LG 32GK850G Manual de usuario

* Disclaimer : LG LED Monitor applies LCD screen with LED backlights.

This product is a computer monitor and not for television purpose.

Please read this manual carefully before operating your set and retain it

for future reference.

32GK850G

OWNER’S MANUAL

LG Gaming

Computer Monitor

(LED COMPUTER MONITOR*)

www.lg.com

ENGLISH

TABLE OF CONTENTS

LICENSE.......................................3

ASSEMBLING AND PREPARING 4

- Product Composition..................................................4

- Supported Drivers and Software .........................5

- Product and Button Description...........................6

How to Use the Joystick Button

How to Use the Lighting Button

Input Connector

- Moving and Lifting the Monitor............................8

- Installing the Monitor ............................................10

Assembling the Stand

Installing on a Table

Adjusting the Stand Height

Adjusting the Angle

Pivot Feature

Tidying up Cables

Using the Kensington Lock

Detaching the Stand Body

Installing the Wall Mount Plate

Installing on the Wall

USING THE MONITOR.............. 21

- Connecting to a PC...................................................21

HDMI Connection

DisplayPort Connection

- Connecting Peripherals...........................................23

USB Cable connection

Connecting Headphones

- Service only port........................................................24

USER SETTINGS ....................... 25

- Activating the Main Menu....................................25

Main Menu Features

- User Settings ...............................................................27

Menu Settings

Game Mode

Game Adjust

Picture Adjust

Input

General

TROUBLESHOOTING................ 36

PRODUCT SPECIFICATION ...... 39

- Factory Support Mode............................................41

- G-SYNC Monitor........................................................42

ENGLISH

LICENSE

Each model has different licenses. Visit www.lg.com for more information on the license.

The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of

HDMI Licensing Administrator, Inc. in the United States and other countries.

ENGLISH

ASSEMBLING AND PREPARING

Product Composition

Please check whether all the components are included in the box before using the product. If there are any missing components, contact the retailer where you purchased the

product. Note that the product and related components may look different from those shown here.

CD (Owner’s Manual / Software /

Guides) / Cards

Power cord AC/DC Adapter USB 3.0 Cable DisplayPort Cable

HDMI Cable Stand Body Stand Base Cable Holder Mouse Holder

ENGLISH

CAUTION

•Always use genuine LG components to ensure safety and product performance.

•The product warranty will not cover damage or injury caused by the use of

unauthorized components.

•It is recommend that use the supplied components.

•If you use generic cables not certified by LG, the screen may not display or there

may be image noises.

NOTE

•The components may look different from those illustrated here.

•Without prior notice, all product information and specifications contained in this

manual are subject to change to improve the performance of the product.

•To purchase optional accessories, visit an electronics store or an online shopping

site, or contact the retailer from which you purchased the product.

•The power cord provided may differ depending upon the region.

Supported Drivers and Software

Check the drivers and software supported by your product and refer to the manuals

on the CD enclosed in the product package.

Drivers and Software Installation Priority 32GK850G

Monitor Driver Recommended O

ASM Driver Required X

OnScreen Control Recommended O

Dual Controller Optional X

True Color Pro Optional X

•Required and Recommended: You can download and install the latest version from

the enclosed CD or from the LGE website (www.lg.com).

•Optional: You can download and install the latest version from the LGE website

(www.lg.com).

ENGLISH

Product and Button Description

Joystick Button / Power LED

•On: Power on

•Off: Power off

Lighting Button

Lighting

ENGLISH

How to Use the Joystick Button

You can easily control the functions of the monitor by pressing the joystick button or

moving it left/right/up/down with your finger.

Basic Functions

Power on Press the joystick button once with

your finger to turn on the monitor.

Power off

Press and hold the joystick button once

more than 5 seconds with your finger

to turn off the monitor.

/ Volume

control

You can control the volume by moving

the joystick button left/right.

Controls

screen

brightness

You can control the screen’s brightness

by moving the joystick button up/down.

How to Use the Lighting Button

You can easily control the functions of the monitor by pressing the lighting button or

moving it left/right with your finger.

Basic Functions

When Lighting is Off When Lighting is On

Press the lighting button

once with your finger to

turn on the lighting on

the back of the monitor.

Pressing the lighting

button enables you to

change the lights on the

back of the monitor to

eight different colors.

Press and hold the

lighting button once with

your finger to turn on the

lighting on the back of

the monitor.

Press and hold the

lighting button once with

your finger to turn off

the lighting on the back

of the monitor.

Not functional You can control the

lighting brightness by

moving the lighting

button left/right.

NOTE

•The joystick and lighting button are located at the bottom of the monitor.

•The Lighting function for the back of the monitor is available even when the monitor

is in power saving mode or when its screen is off.

ENGLISH

Moving and Lifting the Monitor

When moving or lifting the monitor, follow these instructions to prevent the monitor

from being scratched or damaged and to ensure safe transportation, regardless of

its shape or size.

•Place the monitor in the original box or packing material before attempting to

move it.

•Before moving or lifting the monitor, disconnect the power cord and all other

cables.

•Hold the bottom and side of the monitor frame firmly. Do not hold the panel itself.

Input Connector

SERVICE ONLY

1 2

ENGLISH

•When holding the monitor, the screen should face away from you to prevent it

from being scratched.

•When transporting the monitor, do not expose the monitor to shock or excessive

vibration.

•When moving the monitor, keep it upright and never turn the monitor on its side or

tilt it sideways.

CAUTION

•Avoid touching the monitor screen as much as possible.

- This may result in damage to the screen or some of the pixels used to create

images.

•If you use the monitor panel without the stand base, its joystick and lighting

button may cause the monitor to become unstable and fall, resulting in damage to

the monitor or human injury. In addition, this may cause the joystick and lighting

button to malfunction.

ENGLISH

Installing the Monitor

Assembling the Stand

CAUTION

•To protect the screen from scratches, cover the surface with a soft cloth.

Stand Attachment Area

Stand Body

Cable Holder

* Assemble the Cable Holder.

Stand Base
