觽耉擕

濮畦礍摹

簵穮譍

秆璆湭梡篚点蠡皡

3,3

笑瓶暩糖

笑襪湭梡

瓩篚渙昹忉蝽瓩篚

摝必懵

訚笽

笹築

3,3瓩篚

訙渹萱懵

Using the buttons, you can select the Watch or Remind functions.

Displays the program guide for all of the channels.

* Depending on your country, this function may not

be available.















J

Schedule Other channels

Watch

MONO

Move OK

PM 3:56

PM 3:41

PM 3:56 PM 4:17

PM 4:17 PM 4:25

PM 4:25 PM 4:41

PM 4:41 PM 4:57

All

Move OK All

Schedule Other channels You can check the channel information for the current channel

or for all channels.

Press the button on the remote control.

* Press the "Info" key in the countries where the Guide button is not available.

It is possible to switch channels while operating the information display and, if the channel is changed,

the information will then be updated to display the next channel instead.

NOTE

ESPENGLISH

- Screen Split: Automatically splits the monitor screen into the desired layouts.

- Auto Resolution

(for 29EA73,29EB73 and 29MA73 only)

: Automatically switches to the optimal resolution when the monitor is

connected to the PC in PBP mode.

* The software listed above can be installed using the CD provided with the product or downloaded from the LG Electronics website.

* Graphics card: It is recommended to use a graphics card that supports 2560 x 1080 resolution.

Software

Installation

Priority

(required/

optional)

Supported Interface Supported OS

DVI DP HDMI Win XP Win Vista Win 7 Win 8 Mac Linux

Screen Split Optional O X O O O O O 10.7 / 10.8 X

Monitor Driver Optional O O O O O O O X X

Auto Resolution

(for 29EA73,29EB73 and 29MA73 only) Required O O O X X O O X X

LG Software Introduction/System Requirements

Driver

- Installation priority (required/optional): Optional

- Usage: The resolution and frequency are adjusted for the monitor.

How to Install

- Installing with the CD provided

: Insert the user manual CD provided in the product box into the PC's CD drive and install the program.

- Downloading from the LG Electronics website

: Visit the LG Electronics website →CUSTOMER SERVICES →DOWNLOADS →Drivers/Software →Select your product and model

→Install the software

ESP

ENGLISH

Screen Split (MONITOR Screen Split Software)

- Installation priority (required/optional): Optional

- Usage: Automatically splits the monitor screen into desired

layouts (2 sections, 3 sections, or 4 sections).

How to Install

- Installing with the CD provided

: Insert the user manual CD provided in the product box into

the PC's CD drive and install the LG Monitor Software.

On the Select Options window, select Screen Split and

continue.

- Downloading from the LG Electronics website

: Visit the LG Electronics website →CUSTOMER SERVICES

→DOWNLOADS →Drivers/Software →Select your product

and model →Install the software

How to Run

Double-click on the shortcut icon on the desktop, or

Click on the tray icon at the bottom right of the PC screen.

Check "I accept the terms of the agreement" on the License

Agreement screen and then click on the [Next] button.

When the installation is complete, restart the system.

How to Use

* For details on using the software, refer to the program's Help.

1. Click on the tray icon at the bottom right of the PC screen.

2. Select a screen layout.

3. The screen split layout is applied.

ESPENGLISH

Using PIP

How to Run

Setting the PIP

Press the

秆璆湭梡篚点蠡皡

3,3

笑襪湭梡

瓩篚渙昹

3,3瓩篚

訙渹萱懵

忉蝽瓩篚

摝必懵

訚笽

笹築

button on the remote control. 2. Select an input to use as the sub screen.

- Usage: The input for each device is simultaneously displayed on the monitor screen.

* If the Main Input is TV, component, or AV, then the PIP function is not available.

1 Press the PIP Settings button on the remote control and then select "Position."

2 Select the desired position using the arrow keys and then press the OK button.

* Activate when the size is not PIP Balanced.

■Size: Set the PIP screen size.

■Audio-input: Select an audio output device.

■Position: Set the PIP position.

■Ratio: Set the PIP sub screen ratio.

■Transparency: Set the transparency of the PIP window.

1 Press the PIP Settings button on the remote control and then select "Ratio."

2 Select the desired position using the arrow keys and then press the OK button.

* Activate when the size is PIP Balanced.

1 Press the PIP Settings button on the remote control and then select "Transparency."

2 Select the desired position using the arrow keys and then press the OK button.

* Activate when the size is not PIP Balanced.

1 Press the PIP Settings button on the remote control and then select "Size."

2 Select the desired size using the arrow keys.

1 Press the PIP Settings button on the remote control and then select "Audio-input."

2 Select the desired audio input using the arrow keys.

Sub Input

DVI HDMI1

HDMI2/MHL DisplayPort

Ratio

Transparency

Ratio

Position

Audio-input

5$7,2

PIP SIZE

5$7,2

PIP SETTINGS

ESP

ENGLISH

Guides on Using Product Functions (Mac)

Precautions for Changing Resolution

* For HDMI connections, you may be required to enforce custom settings from the graphics card control panel or update to the latest

graphics card driver.

* Support settings are subject to change.

[Mac]

Graphics Card Interface OS

DVI-D HDMI DP Win XP Win Vista Win 7 Win 8 Mac

2560 x 1080

Intel HD3000 or higher O O O

No constraintsAMD HD54XX/HD64XX/HD77XX

or higher OOO

NVIDIA GeForce 300 or higher O O O

1. On the Doc bar, click on the System Preferences icon. 4. In the Display tab, select Best for display. The display is now

set to the recommended resolution (2560 x 1080).

3. Select Scaled and select a desired resolution and a refresh

rate. Settings are now complete.

2. When the System Preferences window opens, select

“Display.”

 Failing to set the video card to the recommended (optimal) resolution may result in blurred text, a dimmed screen, a

truncated display area, or misalignment of the display.

 The configuration procedure may differ depending on your computer and/or operating system. Also, some video

cards may not support certain resolutions. If this is the case, contact the manufacturer of the computer or video

card for assistance.

 Some video cards may not support 2560x1080 resolution. It is recommended to use a video card that supports

2560 x 1080 resolution. Even when you set the resolution to 2560 x 1080 on your PC, the actual PC output may

not support the resolution. Press the OK button on the monitor to check the current resolution of your PC. (Shown

on the OSD at the top right of the monitor screen.)

System Requirements for Graphics Cards
