LG Fridge-Freezer Manual de usuario

FRIDGE-FREEZER

User's Guide

Please read this User's Guide carefully before

operating and keep it handy for reference at all times.

FRIGORÍFICO-

CONGELADOR

Manual de usuario

Lea detenidamente este manual de usuario antes de utilizar el

aparato y consérvelo para consultarlo siempre que lo necesite.

FRIGORÍFICO -

CONGELADOR

Guia do Utilizador

Por favor leia este Guia do Utilizador cuidadosamente antes de

começar a utilizar o aparelho e mantenha-o acessível para

qualquer consulta.

Lea detenidamente el contenido de

esta tarjeta de Garantia

KCM

Registration

Important Safety Instruction

Identification of Parts

Temperature Control

Super Freezer

Self Test

Door Alarm

Miracle Zone

Ice Making

Defrosting

Folding Shelf

Storing Food

General Information

Lamp Replacement

To Reverse the Doors

Cleaning

Trouble Shooting

Table of Contents

Introduction

Operation

Suggestion On

Food storage

Care and

Maintenance

Trouble Shooting

*Refer to Installation Insturction for details.

Introduction

• Do not disassemble, repair or alter the appliance.

It may cause fire or abnormal operations, which may

lead to injury.

• Pull the power plug out of the socket before replacing

the interior light in the refrigerator.

Otherwise, there is a risk of electric shock.

• If possible, connect the fridge-freezer to its own

individual electrical outlet to prevent it and other

appliances or household lights from causing an overload.

It will cause electric shock or fire.

The supply plug of the refrigerator-freezer should be

placed in easy accessible position for quick disconnection

in emergency.

If the supply cord is damaged, it must be replaced by the

manufacturer or its service agent or a similarly qualified

person in order to avoid a hazard.

Don't store or use gasoline or other flammable vapors

and liquids in the vicinity of this or any other appliance.

In the event of an electric short circuit, grounding

(earthing) reduces the risk of electric shock by providing

an escape wire for the electric current. In order to prevent

possible electric shock, this appliance must be grounded.

Improper use of the grounding plug can result in an

electric shock. Consult a qualified electrician or service

person if the grounding instructions are not completely

understood, or if you have doubts on whether the

appliance is properly grounded or not.

Important Safety Instruction

Accessibility of

Supply Plug

Supply Cord

Replacement

Danger

Don't store

Grounding

(Earthing)

Risk of child entrapment.

Before you throw away your old refrigerator or freezer:

Take off the doors.

Leave the shelves in place so that children may not easily

climb inside.

Do not modify or

extend the Power

Cord length.

Introduction

The model and serial number are found on the rear of

this unit. This number is unique to this unit and not

available to others. You should record requested

information here and retain this guide as a permanent

record of your purchase. Staple your receipt here.

Date of Purchase :

Dealer Purchased From :

Dealer Address :

Dealer Phone No. :

Model No. :

Serial No. :

Important Safety Instruction

To avoid any risk of personal injury, material

damage or incorrect use of the appliance, be sure to

observe the following safety precautions. (After

reading these owner’s instructions, please keep

them in a safe place for reference). Remember to

hand them over to any subsequent owner.

Registration

Introduction

Indicates that a

danger of death

or serious injury

exists

Indicates that a

risk of personal

injury or

material

damage exists

Warning

Caution

Introduction

ww Warning

• This fridge-freezer must be properly installed and

located in accordance with the Installation Instruction

before it is used.

• Before you install this fridge-freezer reference to

installation manual.

• Never unplug your fridge-freezer by pulling on the

power cord. Always grip plug firmly and pull straight

out from the outlet.

• When moving your appliance away from the wall, be

careful not to roll over or damage the power cord.

• After your fridge-freezer is in operation, do not touch

the cold surfaces in the freezer compartment,

particularly when hands are damp or wet. Skin may

adhere to these extremely cold surfaces.

• Pull out the power plug prior to cleaning the fridge-

freezer.

Never damage, serverely bend, pull out, or twist the

power cord because power cord damage may cause a

fire or electronic shock.

Never place glass products in the freezer because they

may be broken when their inner contents are frozen.

• Do not directly spray water inside or outside the

fridge/freezer.

There is a risk of explosion or fire.

• Do not insert the power plug with wet hands.

You may receive an electric shock.

• Do not install the fridge/freezer in a damp place, where

it could be splashed with water.

Incorrect insulation of the electrical parts may cause an

electric shock or fire.

Important Safety Instruction

Precaution

Introduction

This appliance contains a small amount of isobutane

refrigerant (R600a), natural gas with high

environmental compatibility, but it is also

combustible. When transporting and installing the

appliance, care should be taken to ensure that no

parts of the refrigerating circuit are damaged.

Refrigerant squirting out of the pipes could ignite or

cause an eye injury. If a leak is detected, avoid any

naked flames or potential sources of ignition and air

the room in which the appliance is standing for

several minutes.

In order to avoid the creation of a flammable gas air

mixture if a leak in the refrigerating circuit occurs, the size

of the room in which the appliance may be sited depends

on the amount of refrigerant used. The room must be

1m2in size for every 8g of R600a refrigerant inside the

appliance. The amount of refrigerant in your particular

appliance is shown on the identification plate inside the

appliance.

Never start up an appliance showing any signs of

damage. If in doubt, consult your dealer.

