LG M2394a Manual de usuario

Make sure to read the Safety Precautions before

using the product.

Keep the User's Guide(CD) in an accessib e p ace

for furture reference.

See the abe attached on the product and give the

information to your dea er when you ask for service.

OWNER’S MANUAL

MM22339944AA

MM22779944AA

Downloaded from ManualMonitor.com Manuals

PREPARATION

FRONT PANEL CONTROLS

■

This is a simp ified representation of the front pane . The image shown may be somewhat different from your

set.

INPUT MENU VOL PROK

PROGRAMME

Buttons

VOLUME

Buttons

Button

INPUT

Button

Power

Button

Headp one

Jack

Downloaded from ManualMonitor.com Manuals

PREPARATION

BACK PANEL INFORMATION

■

This is a simp ified representation of the back pane . The image shown may be somewhat different from your

set.

AC IN

AUDIO IN

(RGB/DVI)

VIDEO

COMPONENT

AV IN

VIDEO AUDIO

(MONO)

S-VIDEO

AUDIO

DVI-D IN (PC)

RS-232C IN

(CONTROL & SERVICE)

HDMI

AC IN

ANTENNA/

CABLE IN

RGB IN (PC)

910

4 6 73 5

PPoowweerr CCoorrdd SSoocckkeett

T is set operates on AC power. T e voltage is indi-

cated on t e Specifications page. Never attempt to

operate t e set on DC power.

HHDDMMII IInnppuutt

Connect a HDMI signal to HDMI .

Or DVI (VIDEO) signal to HDMI wit DVI to HDMI

cable.

RRGGBB//DDVVII AAuuddiioo IInnppuutt

Connect t e audio from a PC.

RRGGBB IInnppuutt ((PPCC))

Connect t e output from a PC.

CCoommppoonneenntt IInnppuutt

Connect a component video/audio device to t ese

jacks.

AAVV((AAuuddiioo//VViiddeeoo)) IInnppuutt

Connect audio/video output from an external device

to t ese jacks.

AAnntteennnnaa IInnppuutt

Connect over-t e-air signals to t is jack.

DDVVII--DD IInnppuutt((PPCC))

Connect t e output from a PC.

RRSS--223322CC IINN ((CCOONNTTRROOLL && SSEERRVVIICCEE)) PPOORRTT

Connect to t e RS-232C port on a PC.

SS--VViiddeeoo IInnppuutt

Connect S-Video out from an S-VIDEO device.

Downloaded from ManualMonitor.com Manuals

PREPARATION

STAND INSTALLATION

■

The image shown may be somewhat different from your set.

Carefu y p ace the product screen side down on a

cushioned surface that wi protect product and

screen from damage.

Insert the ssttaanndd bbaasseeinto the product

Attach the monitor to the Stand Base by turning

the screw to the right.

* Turn the screw by using the screw hand e

Screw

Downloaded from ManualMonitor.com Manuals

PREPARATION

DETACHING STAND

P ace the set screen side down on a cushion or

soft c oth.

Detach the monitor to the Stand Base by turn-

ing the screw to the eft.

Turn the screw by using the screw hand e 4

Pu the stand base.

■

The image shown may be somewhat different from your set.

Downloaded from ManualMonitor.com Manuals

PREPARATION

DESKTOP PEDESTAL INSTALLATION

For proper ventilation, allow a clearance of 4 inc es on eac side and from t e wall.

4 inches

WALL MOUNT: HORIZONTAL INSTALLATION

For proper ventilation, allow a clearance of 4 inc es on eac side and from t e wall. Detailed installation

instructions are available from your dealer, see t e optional Tilt Wall Mounting Bracket Installation and

Setup Guide.

4 inches

4 inches 4 inches

4 inches

Downloaded from ManualMonitor.com Manuals

PREPARATION

POSITIONING YOUR DISPLAY

■

The image shown may be somewhat different from your set.

Adjust t e position of t e panel in various ways for maximum comfort.

