OWNER'S MANUAL
LG CLOUD V SERIES BOX
CBV42
Please read the safety information carefully before using the product.
LG Cloud V Series Box Model List
English
2
ENG
English
Table of Contents
Table of Contents
3ASSEMBLING AND
PREPARING
3 Unpacking
4 Parts and Buttons
5 Product Installation
5 - Using in Horizontal Position
5 - Using in Vertical Position
5 - Mounting on the Back of the Monitor
6CONNECTING LAN/
PERIPHERALS
6 - LAN Connection
6 - DisplayPort Connection
7 - Extended Monitor Connection
7 - Peripheral device connection
9TROUBLESHOOTING
10 SPECIFICATIONS
10 Power Indicator
11 USING CLOUD SOLUTION
3
ENG
English
ASSEMBLING AND PREPARING
Main Unit Stand Base Mount Bracket 4 Screws
Power CordCD / Card DisplayPort Cable
AC/DC Adapter
ASSEMBLING AND PREPARING
Unpacking
Please check whether all the components are included in the box before using the product. If there are
missing components, contact the retail store where you purchased the product. Note that the product and
components may look different from those shown here.
yOnly use an approved LG power adapter.
yDamage caused by other power adapters is not covered by warranty.
yNote that the components may look different from those shown here.
yWithout prior notice, all information and specifications in this manual are subject to change to improve
the performance of the product.
yTo purchase optional accessories, visit an electronics store or online shopping site or contact the retail
store where you purchased the product.
CAUTION
NOTE
4
ENG
English
ASSEMBLING AND PREPARING
Parts and Buttons
Power Indicator &
Power Button
yOn: Power On
yOff: Power Off
Input Connectors
Front Side
Rear Side
5
ENG
English
ASSEMBLING AND PREPARING
Product Installation
Using in Horizontal Position
Using in Vertical Position
1Firmly attach the stand on the bottom of the
product as illustrated below.
2Using a coin, turn the screw clockwise to
secure the stand base.
Mounting on the Back of the
Monitor
1Fix the mount bracket on the back of the
monitor with 4 screws as illustrated below.
2Put the product on the two latches as illustrated
below.
Assemble the product by aligning the below
two holes out of 4 holes on the product.
yAttach the stand
base to the
stand hinge with
its front part fac-
ing forward.
yIf this product is used with upside down, it
may not work properly.
yUse the product with the Kensington lock
facing upward.
NOTE
yThe product may not be mounted on some
monitors with mount bracket.
- In this case, use the product in horizontal
or vertical position.
yWhen connecting the peripherals after
mounting the product on the monitor, be
sure to hold the product.
CAUTION
NOTE
6
ENG
English
Connecting LAN/Peripherals
CONNECTING LAN/PERIPHERALS
DisplayPort Connection
Transmits digital video signals to the monitor. Con-
nect the product using the DisplayPort cable as
illustrated below.
yThe LAN cable is sold separately.
yThe following LAN cable type can be used:
Standard: IEEE 802.3 ETHERNET
yConnect the LAN cable and the peripheral de-
vices to use the CITRIX cloud monitor.
DP OUT
DP IN
MONITOR 1
DP OUT
DP IN
MONITOR 1
NOTE
LAN Connection
Connect the router or switch to the monitor using a
LAN cable as illustrated below.
7
ENG
English
Connecting LAN/Peripherals
yConnect the input signal cable
and turn in the direction of the
arrow. To prevent disconnection
secure the cable tightly.
yWhen connecting the power cord to the
outlet, use a grounded (3-hole) multi-socket
or a grounded power outlet.
yDVI cable is not included in the basic com-
ponents. Use the DVI cable provided with
the monitor or the standard DVI cable.
yIf the main/sub screen was changed after
extended monitor was connected, the main/
sub can be changed in Setup.
Extended Monitor Connection
Transmits digital video signals to the monitor. Con-
nect the product using the DVI cable as illustrated
below.
DP OUT
DP IN
MONITOR 1
DP OUT
DP IN
MONITOR 1
DP OUT
DP IN
MONITOR 1
Peripheral device connection
Connect peripheral devices to the monitor using
USB, microphone and headphone ports.
Front Side
Rear Side
CAUTION
NOTE
NOTE
8
ENG
English
Connecting LAN/Peripherals
yThe cloud server settings may affect the perfor-
mance of the headphones, earphones or speak-
ers depending on the connected cloud server.
yThe cloud server settings may affect the
functions or speed of the specific USB stor-
age device depending on the connected
cloud server.
yPeripheral devices are sold separately.
yThe USB ports can be used to connect the
keyboard, mouse, and other USB devices.
yFor an angle plug earphone/microphone, it is
difficult connect it with a peripheral device, so
use a straight type.
Angle Type Straight Type
NOTE
NOTE
9
ENG
English
TROUBLESHOOTING
TROUBLESHOOTING
Nothing is displayed on the screen
Is the power adapter of the Box
plugged in ?
yCheck if the power cord is correctly plugged in to the power outlet.
Is the power indicator on?
yCheck the power indicator.
Is the power indicator displaying as
red?
yAdjust the brightness and the contrast of the connected monitor.
Are the BOX and the monitor con-
nected with the signal cable?
yCheck whether the monitor and the Box are properly connected to DVI
cable or DisplayPort cable.
yThis box type product is used by connecting the monitor.
yIf the monitor does not work normally, the screen may not be displayed correctly.
NOTE
10
ENG
English
SPECIFICATIONS
SPECIFICATIONS
Supported Dis-
play Resolution
Maximum Resolution 1920 x 1200 @ 60 Hz
Recommended Resolution 1920 x 1200 @ 60 Hz
Power Voltage 19 V 1.2 A
Power consumption (Typ.)
(Cloud)
Cloud Mode 6 W
Off Mode ≤ 0.5 W
Dimension Dimensions (Width x Height x Depth)
With stand 70.3 mm x 189.3 mm x 143.6 mm
Without Stand 185 mm x 30.5 mm x 143.6 mm
Weight (Without
Packaging)
0.6 kg
AC/DC adapter Type ADS-40SG-19-3 19025G, manufactured by SHENZHEN HONOR ELECTRONIC
Or Type LCAP21, manufactured by LIEN CHANG ELECTRONIC ENTERPRISE
Or Type PSAB-L203A, manufactured by LG Innotek Co.,Ltd
Output: 19 V 1.3 A
Environmental
Conditions
Operating Condition Temperature: 10°C to 35°C; Humidity: 10% to 80%
Storing Condition Temperature: -20°C to 60°C; Humidity: 5% to 90%
The specifications are subject to change without notice.
Power Indicator
Mode LED Color
On Mode Red
Off Mode Off