Important Safety Instruction

ww Warning

wwKeep ventilation openings, in the appliance enclosure

or in the built-in structure, clear of obstruction.

wwDo not use mechanical devices or other means to

accelerate the defrosting process, other than those

recommended by the manufacturer.

wwDo not damage the refrigerant circuit.

wwDo not use electrical appliances inside the food

storage compartments of the appliance, unless they

are of the type recommended by the manufacturer.

wwThe refrigerant and insulation blowing gas used in the

appliance require special disposal procedures. When

disposal, please consult with a service agent or

similarly qualified person.

Introduction

• If the wall socket is loose, do not insert the power

plug.

It may cause electric shock or fire.

• Never unplug your refrigerator by pulling on the

power cord. Always grip plug firmly and pull it

straight out from the outlet.

You may disconnect a wire and cause a short circuit.

• Do not use a wet or damp cloth when cleaning the

plug. Remove any foreign matter from the power

plug pins.

Otherwise, there is a risk of fire.

• Do not put your hands into the bottom area of the

appliance.

Any Sharp edges may cause personal injury..

• After unplugging the appliance, wait for at least

five minutes before plugging it again to the wall

socket.

Abnormal operation of the freezer may cause material

damage.

• If the appliance is not to be used for a long time,

pull out the power plug.

Any deterioration in the insulation may cause fire.

• Do not let children touch or play with the control

panel on the front of the appliance.

• The refrigerant used in fridge/freezer and the

gases in the insulation material require special

disposal procedures. Ensure that none of the pipes

on the back of the appliances are damaged prior

to disposal.

Important Safety Instruction

ww Caution

Introduction

Identification of Parts

Dairy Corner

Door Basket

Egg Tray

Bottle Guide

Removable

Glass Shelf

Lamp

Folding Shelf

Snack Bin

Multi-Air Flow Duct

Vegetable Drawer

Used to keep fruits

and vegetables crisp

Miracle Zone

Ice Tray

Ice Bank

Freezer

Compartment

Leveling Screw

Door Basket

2 Bottle

Door Basket

Operation

SUPER FRZ.

°C°C

FRZ. TEMP REF. TEMP MIRACLE POWER

°C

Display Panel

Power

Temperature Adjustment Button

for Miracle Zone Compartment

Temperature Adjustment Button

for Freezer Compartment

Temperature Adjustment Button

for Refrigerator Compartment

Super Freezer

Your fridge-freezer has controls that lets you regulate the

temperature in the fridge and freezer compartments.

Display Panel For

Temperature Control

Adjusting the

temperatures and

functions

Operation

Note

Power

• If you push button more than 3 seconds

you can switch on or off the Refrigerator.

• The initial Temperature of the Freezer and Refrigerator

Compartment is -18°C and 2°C respectively.

You can now adjust the temperature of the

compartments as you want.

How to adjust the

temperature in the

refrigerator and

freezer

compartment

POWER

°C°C

FRZ. TEMP REF. TEMP

• When you press the

temperature control button,

the temperature of the

Freezer or Refrigerator part is

change by 1 degree.

The actual inner temperature varies depending on the

food status, as the indicated setting temperature is a

target temperature, not actual temperature within

refrigerator.

Refrigeration function is weak in the initial time. Please

adjust temperature as above after using refrigerator for

minimum 2~3 days.

Otros manuales para Fridge-Freezer

Tabla de contenidos

Otros manuales de Refrigerador de LG

LG LSC 27960ST Manual de usuario

LG LMXS30776S Manual de usuario

LG GF-B590BLE Manual de usuario

LG Studio LSFS213ST Manual de usuario

LG LRFWS2906 Series Manual de usuario

LG GF-V500MBLC Manual de usuario

LG GC-F419BLQ Manual de usuario

LG GM-B258R4S Manual de usuario

LG LFXC24796S Manual de usuario

LG LFC25770ST - 25.0 cu. ft. Refrigerator Manual de usuario

LG GWB227WLQV Manual de usuario

LG LFX25950SB - 24.7 Cu.Ft. Refrigerator Manual de usuario

LG LFX25973ST Manual de usuario

LG GN-B722HLCL Manual de usuario

LG LTC19340SB Manual de usuario

LG GCFB507PQAM Manual de usuario

LG GC-051SA Manual de usuario

LG LRBP1031NI Manual de usuario

LG LMX21981ST Series Manual de usuario

LG G 4 Series Manual de usuario

LG GBB548BLCZH Manual de usuario

LG LFX31935ST Guía del usuario

LG GL-B181RPRW Manual de usuario

LG LMXC23746 Series Manual de usuario

Manuales populares de Refrigerador de otras marcas

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manual de usuario

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manual de usuario

Sharp

Sharp SJ-BA31IEXW2-EU Manual de usuario

CORBERO

CORBERO CC2300MCW Manual de usuario

KitchenAid

KitchenAid 2205264 Manual de usuario

Stengel

Stengel KU 1101 A++ Manual de usuario

NEFF

NEFF KI181 Series Manual de usuario

Hoshizaki

Hoshizaki Reach-In Manual de usuario

Amana

Amana ASD2524VES00 Manual de usuario

BOMANN

BOMANN KGC 213 Manual de usuario

Danby

Danby DAR044A1SLDD Instrucciones de montaje

Samsung

Samsung RF323TE Manual de usuario

Beko

Beko CSA31022 Manual de usuario

IKEA

IKEA FROSTIG C 185 E Manual de usuario

Electrolux

Electrolux ER 6821 D Manual de usuario

True

True TS-28 Manual de usuario

Frigidaire

Frigidaire FSC23R5DW9 Manual de usuario

Beko

Beko LSP4579W Manual de usuario
