LG GR-419ST Manual de usuario

FRIDGE-FREEZER

User's Guide

Please read this User's Guide carefully before

operating and keep it handy for reference at all times.

REFRIGERATEUR-

CONGELATEUR

Manuel de l’utilisateur

Lisez avec attention ce Manuel de l’utilisateur

avant d’utiliser le réfrigérateur et gardez-le

toujours pour toute référence.

FRIGORÍFICO

CONGELADOR

Guía del usuario

Lea esta guía del usuario con atención antes de utilizar la

unidad y manténgala a mano para consultas posteriores.

Models / Modèles / Modelos

GR-419ST

website:http://www.lg.ca

☎1-888-LGCANADA

FOR LG CUSTOMER SERVICE

EL SERVICIO DE ATENCIÒN AL CLIENTE DE LG

POUR SERVICE À LA CLIENTÈLE DE LG

Registration

Important Safety Instruction

Identification of Parts

Installation

Starting

Temperature Control

Vacation

Express Frz.

Self Test

Door Alarm

Ice Making

Defrosting

Storing Food

General Information

Lamp Replacement

To Reverse the Doors

Cleaning

Trouble Shooting

Table of Contents

Introduction

Installation

Operation

Suggestion On

Food storage

Care and

Maintenance

Trouble Shooting

Introduction

The model and serial number are found on the rear of

this unit. This number is unique to this unit and not

available to others. You should record requested

information here and retain this guide as a permanent

record of your purchase. Staple your receipt here.

Date of Purchase :

Dealer Purchased From :

Dealer Address :

Dealer Phone No. :

Model No. :

Serial No. :

Important Safety Instruction

This fridge-freezer must be properly installed and

located in accordance with the Installation

Instruction before it is used.

Never unplug your fridge-freezer by pulling on the

power cord. Always grip plug firmly and pull straight

out from the outlet.

When moving your appliance away from the wall,

be careful not to roll over or damage the power

cord.

After your fridge-freezer is in operation, do not

touch the cold surfaces in the freezer compartment,

particularly when hands are damp or wet. Skin may

adhere to these extremely cold surfaces.

Registration

Introduction

Precaution

Introduction

Pull out the power plug prior to cleaning the fridge-

freezer.

Never damage, serverely bend, pull out, or twist the

power cord because power cord damage may cause a fire

or electronic shock.

Never place glass products in the freezer because they

may be broken when their inner contents are frozen.

If possible, connect the fridge-freezer to its own individual

electrical outlet to prevent it and other appliances or

household lights from causing an overload.

The supply plug of the refrigerator-freezer should be

placed in easy accessible position for quick disconnection

in emergency.

If the supply cord is damaged, it must be replaced by the

manufacturer or its service agent or a similarly qualified

person in order to avoid a hazard.

Don't store or use gasoline or other flammable vapors

and liquids in the vicinity of this or any other appliance.

In the event of an electric short circuit, grounding

(earthing) reduces the risk of electric shock by providing

an escape wire for the electric current. In order to prevent

possible electric shock, this appliance must be grounded.

Improper use of the grounding plug can result in an

electric shock. Consult a qualified electrician or service

person if the grounding instructions are not completely

understood, or if you have doubts on whether the

appliance is properly grounded.

Important Safety Instruction

Accessibility of

Supply Plug

Precaution

Supply Cord

Replacement

Danger

Don't store

Grounding

(Earthing)

Risk of child entrapment.

Before you throw away your old refrigerator or freezer:

Take off the doors.

Leave the shelves in place so that children may not easily

climb inside.

Don’t Use on

Extension Cord

Identification of Parts

Introduction

If you find some parts missing from your unit, they

may be parts only used in other models.

Note

Removable

Glass Shelf

Display

Multi-air Flow Duct

Vegetable Drawer

(Optional)

Used to keep fruits

and vegetables, etc.

fresh and crisp.

Ice Tray

Freezer

Compartment

Removable

Plinth

Leveling Screw

Door Basket

Egg Tray

2 Bottle

Door Basket

Bottle Guide

Utility Corner

Handle

Installation

1. Select a good location.

Place your fridge-freezer where it is easy to use.

2. Avoid placing the unit near heat sources,

direct sunlight or moisture.

3. To ensure proper air circulation around the fridge -

freezer, please maintain sufficient space on both the

sides as well as top and maintain at least 2 inches (5

cm) from the rear wall.

4. To avoid vibration, the unit must be leveled.

If required, adjust the leveling screws to compensate

for the uneven floor.

The front should be slightly higher than the rear to aid

in door closing.

Leveling screws can be turned easily by tipping the

cabinet slightly.

Turn the leveling screws counterclockwise( ) to

raise the unit, clockwise( ) to lower it.

5. Clean your fridge-freezer thoroughly and wipe off all

dust accumulated during shipping.

6. Install accessories such as ice cube box, etc., in their

proper places. They are packed together to prevent

possible damage during shipment.

7. Connect the power supply cord (or plug) to the outlet.

Don't double up with other appliances on the same

outlet.

When your fridge-freezer is installed, allow it 2-3 hours to

stabilize at normal operating temperature prior to filling

it with fresh or frozen foods.

If power plug is disconnected, allow 5 minutes delay

before restarting.

Your fridge-freezer is now ready for use.

Installation

Starting

Operation

• Your fridge-freezer has controls that let you regulate

the temperature in the fridge and freezer

compartments. These controls are on the top of the

fridge-freezer.

• Initially set the TEMP(erature) CONTROL at “NORMAL”.

Then adjust the compartment temperature according to

your desire.

• By pressing the REF.TEMP (Refrigerator Temperature)

button, you can adjust the temperature of the

Refrigerator as indicated by the numbers of lamps it.

(the setting is composed of five steps, 5 lamps it

indicates coldest.)

