LG 20M47A Manual de usuario

www.lg.com

LED LCD MONITOR MODEL

ENGLISH

OWNER’S MANUAL

LED LCD MONITOR

Please read this manual carefully before operating

your set and retain it for future reference.

20M47A

20M47D

27M47H

27M47HQ

27M47VQ

ENG

ENGLISH

TABLE OF CONTENTS

CONTENTS

3 LICENSE

4 ASSEMBLINGANDPREPAR-

ING

4 Unpacking

6 Partsandbuttons

7 MovingandLiftingtheMonitor

8 SettinguptheMonitorset

8 - AttachingtheStandBase

9 - DetachingtheStandBase

10 - Mountingonatable

10 - Usingthecableholder

12 - Mountingonawall

13 USINGTHEMONITORSET

13 ConnectingtoaPC

13 - D-SUBconnection

13 - DVI-Dconnection

13 - HDMIconnection

14 ConnectingtoAVDevices

14 - HDMIconnection

15 ConnectingtoExternalDevices

15 - Peripheraldeviceconnection

16 CUSTOMIZINGSETTINGS

17 CustomizingSettings

17 - MenuSettings

19 -Picture

20 -Color

21 -Display

21 -Audio

22 -Others

23 READERSetting

24 FUNC.Setting

24 -SMARTENERGYSAVING

25 -PictureMode

26 -Colorwizard

27 -DUALDISPLAY

27 -DUALWEB

28 TROUBLESHOOTING

30 SPECIFICATIONS

34 PresetModes(Resolution)

35 Indicator

36 PROPERPOSTURE

36 ProperpostureforusingtheMonitorset.

ENG

ENGLISH

LICENSE

Eachmodelhasdifferentlicenses.Visitwww.lg.comformoreinformationonthelicense.

ThetermsHDMIandHDMIHigh-DefinitionMultimediaInterface,andthe

HDMIlogoaretrademarksorregisteredtrademarksofHDMILicensingLLC

intheUnitedStatesandothercountries.

27M47H 27M47HQ 27M47VQ

ThefollowingcontentisonlyappliedtothemonitorwhichissoldinEuropemarketandwhichneedsto

meettheErPDirective:

*Thismonitorissettobeturnedoffautomaticallyin4hoursafteryouturnedondisplayifthereisnoadjust-

menttodisplay.

*Tomakethissettingbedisabled,changetheoptionto‘Off’inOSDmenuof“AutomaticStandby”.

ENG

ENGLISH

ASSEMBLING AND PREPARING

ASSEMBLINGANDPREPARING

Unpacking

Checkyourproductboxforthefollowingitems.Ifthereareanymissingaccessories,contactthelocal

dealerwhereyoupurchasedyourproduct.Theillustrationsinthismanualmaydifferfromtheactualproduct

andaccessories.

CD(Owner'sManual)/

Card

(Dependingonthecountry) (Dependingonthecountry)

PowerCord AC-DCAdapter

AC-DCAdapter

or

D-SUBCable

(Thiscableisnotincludedinall

countries.)

HDMICable

StandBody StandBase

DVI-DCable

(Thiscableisnotincludedinall

countries.)

(Thiscableisnotincludedinall

countries.)

StandBody StandBase

ENG

ENGLISH

ASSEMBLING AND PREPARING

 Donotuseanyunapprovedaccessoriestoensurethesafetyandproductlifespan.

 Anydamagesorinjuriesbyusingunapprovedaccessoriesarenotcoveredbythewarranty.

 Theaccessoriessuppliedwithyourproductmayvarydependingonthemodel.

 Productspecificationsorcontentsinthismanualmaybechangedwithoutpriornoticeduetoupgrade

ofproductfunctions.

CAUTION

NOTE

ENG

ENGLISH

ASSEMBLING AND PREPARING

Partsandbuttons

PowerIndicator

 LightingOn:Turnedon

 LightingOff:Turnedoff

Connectionpanel(Seep.13~15)

Button(Seep.16)

(PowerButton)

ENG

ENGLISH

ASSEMBLING AND PREPARING

MovingandLiftingtheMonitor

Whenmovingorliftingthemonitor,followthese

instructionstopreventthemonitorfrombeing

scratchedordamagedandtoensuresafetrans-

portationregardlessofitsshapeorsize.

 Asfaraspossible,avoidtouchingthemoni-

torscreen.Thismayresultindamagetothe

screenorsomeofthepixelsusedtocreate

images.

 Itisadvisabletoplacethemonitorinthe

originalboxorpackingmaterialbeforeat-

temptingtomoveit.

 Beforemovingorliftingthemonitor,discon-

nectthepowercordandallcables.

 Holdthetopandbottomofthemonitorframe

firmly.Donotholdthepanelitself.

 Whenholdingthemonitor,thescreenshould

faceawayfromyoutopreventitbeing

scratched.



 Whenmovingthemonitor,avoidanystrong

shockorvibrationstotheproduct.

 Whenmovingthemonitor,keepitupright,

neverturnthemonitoronitssideortiltit

sideways.

CAUTION

ENG

ENGLISH

ASSEMBLING AND PREPARING

AttachtheStandBodytothemonitorset.

AttachtheStandBase.

Tightenthescrewtotheright.

SettinguptheMonitorset

AttachingtheStandBase

1 PlacetheMonitorsetwiththescreenside

downonaflatandcushionedsurface.

Layafoammatorsoftprotectivecloth

onthesurfacetoprotectthescreenfrom

damage.

CAUTION

2

StandBase

StandBody

StandBase

20M47A 20M47D

27M47H 27M47HQ 27M47VQ

ENG

ENGLISH

ASSEMBLING AND PREPARING

DetachingtheStandBase

1 PlacetheMonitorsetwiththescreenside

downonaflatandcushionedsurface.

StandBase

StandBody

PullouttheStandBodyandStandBase

fromthemonitorset.

Turnthescrewtotheleft.

PullouttheStandBase.

 Thisillustrationdepictsthegeneralmodelof

connection.Yourmonitormaydifferfromthe

itemsshowninthepicture.

 Donotcarrytheproductupsidedownholding

onlythestandbase.Theproductmayfall

andgetdamagedorinjureyourfoot.

CAUTION

Turnthescrewtotheleft.

PullouttheStandBasefromtheStandBody.

RemovetwoscrewsandpullouttheStand

Bodyfromthemonitorset.

StandBody

StandBase

2

27M47H 27M47HQ 27M47VQ

20M47A 20M47D

ENG

ENGLISH

ASSEMBLING AND PREPARING

Mountingonatable

1 LiftandtilttheMonitorsetintoitsupright

positiononatable.

Leavea10cm(minimum)spacefromthewall

forproperventilation.

Usingthecableholder

2 ConnecttheAC-DCAdapterandPowerCord

toawalloutlet.

3 Press (Power)buttononthebottomswitch

paneltoturnthepoweron.

10 cm

Unplugthepowercordbeforemovingthe

Monitortoanotherlocation.Otherwiseelectric

shockmayoccur.

CAUTION

Cableholder

or