•• TTiilltt rraannggee

LOCATION

Position your set so t at no brig t lig t or sunlig t falls directly onto t e screen. Care s ould be taken not to

expose t e set to any unnecessary vibration, moisture, dust or eat. Also, ensure t at t e set is placed in a posi-

tion to allow a free flow of air. Do not cover t e ventilation openings on t e back cover.

If you intend to mount t e set to a wall, attac Wall mounting interface (optional parts) to t e back of t e set.

W en you install t e set using t e wall mounting interface (optional parts), attac it carefully so it will not drop.

- Be sure to use screws and a wall mount t at meet VESA standards.

- Using screws longer t an t ose recommended mig t damage t e product.

- Using screws t at do not meet VESA standards mig t eit er damage t e product or result in it coming away from

t e wall. We will not be eld responsible for any damage resulting from failure to follow t ese instructions.

< Screw Mounting Interface Dimension >

M2394A : 75mm x 75mm ole spacing

M2794A : 100mm x 100mm ole spacing

WWaarrnniinngg::

W en adjusting t e angle of t e screen,do not put your

finger(s)in between t e ead of t e monitor and t e stand

body.You can urt your finger(s).

-6

~ -2

~ 18

-5

~ -2

~ 13

Downloaded from ManualMonitor.com Manuals

PREPARATION

KENSINGTON SECURITY SYSTEM

- T e product is equipped wit a Kensington Security System connector on t e back panel. Connect t e

Kensington Security System cable as s own below.

- For detailed installation and use of t e Kensington Security System, refer to t e user’s guide provided wit

t e Kensington Security System.

For furt er information, contact ttttpp::////wwwwww..kkeennssiinnggttoonn..ccoomm, t e internet omepage of t e

Kensington company. Kensington sells security systems for expensive electronic equipment suc as note-

book PCs and LCD projectors.

NOTE

- T e Kensington Security System is an optional accessory.

NOTES

a. If t e product feels cold to t e touc , t ere may be a small “flicker” w en it is turned on.

T is is normal, t ere is not ing wrong wit product.

b. Some minute dot defects may be visible on t e screen, appearing as tiny red, green, or blue spots.

However, t ey ave no adverse effect on t e monitor's performance.

c. Avoid touc ing t e LCD screen or olding your finger(s) against it for long periods of time.

Doing so may produce some temporary distortion effects on t e screen.

Downloaded from ManualMonitor.com Manuals

EXTERNAL EQUIPMENT SETUP

■For optimum picture qua ity, adjust antenna direction.

■An antenna cab e and converter are not supp ied.

■To prevent equipment damage, never p ug in any power cords unti you have finished connecting a equipment.

Multi-famil Dwellings/Apartments

(Connect to wall antenna socket)

Single-famil Dwellings /Houses

(Connect to wall jack for outdoor antenna)

Outdoor

Antenna

(VHF, UHF)

Wall

Antenna

Socket

RF Coaxial Wire (75 ohm)

ANTENNA CONNECTION

Antenna

UHF

VHF

■In poor signa areas, to get better picture qua ity, insta a signa amp ifier to the antenna as shown above.

■If signa needs to be sp it for two sets, use an antenna signa sp itter for connection.

AV 1

AC IN

ANTENNA/

CABLE IN

AV 1

AC IN

ANTENNA/

CABLE IN

AV 1

Signal

Amplifier

Downloaded from ManualMonitor.com Manuals

EXTERNAL EQUIPMENT SETUP

Connect the SET-TOP outputs to the CCOOMMPPOONNEENNTT IINN

VVIIDDEEOOsockets (Y PBPR) on the set.

Connect the audio cab e from the SET-TOP to CCOOMMPPOO--

NNEENNTT IINNAAUUDDIIOOsockets of the set.

Press the IINNPPUUTTbutton to se ect CCoommppoonneenntt..

HD RECEIVER SETUP

■To prevent t e equipment damage, never plug in any power cords until you ave finis ed connecting all equipment.

■

T e image s own may be somew at different from your set.

When connecting with a component cable

Signa

480i/576i

480p/576p

720p/1080i

1080p

Component

Yes

VIDEO

COMPONENT

AUDIO

Downloaded from ManualMonitor.com Manuals
