Easy Setup Guide

MONITOR SIGNAGE

47WV30MS

47WV30BR

47WV30BS

47WV30-BAAM

47WV30-BAAL

Please read this manual carefully before operating your set and retain

it for future reference.

MONITOR SIGNAGE MODELS

ENG

ENGLISH

P/NO : MFL67559901(1207-REV01)

Printed in Korea

ENG

ENGLISH

PRECAUTION

Precaution in movement

Adhere to the warning signs printed on the Box.

Do not Clamp.

Do not drop from clamping.

2 Persons needed for transport

Load with care.

Do not transport horizontally.

Do not drop from stacking.

4 Persons needed for transport

Do not drop from carrying.

Don’t tumble the Set box sideward down.

Don’t lie on or lean on the Set box.

PRECAUTION

ENG

ENGLISH

PRECAUTION

Precaution in Handling

Move the Set as a team of 2 persons. When you move the bare Set, please use one hand on grabbing the

handle and the other support under the Set.

 This way up/ Fragile/ Keep away from rain/ Stacking limit 4.

CAUTION

ENG

ENGLISH

PRECAUTION

Causes & Phenomena of the Line Defect

LOG (LINE ON GLASS) DEFECT

The line defect would occur on your Set if you strike on the edge of the Set.

Shock on Module Top Side  Top COF Crack 

Vertical Line Defect

Shock on Module Left/Top Corner Left/Top LOG Crack Horizontal Line Defect

Shock on Module Left Side Left COF Crack 

Horizontal Line Defect

COF Cable

Source PCB

COF Cable

Source PCB

ENG

ENGLISH

PRECAUTION

Panel

Panneau

Panello

Panel

10 cm

10 cm10 cm

20 cm

 Be careful not to collide the sets with

the floor or with each other. Install in

the space with enough airflow.

CAUTION

ENG

ENGLISH

ASSEMBLING AND PREPARING

Unpacking

Check your product box for the following items. If there are any missing accessories, contact the local

dealer where you purchased your product. The illustrations in this manual may differ from the actual product

and accessories.

 Do not use any pirated items to ensure the safety and product life span.

 Any damages or injuries by using pirated items are not covered by the warranty.

CAUTION

INPUT

ENERGY

SAVING

MARK

ARC

OFF



. , !



ABC



DEF



GHI



JKL



MNO



PQRS



TUV



1/a/A



- * #

WXYZ

CLEAR

MONITOR

PSM

AUTO

MUTE

BRIGHT

NESS

POWER

S.MENU

BACK TILE

ON OFF

EXIT

Remote control and Batteries

Power Cord DVI Cable

IR Receiver Guide bracket

M4 x 10L

Screw (4ea)

Power cable holder U-shaped fixture

Screw (4ea)

Ring Core

Cable holder

(2ea)

RGB Cable

RS-232C Cable

 The accessories supplied with your product may vary depending on the model.

 Product specifications or contents in this manual may be changed without prior notice due to upgrade

of product functions.

 How to Use a Ring Core

A ring core reduces electromagnetic waves emitted from the IR receiver.

Loop the cable through the core once, before using it as illustrated.

NOTE

Ring Core

CD (Owner's Manual, SuperSign

Program, SuperSign Manual) /

Card

ENG

ENGLISH

ASSEMBLING AND PREPARING

Dimensions (Width x Height x Depth) / Weight

To view the User’s guide

“Insert CD ROM” in Computer

CD-ROM will open automatically.(for Window only)

My computer Digital_LG(CD-ROM) Index.htm Open

My computer Digital_LG(CD-ROM) Manual folder User's Guide Open

1047 mm x 592 mm x 91.1 mm / 29 kg

ENG

ENGLISH

ASSEMBLING AND PREPARING

Installing the Product

1 2

Cut Packing Strap of the Box.

Remove the Upper Box.

Cut Tape on the Box.

Open the Box and remove the top packing.

Open the Poly Bag. Undress the Poly Bag.

5 6
