LG 27MQ70QC Manual de usuario

* LG LED Monitor applies LCD screen with LED backlights.

Please read this manual carefully before operating your set and retain it for future reference.

www.lg.com

Owner’s Manual

LED LCD MONITOR

(LED Monitor*)

27BQ70QC

27MQ70QC

ENGLISH

TABLE OF CONTENTS

LICENSE ............................................................................................. 3

OPEN SOURCE SOFTWARE NOTICE INFORMATION ............................ 4

ASSEMBLING AND PREPARING ......................................................... 4

USING THE MONITOR....................................................................... 13

USER SETTINGS ............................................................................... 16

TROUBLESHOOTING ........................................................................ 21

PRODUCT SPECIFICATION................................................................ 22

ENGLISH

LICENSE

Each model has different licenses. Visit www.lg.com for more information on the license.

The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.

ENGLISH

OPEN SOURCE SOFTWARE NOTICE

INFORMATION

To obtain the source code that is contained in this product, under GPL, LGPL, MPL, and other open source

licenses that have the obligation to disclose source code, and to access all referred license terms, copyright

notices and other relevant documents, please visit https://opensource.lge.com.

LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing

such distribution (such as the cost of media, shipping, and handling) upon email request toopensource@lge.

com.

This offer is valid to anyone in receipt of this information for a period of three yearsafter our last shipment of

this product.

ASSEMBLING AND PREPARING

CAUTION

•Always use genuine LG components to ensure safety and product performance.

•The product warranty will not cover damage or injury caused by the use of unauthorized components.

•It is recommended that use the supplied components.

•Illustrations in this document represent typical procedures, so they may look different from the actual

product.

•Do not apply foreign substances (oils, lubricants, etc.) to the screw parts when assembling the product.

(Doing so may damage the product.)

•Applying excessive force when tightening screws may cause damage to the monitor. Damage caused in this

way will not be covered by the product warranty.

•When lifting or moving the monitor, do not touch the monitor screen. The force applied to the monitor screen

may cause damage to it.

ENGLISH

NOTE

•The components may look different from those illustrated here.

•Without prior notice, all product information and specifications contained in this manual are subject to

change to improve the performance of the product.

•To purchase optional accessories, visit an electronics store or an online shopping site, or contact the retailer

from which you purchased the product.

•The power cord provided may differ depending upon the region.

Supported Software

You can download and install the latest version from the LGE website (www.lg.com).

•Monitor Driver/ OnScreen Control/ Dual Controller

Product and Button Description

Button Description

(Power) Power off state Press the button once to turn on the monitor.

Power on state Press and hold the button once for five seconds or longer

to turn off the monitor.

(Menu) Press the button once to set the screen.

/ Adjusts the volume.

Enters the [Accessibility] menu.

ENGLISH

Moving and Lifting the Monitor

When moving or lifting the monitor, follow these instructions to prevent the monitor from being scratched or

damaged and to ensure safe transportation, regardless of its shape or size.

•Place the monitor in the original box or packing material before attempting to move it.

•Before moving or lifting the monitor, disconnect the power cord and all other cables.

•Hold the bottom and side of the monitor frame firmly. Do not hold the panel itself.

•When holding the monitor, the screen should face away from you to prevent it from being scratched.

•When transporting the monitor, do not expose the monitor to shock or excessive vibration.

•When moving the monitor, keep it upright and never turn the monitor on its side or tilt it sideways.

CAUTION

•Avoid touching the monitor screen as much as possible.

-This may result in damage to the screen or some of the pixels used to create images.

ENGLISH

Installing on a Table

After folding the stand to secure it, lift the monitor and place it on the table in an upright position.

A-Type

CAUTION

•Make sure the table on which the product is installed is stable and solid. A table made of fragile materials

such as glass may be damaged.

•The monitor may tilt on uneven or slanted tables.

•Installation of the stand may leave a mark on the table.

•Avoid falls by verifying that the table is large enough to support the monitor.

•Unplug the power cord before moving or installing the monitor.There is risk of electric shock.

•Make sure to use the power cord that is provided in the product package and connect it to a grounded power

outlet.

•If you need another power cord, please contact your local dealer or the nearest retail store.

ENGLISH

Adjusting the Angle

The angle of the screen can be adjusted forward or backward from -5° to 10° for a comfortable viewing

experience.

WARNING

•Be careful not to touch or press the screen area when adjusting the angle of the monitor.

•Do not use the button on the back of the product when adjusting the angle.

•Be careful not to use excessive force when adjusting the angle.

Using the Kensington Lock

For more information on installation and usage, refer to the Kensington lock owner’s manual or visit the website

at http://www.kensington.com.

Connect the monitor to a table using the Kensington security system cable.

NOTE

•The Kensington security system is optional. You can obtain optional accessories from most electronics stores.

ENGLISH

Installing on the Wall

Secure at least a certain amount of vertical flat space in the partition to be installed.

In addition, ensure that it is strong and sturdy enough to hold and use the product.

B-Type C-Type

Hanger

Length (A)

B-Type 80mm (3.1 inches)

C-Type 200mm (7.8inches)

NOTE

•The stand can be unfolded by pushing the button on the back of the product.

ENGLISH

CAUTION

•The partition in which the product is installed must be sufficiently rigid. If it is made of fragile material such

as glass, this may result in damage to the product.

•If the partition surface is uneven or tilted, the product may tilt.

•When the monitor is installed, the traces may remain on the partition.

•Do not hang heavy items such as bags or clothes on the monitor or cradle.

•If the partition cannot support the monitor sufficiently, be careful as the monitor may fall over.

•When standing the folded stand, be careful not to get your fingers caught between the monitor head and

the stand.

•Unplug the power cord before moving or installing the monitor.There is risk of electric shock.

•Make sure to use the power cord that is provided in the product package and connect it to a grounded power

outlet.

•If you need another power cord, please contact your local dealer or the nearest retail store.

NOTE

B-Type 550mm (21.6inches)

C-Type 670mm (26.3inches)

B530mm (20.8inches)

C30~70mm (1.1~ 2.7inches)
