FRIDGE-FREEZER
User's Guide
Please read this User's Guide carefully before
operating and keep it handy for reference at all times.
P/No. MFL37986133 Printed in Korea
LG Twin Tower, 20, Yoido-Dong, Youngdungpo-Gu, Seoul, 150-721, Korea.
http://www.lge.co.kr
Electrical Connections
2
The wires in this mains lead are coloured in accordance
with the following code:
GREEN AND YELLOW:EARTH
BLUE:NEUTRAL
BROWN:LIVE
This appliance must be earthed
As the colours of the wires in the mains lead of this
apparatus may not correspond with the coloured
markings identifying the terminals in your plug, proceed
as follows:
The wire which is coloured Green and Yellow must be
connected to the terminal in the plug which is marked
with the letter E or by the earth symbol(b) or coloured
Green or Green and Yellow.
The wire which is coloured Blue must be connected to
the terminal which is marked with the letter N or
coloured Black.
The wire which is coloured Brown must be connected to
the terminal which is marked with the letter L or coloured
Red.
If a 13 amp(BS 1363) plug is used, fit a 13 amp BS 1362
fuse.
(In the UK Only)
Important
Fuse
Cord
grip
Green and Yellow(Earth)
Brown(Live)
Blue(Neutral)
3
Registration
Important Safety Instruction
Identification of Parts
Installation
Starting
Temperature Control
Miracle Zone
Express Frz.
Vacation
Self Test
Lock
On/Off
Vita Light
Door Alarm
Ice Making
Ice Homebar
Defrosting
Water Dispenser
Wine Rack
Storing Food
General Information
Lamp Replacement
To Reverse the Doors
Cleaning
Trouble Shooting
Table of Contents
Introduction
Installation
Operation
Suggestion On
Food storage
Care and
Maintenance
Trouble Shooting
4
4
16
17
17
18
20
21
22
23
23
23
23
24
24
25
25
26
28
29
31
32
32
33
35
Introduction
4
Registration
Introduction
The model and serial number are found on the rear of
this unit. This number is unique to this unit and not
available to others. You should record requested
information here and retain this guide as a permanent
record of your purchase. Staple your receipt here.
Date of Purchase :
Dealer Purchased From :
Dealer Address :
Dealer Phone No. :
Model No. :
Serial No. :
Important Safety Instruction
BASIC SAFETY PRECAUTIONS
This guide contains many important safety messages.
Always read and obey all safety messages.
ww
This is the safety alert symbol. It alerts you to safety
messages that inform you of hazards that can kill or hurt
you or others or cause damage to the product. All safety
messages will be preceded by the safety alert symbol and
the hazard signal word DANGER, WARNING, or
CAUTION. These words mean:
wwDANGER
You will be killed or seriously injured if
you don’t follow instructions.
ww
WARNING
You can be killed or seriously injured if
you don’t follow instructions.
wwCAUTION
Indicates an imminently hazardous
situation which, if not avoided, may
result in minor or moderate injury, or
product damage only.
All safety messages will identify the hazard, tell you how
to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
Introduction
5
ww
WARNING
To reduce the risk of fire, electric shock, or injury to
persons when using your product, basic safety
precautions should be followed, including the
following. Read all instructions before using this
appliance.
1. When connecting the power
The dedicated outlet should be used.
• Using several devices at one outlet
may cause fire.
• The electric leakage breaker may
damage food and the dispenser may
be leaked.
Do not allow the power plug to face upward or to
be squeezed at the back of the fridge-freezer.
Water may be flown into or the plug
may be damaged, which causes fire or
electric shock.
Do not allow the power cord bent or pressed by the
heavy object to be damaged.
It may damage the power cord to cause
fire or electric shock.
Do not extend or modify the length of the power
plug.
It causes electric shock or fire by the
electric damage of the power cord or
others.
Unplug the power plug when cleaning, handling or
replacing the interior lamp of the fridge-freezer.
• It may cause electric shock or injury.
• When replacing the interior lamp of
the fridge-freezer, make sure that the
rubber ring for preventing the electric
spark within the socket is not taken
off.
Important Safety Instruction
Introduction
Important Safety Instruction
Do not pull out the cord or touch the power plug
with wet hands.