• When you are starting the Fridge-Freezer or connecting

the power plug to the outlet, temperature setting is

automatically set to the “NORMAL”.

• Initially set the TEMP. (erature) CONTROL at

“NORMAL”. Then adjust the compartment temperature

according to your desire.

• By pressing the FRZ. TEMP (Freezer Temperature)

button, you can adjust the temperature of the Freezer

as indicated by the numbers of lamps it.

(the setting is composed of five steps, 5 lamps it

indicates coldest.)

• When you are starting the Fridge-Freezer or connecting

the power plug to the outlet, temperature setting is

automatically set to the “NORMAL”.

Temperature Control

Fridge

Freezer

NORMAL

Operation

• This function makes the fridge-freezer work in a power

saving mode which is useful when you are

away on holiday, by reducing energy

consumption as much as possible.

Pressing ‘VACATION’ starts operation with

lamp ON and pressing it again stops the

operation.

• This function is used when you want to

freeze the foods quickly. Press the EXPRESS

FRZ. button once, and then the quick freeze

operation starts with the lamp it.

• The EXPRESS FRZ. operation takes about 3

hours. When its operation ends, it automatically returns

to the normal state. If you want to stop the quick freeze

operation, press the EXPRESS FRZ. button once more,

the lamp goes out, and the EXPRESS FRZ. operation

stops and the refrigerator returns to the normal state.

Vacation

Express Frz.

This function allows you to check for operational

problems. If you think you have a problem with your

fridge-freezer, then press the temperature control button:

- If the indicate lights move up or down, then there is no

problem with your fridge-freezer.

- If the indicate lights do not move up or down, then

please leave the power connected and call your nearest

service agent.

When the door of the fridge is left opened for a while,

the alarm sounds.

• To make ice cubes, fill the ice

tray to the water level and

place it in the freezer.

• If ice cubes are required fast,

press the 'EXPRESS FRZ.'

button.

• To remove ice cubes,

hold the tray at its ends and

twist gently.

Defrosting takes place automatically.

The defrosting water flows down to the evaporating tray

and is evaporated automatically.

Operation

Self Test

Ice Making

Door Alarm

Defrosting

To remove ice cubes easily, run water on the tray before

twisting.

Tip

Suggestions on food storage

Storing Food

ww Caution

• Do not store food which goes bad easily at low

temperature, such as banana, and melon.

• Allow hot food to cool prior to storing. Placing hot food

in the fridge-freezer could spoil other food, and lead to

higher electric bills.

• When storing the food, use a container with a lid. This

prevents moisture from evaporating, and helps food to

keep its taste and nutrients.

• Do not block air vents with food. Smooth circulation of

cold air keeps fridge-freezer temperature even.

• Do not open the door frequently. Opening the door lets

warm air enter the fridge-freezer, and cause

temperature to rise.

• Never keep too many foods in door rack, as this may

stop the door from fully closing.

• Do not store bottles in the freezer compartment - they

may break when frozen.

• Do not refreeze food that has been thawed. This causes

loss of taste and nutrition.

• Do not store pharmaceutical products, scientific

materials or other temperature sensitive products in the

refrigerator.

Products that require strict temperature controls must

not be stored in the refrigerator.

Otros manuales para GR-419ST

Tabla de contenidos

Otros manuales de Refrigerador de LG

LG LRTBC2021BS Service Manual de usuario

LG LBN10551PS Manual de usuario

LG SXS Refrigerator Manual de usuario

LG LRONC0705V Manual de usuario

LG GL-B282SMCL Manual de usuario

LG GM5148AERV Manual de usuario

LG LRBC20512 Series Manual de usuario

LG LMXC23746S Manual de usuario

LG GT58BP Series Manual de usuario

LG GSJ960MCCZ Manual de usuario

LG GT51SGP Manual de usuario

LG LRSC 26945TT, LRSC 26944TT, LRSC 26930TT, LRSC 26922TT, LRSC 26920TT, LRSC 26911TT, LRSC 26910TT, LRSC 26944SW, LRSC 26930SW,... Manual de usuario

LG LMXC23746D Manual de usuario

LG GN-M562GLHH Manual de usuario

LG LSXS22423 series Manual de usuario

LG LFX21975ST - 20.5 Cu. Ft. Bottom Freezer... Manual de usuario

LG LMX30995 Instrucciones de montaje

LG LMX28988SB Manual de usuario

LG LRTN09314SW Instrucciones de montaje

LG LFX31995ST Guía de instalación

LG LRFDS2503 Series Manual de usuario

LG LTCS24223 series Manual de usuario

LG LFX25991ST Manual de usuario

LG LMXS28596S Manual de usuario

Manuales populares de Refrigerador de otras marcas

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manual de usuario

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manual de usuario

Sharp

Sharp SJ-BA31IEXW2-EU Manual de usuario

CORBERO

CORBERO CC2300MCW Manual de usuario

KitchenAid

KitchenAid 2205264 Manual de usuario

Stengel

Stengel KU 1101 A++ Manual de usuario

NEFF

NEFF KI181 Series Manual de usuario

Hoshizaki

Hoshizaki Reach-In Manual de usuario

Amana

Amana ASD2524VES00 Manual de usuario

BOMANN

BOMANN KGC 213 Manual de usuario

Danby

Danby DAR044A1SLDD Instrucciones de montaje

Samsung

Samsung RF323TE Manual de usuario

Beko

Beko CSA31022 Manual de usuario

IKEA

IKEA FROSTIG C 185 E Manual de usuario

Electrolux

Electrolux ER 6821 D Manual de usuario

True

True TS-28 Manual de usuario

Frigidaire

Frigidaire FSC23R5DW9 Manual de usuario

Beko

Beko LSP4579W Manual de usuario
