OWNER’S MANUAL

SOUND BAR

Please read this manual carefully before operating your set and retain it for future

reference.

Model

SPM2

2102_Rev01

www.lg.com

Sound Bar Quick Guide

Installing and using the Product

aConnect the sound bar to your TV via an optical cable or an HDMI

cable.

HDMI OUT

OPTICAL

HDMI OUT

(TV ARC)

HDMI IN

(ARC)

HDMI IN OPTICAL

OUT

ASound bar

BRemote Control Receiver / Status LED ([See

“Status LED” on page 7.)

CExternal Device - (Blu-ray player, game console,

etc.)

Soundbar Quick Guide

b If you are using an external device (ex. Blu-ray player, game console, etc.), connect it to the sound bar via an

HDMI cable.

cUsing the product with your TV ([See “Connecting to the TV”

on page 11.)

APress the Function button repeatedly until the rst (Top) LED among the three LEDs lights up in white.

B On your TV's settings, set the output speaker to [HDMI ARC], [Optical], or [External Speaker].

dConnecting the product to your smartphone via Bluetooth ([

See “Connecting via Bluetooth” on page 19.)

A Tap the Settings button on your smartphone and select Bluetooth. Turn on the Bluetooth function. (

Off > On)

BPress the Bluetooth pair button. After a moment, the second LED lights up in blue and blinking among

the three LEDs.

C Find and tap the product on your smartphone. The product appears as ”LG SPM2 (XX)”.

eConnecting to the LG Sound Bar app ([See “Connecting with a

Smartphone via LG Sound Bar app” on page 22.)

AFind and install the LG Sound Bar app on Google Play or App Store from your smartphone.

B You can get more information regarding its use by selecting [Help] in [Setting].

Table of Contents

Sound Bar Quick Guide

2Installing and using the Product

Installation

5Connecting the Product

Exploring the Product

6Front

8 Back

9Exploring Remote Control

Connecting to the TV

11 Connecting with an Optical Cable

13 Connecting with LG Sound Sync (Wireless)

14 Connecting with an HDMI Cable

Connecting to an External Device

16 Connecting with an HDMI Cable

18 Connecting with an Optical Cable

Using the Product as an Audio

System

19 Connecting via Bluetooth

22 Connecting with a Smartphone via LG Sound

Bar app

24 Connecting to a USB Storage Device

Mounting the Product to a Wall

27 Mounting the Product to a Wall

Safety Precautions

29 Safety and Regulatory

Before Reporting Product

Malfunction

32 Troubleshooting

Appendix

34 Specications

35 Registered Trademarks and Licenses

36 Handling the Product

Installation

Connecting the Product

After completing installation, plug the sound bar power cable into an outlet in the following order.

a Plug the power cable to the AC IN (AC input) terminal on the back of the product.

b Plug the power cable connected to the product into an outlet. You will see the LED on the front of the

product light up in red.

AC IN

Installation

Exploring the Product

Front

b b

aPower This turns the product on/off.

Function Press the button repeatedly to select the desired function or input mode.

Status Description

OPTICAL / HDMI

ARC

Connects the product to a TV that supports an optical

cable, ARC or LG Sound Sync.

Bluetooth Connects the product via Bluetooth

LG TV Connects the product to a TV that supports LG Sound

Sync (Wireless)

HDMI IN Connects the product to an HDMI input port

USB Connects the product to a USB storage device

Volume This adjusts the speaker volume.

Bluetooth pair It allows you to pair your Bluetooth device such as a smartphone to this product

for three minutes. ([See “Connecting via Bluetooth” on page 19.)

It allows you to pair your LG TV to this product for three minutes. ([See

“Connecting with LG Sound Sync (Wireless)” on page 13.)

bPassive Radiator Make the bass sound improved.

cRemote Control

Receiver

This receives wireless signals from the remote control.

Exploring the Product

dStatus LED • Options such as input mode and volume are light up in Red/Yellow green/

White/Blue/ Green LED.

• If there is no active input for 15 seconds, the status LED will automatically dim.

When you press the button, the status LED will light up again.

Power On / Standby Volume

Power on Standby Volume control Mute

Red blinking Red

Yellow green

• Volume up: Every time the

volume level gets upper

than a certain level, the LEDs

light up one by one and gets

brighter.

• Volume down: Every time

the volume level gets lower

than a certain level, the LEDs

turn off one by one and gets

darker.

Yellow green

(All the

lights are

blinking)

Function

OPTICAL

/ HDMI

ARC

Bluetooth

ready Bluetooth LG TV HDMI IN USB

White Blue

blinking Blue White White Green

Note • To reduce power consumption, the product will automatically turn off after 15 minutes of no

input signal from an external device.

How to disconnect the wireless network connection or the wireless

device

Set up the Auto power function to off by the app and turn off the product.

Back

HDMI OUT

(TV ARC)

HDMI IN OPTICAL

AC IN

aHDMI IN Plug in an HDMI cable to connect an external device to the

product.

bHDMI OUT (TV ARC) Plug in an HDMI cable to connect the TV to the product.

cOPTICAL IN Plug in an optical cable to connect the TV to the product.

dUSB port Plug in a USB storage device to play music with the product.

eAC IN Plug in a power cord.

Exploring Remote Control

You can use the remote to control all functions of the product, from turning the power on/off to enabling

cinematic sound.

Replacement of Battery

Use AA 1.5V batteries. Replace the two batteries by

inserting them into the remote control in accordance

with the directions indicated.

A Open the battery cover on the back of the remote

control.

B Insert the batteries with the + and – ends

corresponding to the markings.

C Close the battery cover.

Risk of re or explosion if the battery is replaced by an

incorrect type.

aPower Turns the product on/off

bVolume Adjusts the sound volume

cBluetooth pair It allows you to pair your Bluetooth device such as a smartphone to this product

for three minutes. ([See “Connecting via Bluetooth” on page 19.)

It allows you to pair your LG TV to this product for three minutes. ([See

“Connecting with LG Sound Sync (Wireless)” on page 13.)

dAI Sound Pro Articial intelligence selects the optimal sound settings to suit your content.

Music (Standard) You can enjoy optimized sound.

Cinema Play content with 3D sound similar to a movie theater.

Game Optimized sound for game.

eMute This turns off the sound from the product.

fFunction Press the button repeatedly to select the desired input mode or function.

gUp/Down/Left/

Right

Up/Down: You can press the button to adjust the built-in woofer level.

Left/Right: If you play a previous song, press Left button. If you play a next song,

press Right button.

hPlay/Pause If you play or pause a song, press this button.