It may cause electric shock or injury.
Remove water or dust from the power plug and
insert it with the ends of the pins securely
connected.
Dust, water or unstable connection may
fire or electric shock.
Make sure of grounding.
The incorrect grounding may cause
breakdown and electric shock.
When the power cord or the power plug is
damaged or the holes of the outlet are loosed, do
not use them.
It may cause electric shock or short circuit
to make fire.
2. When using the fridge-freezer
Do not place the heavy object or the dangerous
object (container with liquid) on the fridge-freezer.
It may be dropped to cause injury, fire or
electric shock when opening or closing
the door.
Do not cling to the door or the shelves of the door
or the home bar of the freezer or the cool chamber.
It may make the fridge-freezer fallen
down or damage the hands. Especially,
do not allow the children to do the
above.
6
Introduction
7
Do not install the fridge-freezer in the wet place or
the place which water or rain splashes.
Deterioration of insulation of electric
parts may cause electric leakage.
Do not use or store inflammable materials ether,
benzene, alcohol, medicine, LP gas, spray or
cosmetics near or in the fridge-freezer.
It may cause explosion or fire.
Do not place the lit candle within the fridge-freezer
to deodorize.
It may cause explosion or fire.
Do not store the medicine or the academic materials
at the fridge-freezer.
When the material with the strict
temperature control is stored, it may be
deteriorated or it may make an
unexpected reaction to cause any risk.
Do not use the combustible spray near the fridge-
freezer.
It may cause fire.
Important Safety Instruction
Introduction
8
Avoid the heating devices.
It may cause fire.
Do not place flower vase, cup, cosmetics, medicine
or any container with water on the fridge-freezer.
It may cause fire, electric shock or
injury by dropping down.
Use the submerged fridge-freezer after checking it.
It may cause electric shock or fire.
When gas is leaked, do not touch the fridge-freezer
or the outlet and ventilate the room immediately.
• The explosion by spark may cause
fire or burn.
• Because this fridge-freezer uses
natural gas (isobutene, R600a) as
the environment-friendly
refrigerant, even a small amount
(80~90g) is combustible. When the gas is leaked by the
severe damage during delivering, installing or using the
fridge-freezer, any spark may cause fire or burn.
Do not spray water at the outside or the inside of
the fridge-freezer or do not clean it with benzene or
thinner.
Deterioration of insulation of electric
parts may cause electric shock or fire.
Important Safety Instruction
Introduction
9
When any strange smell or smoke is detected from
the fridge-freezer, disconnect the power plug
immediately and contact to the service center.
It may cause fire.
Do not allow any person except the qualified
engineer to disassemble, repair or alter the fridge-
freezer.
It may cause injury, electric shock or
fire.
Do not use the fridge-freezer for non-domestic
purpose (storing medicine or testing material, using
at the ship, etc.).
It may cause an unexpected risk such
as fire, electric shock, deterioration of
stored material or chemical reaction.
When disposing the fridge-freezer, remove the
packing materials from the door.
It may cause to lock out the child.
Install the fridge-freezer on the solid and level floor.
Installing it on the unstable place may
cause death by falling down the
fridge-freezer when opening or
closing the door.
Important Safety Instruction
Introduction
Do not insert the hands or the metal stick into the
exit of cool air, the cover, the bottom of the fridge-
freezer, the heatproof grill (exhaust hole) at the
backside.
It may cause electric shock or injury.
When you want to dispose the fridge-freezer,
contact to the down-block office.
When you want to dispose the large
living waste such as
electric home appliance and furniture,
you’d better contact the local down-
block office.
ww
CAUTION
Violating this direction may cause injury or damage
house or furniture. Always be careful, please.
Do not touch food or containers at
the freezer with wet hands.
It may cause frostbite.
Wait for 5 minutes or longer when
reconnecting the plug.
It may cause the operation of the
freezer to fail.
Do not put bottle in the freezer.
It may freeze the contents to break the
bottle to cause injury.
Pull out the power plug not by
grasping the cord but the plug of its
end.
It may cause electric shock or short
circuit to fire.
Important Safety Instruction
10
