LG Flatron M2094D Manual de usuario

Please read this manual carefully before operating

your set.

Retain it for future reference.

Record model number and serial number of the set.

See the label attached on the back cover and quote

this information to your dealer when you require

service.

OWNER’S MANUAL

MM119999DD

MM220099DD

MM222299DD

Trade Mark of the DVB Digital Video

Broadcasting Project (1991 to 1996)

IIDD NNuummbbeerr((ss))::5573 : M199 D

557 : M209 D

5575 : M229 D

PREPARATION

FRONT PANEL CONTROLS

■

This is a simplified representation of the front panel. The image shown may be somewhat different from your

set.

INPUT MENU VOL PROK

PROGRAMME

Buttons

VOLUME

Buttons

Button

INPUT

Button

Power

Button

Headp one

Button

PREPARATION

BACK PANEL INFORMATION

PCMCIA (Personal Computer Memory Card

International Association) Card Slot

(T is feature is not available in all countries.)

Power Cord Socket

T is set operates on AC power. T e voltage is indicat-

ed on t e Specifications page. Never attempt to

operate t e set on DC power.

HDMI Input

Connect a HDMI signal to HDMI IN.

Or DVI (VIDEO) signal to HDMI IN wit DVI to HDMI

cable.

RGB/DVI Audio Input

Connect t e audio from a PC.

Optical Digital Audio Out

Connect digital audio from various types of eguip-

ment

RGB INPUT (PC)

Connect t e output from a PC.

SERVICE ONLY PORT

DVI-D Input

Connect t e output from a PC.

RS-232C IN (CONTROL & SERVICE) PORT

Connect to t e RS-232C port on a PC.

Component Input

Connect a component video/audio device to t ese

jacks.

Euro Scart Socket (AV1/AV2)

Connect scart socket input or output from an exter-

nal device to t ese jacks.

Antenna Input

Connect over-t e-air signals to t is jack.

■

This is a simplified representation of the back panel. The image shown may be somewhat different from your

set.

AV 1 AV 2

AC IN

AUDIO IN

(RGB/DVI) OPTICAL

DIGITAL

AUDIO OUT

VIDEO

COMPONENT

AUDIO

RS-232C IN

(CONTROL & SERVICE)

SERVICE

ONLY

RGB IN (PC)

DVI-D

HDMI

AV 1

V 1

AV 2

V 2

ANTENNA IN

AC IN

910

87 1211

64 5

PREPARATION

STAND INSTALLATION

■

The image shown may be somewhat different from your set.

Carefully place the product screen side down on a

cushioned surface that will protect product and

screen from damage.

Insert the ssttaanndd bbaasseeinto the product

Attach the monitor to the Stand Base by turning

the screw to the right.

* Turn the screw by using the screw handle

Screw

PREPARATION

DETACHING STAND

Place the set screen side down on a cushion or

soft cloth.

Detach the monitor to the Stand Base by turn-

ing the screw to the left.

Turn the screw by using the screw handle 4

Pull the stand base.

■

The image shown may be somewhat different from your set.

PREPARATION

DESKTOP PEDESTAL INSTALLATION

For proper ventilation, allow a clearance of 4 inc es on eac side and from t e wall.

4 inches

PREPARATION

POSITIONING YOUR DISPLAY

■

The image shown may be somewhat different from your set.

Adjust t e position of t e panel in various ways for maximum comfort.

•• TTiilltt rraannggee

LOCATION

Position your set so t at no brig t lig t or sunlig t falls directly onto t e screen. Care s ould be taken

not to expose t e set to any unnecessary vibration, moisture, dust or eat. Also, ensure t at t e set is

placed in a position to allow a free flow of air. Do not cover t e ventilation openings on t e back cover.

If you intend to mount t e set to a wall, attac VESA standard mounting interface (optional parts) to t e

back of t e set.

W en you install t e set using t e wall mounting bracket (optional parts), attac it carefully so it will not

drop.

-5

~ -2

~ 18

WWaarrnniinngg::

W en adjusting t e angle of t e screen,do not put your

finger(s)in between t e ead of t e monitor and t e stand

body.You can urt your finger(s).

PREPARATION

KENSINGTON SECURITY SYSTEM

- T e product is equipped wit a Kensington Security System connector on t e back panel. Connect t e

Kensington Security System cable as s own below.

- For detailed installation and use of t e Kensington Security System, refer to t e user’s guide provided wit

t e Kensington Security System.

For furt er information, contact ttttpp::////wwwwww..kkeennssiinnggttoonn..ccoomm, t e internet omepage of t e

Kensington company. Kensington sells security systems for expensive electronic equipment suc as note-

book PCs and LCD projectors.

NOTE

- T e Kensington Security System is an optional accessory.

NOTES

a. If t e product feels cold to t e touc , t ere may be a small “flicker” w en it is turned on.

T is is normal, t ere is not ing wrong wit product.

b. Some minute dot defects may be visible on t e screen, appearing as tiny red, green, or blue spots.

However, t ey ave no adverse effect on t e monitor's performance.

c. Avoid touc ing t e LCD screen or olding your finger(s) against it for long periods of time.

Doing so may produce some temporary distortion effects on t e screen.

PREPARATION

AV 3

L/MONO

AUDIO

VIDEO

S-VIDEO

AUDIO

VIDEO

AV 1 AV 2

ANTENNA

EJECT

HDMI/DVI IN 1 HDMI IN 2

PCMCIA

CARD SLOT

RS-232C IN

AV 3

L/MONO

AUDIO

VIDEO

S-VIDEO

AUDIO

VIDEO

AV 1 AV 2

ANTENNA

EJECT

HDMI/DVI IN 1 HDMI IN 2

PCMCIA

CARD SLOT

RS-232C IN

■For optimum picture quality, adjust antenna direction.

■An antenna cable and converter are not supplied.

■To prevent equipment damage, never plug in any power cords until you have finished connecting all equipment.

Multi-famil Dwellings/Apartments

(Connect to wall antenna socket)

Single-famil Dwellings /Houses

(Connect to wall jack for outdoor antenna)

Outdoor

Antenna

(VHF, UHF)

Wall

Antenna

Socket

RF Coaxial Wire (75 ohm)

ANTENNA CONNECTION

Antenna

UHF

Signal

Amplifier

VHF

■In poor signal areas, to get better picture quality, install a signal amplifier to the antenna as shown above.

■If signal needs to be split for two TVs, use an antenna signal splitter for connection.

EXTERNAL EQUIPMENT SETUP

Connect the SET-TOP outputs to the CCOOMMPPOONNEENNTT IINN

VVIIDDEEOOsockets (YP

BPR) on the set.

Connect the audio cable from the SET-TOP to CCOOMMPPOO--

NNEENNTT IINNAAUUDDIIOOsockets of the set.

Press the IINNPPUUTTbutton to select Component.

HD RECEIVER SETUP

■To prevent t e equipment damage, never plug in any power cords until you ave finis ed connecting all equipment.

■

T e image s own may be somew at different from your set.

When connecting with a component cable

Signal

80i/576i

80p/576p

720p/1080i

1080p

Component

Yes

HDMI

Yes

VIDEO

COMPONENT

AUDIO
