LG 27HJ710S Manual de usuario

OWNER’S MANUAL

27HJ710S

IPS LED

MONITOR

(LED Monitor*)

Please read this manual carefully before operating

your set and retain it for future reference.

* LG LED Monitor applies LCD screen with LED backlights.

www.lg.com

ENGLISH

TABLE OF CONTENTS

ON CLEANING ------------------------ 3

LICENSE ------------------------------- 3

ASSEMBLY AND PREPARING-------- 4

SETTINGS ---------------------------- 13

TROUBLESHOOTING ---------------- 25

PRODUCT SPECIFICATIONS -------- 27

EXTERNAL CONTROLLER SETUP -- 31

ENGLISH

ON CLEANING

Recommended Cleaning Chemicals

Isopropanol 100%

Ethanol 70%

Cidex®OPA

0.9% NaCl solution

How to Use Cleaner

Prior to cleaning, turn off the monitor and remove the power cable.

Soak a soft cloth in a recommended cleaner, then lightly rub the screen with no more than 1 N of force.

The cleaner could cause serious damage if it leaks inside the monitor while cleaning.

Do not clean the screen’s LCD panel as it may be damaged. Clean the other parts of the monitor.

Do not use benzene, thinner, acids or alkaline cleaners or other such solvents.

Cleaning guidelines for displays must only be carried out by medical professionals (doctors or nurses) and must not

be handled by patients.

LICENSE

Each model has different licenses. Visit www.lg.com for more information on the license.

The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI

logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

VESA, VESA logo, DisplayPort compliance logo and DisplayPort compliance logo for

dual-mode source devices are all registered trademarks of the Video Electronics

Standards Association.

The SuperSpeed USB Trident logo is a registered trademark of USB Implementers

Forum, Inc.

ENGLISH

ASSEMBLY AND PREPARING

Product Composition

Please check whether all the components are included in the box before using the product. If there are any missing

components, contact the retailer where you purchased the product. Note that the product and related components

may look different from those shown here.

CD (Owner’s Manual / Software /

Guides) / Cards Power Cord AC/DC Adaptor

DisplayPort Cable HDMI Cable

CAUTION

Always use genuine LG components to ensure safety and product performance.

The product warranty will not cover damage or injury caused by the use of unauthorized components.

It is recommend that use the supplied components.

If you use generic cables not certified by LG, the screen may not display or there may be image noises.

ENGLISH

NOTE

The components may look different from those illustrated here.

Without prior notice, all product information and specifications contained in this manual are subject to change to

improve the performance of the product.

To purchase optional accessories, visit an electronics store or an online shopping site, or contact the retailer from

which you purchased the product.

The power cord provided may differ depending upon the region.

Supported Drivers and Software

Check the drivers and software supported by your product and refer to the manuals on the CD enclosed in the product

package.

Drivers and Software Installation Priority 27HJ710S

Monitor Driver Recommended O

True Color Pro Optional O

Required and Recommended: You can download and install the latest version from the enclosed CD or from the LGE

website (www.lg.com).

Optional: You can download and install the latest version from the LGE website (www.lg.com).

ENGLISH

Product and LED Control buttons

1 2 5 7 83 64

ENGLISH

LED Control button Functions

Input Selects the input mode.

PIP/PBP Displays the screens of two input modes on one monitor.

Hotkey 1, 2 Opens the Hot key Settings menu.

Brightness Adjusts the screen brightness.

OK Selects menus or options and confirms.

Contrast Adjusts the screen contrast.

Menu Displays LED Control buttons on the front panel and opens the menu mode.

Power

indicator

The green indicator illuminates if the power is on. The arrow indicates the position of the

power switch.

Power switch Turns the power on/off.

NOTE

The Power button is located at the bottom right on the front of the monitor.

If the Control Key LED is turned off, press the Control Key [Menu] button to turn the Control button LED on. When

the Control Key LED is turned on, you can control the Control Key functions.

ENGLISH

Connectors

1 2 3 4 5 6 7 98

Potential Equalization Conductor

- Connect an equipotential plug.

RS-232C Connector

- Connect to an external device through the RS-232C connector and control the monitor.

DC-IN (19 V )Connector

- Connect the AC/DC adaptor.

SDI IN / SDI OUT Connector

- Receives or transmits serial digital component signals.

DVI-D IN / DVI-D OUT Connector

- Receives or transmits digital video signals.

HDMI IN Connector

- Receives digital video signals.

- DVI to HDMI/DP (DisplayPort) to HDMI cables may cause compatibility issues.

Make sure to use certified cables that bear the HDMI logo. If you do not use a certified HDMI cable, the

screen may not display, or a connection error may occur.

►Recommended HDMI cable types

- High-speed HDMI®/TM cables

- High-speed HDMI®/TM Ethernet cables

ENGLISH

DP IN / DP OUT Connector

- Receives or transmits digital video signals.

- There may be no video output depending on the DP (DisplayPort) version of your PC.

- A cable with DisplayPort 1.2 specifications is recommended when using a Mini DP to DP (Mini DisplayPort

to DisplayPort) cable.

SERVICE ONLY Connector

-The USB port is used for service only.

5 V 0.9 A (USB Connector)

- Used for HW Calibrator (Optional Accessory) connection.

- A keyboard, mouse or USB device can be connected.

CAUTION

Precautions for Using USB Storage Devices

A USB storage device installed using an automatic recognition program or its own driver may not be

recognizable.

Some USB devices may not be supported or may not work properly.

It is recommended that you use a USB hub or hard disk drive with power supplied. (If insufficient power is

supplied, the USB storage device may not be detected properly)

5 V 0.9 A / (USB Connector)

- Connect your accessory to the USB input port.

- To use USB 3.0, connect a USB 3.0 Type A-B cable to your PC.

NOTE

All signal OUT connectors (SDI, DVI, DP) output signals when the monitor's power switch is on. Signals are not output

when the power switch is off.

This monitor supports the *Plug and Play feature.

* Plug and Play: A feature that allows you to add a device to your computer without having to reconfigure anything or

install any manual drivers.

The standard of the DVI and the SDI output terminals for transmitting a screen

- DVI OUT: Connect a 5-meter cable to transmit a copied screen to a monitor.

- SDI OUT: Connect a 100-meter cable (BELDEN 1694) to transmit a copied screen to a monitor.

ENGLISH

Installing the Monitor

Cable connection and organize

Before connecting the connectors, remove the back

door as shown below.

CAUTION

When the back door is attached to the monitor, the

monitor meets water resistance standards. Do not

use the monitor with the back door detached, as the

water resistance capability is not guaranteed without

the door.
