LG 19M38A Manual de usuario

www.lg.com

IPS LED(LED LCD) MONITOR MODEL

Please read this manual carefully before operating

your set and retain it for future reference.

19M38A

19M38D

20M38A

20M38D

20M38H

22M38A

22M38D

22M38H

24M38A

24M38D

24M38H

27MP38VQ

27MP38HQ

*LG LED Monitors are LCD Monitors with LED Backlighting.

Owner's Manual

IPS LED MONITOR

LED LCD MONITOR

(LED MONITOR*)

ENG

ENGLISH

TABLE OF CONTENTS

CONTENTS

3 LICENSE

4 ASSEMBLINGANDPREPAR-

ING

4 Unpacking

6 Partsandbuttons

7 MovingandLiftingtheMonitor

8 SettinguptheMonitorset

8 - AttachingtheStandBase

9 - DetachingtheStandBase

10 - Mountingonatable

10 - Usingthecableholder

12 - Mountingonawall

13 USINGTHEMONITORSET

13 ConnectingtoaPC

13 - D-SUBconnection

13 - DVI-Dconnection

14 - HDMIconnection

14 ConnectingtoAVDevices

14 - HDMIconnection

15 ConnectingtoExternalDevices

15 - Peripheraldeviceconnection

16 CUSTOMIZINGSETTINGS

17 CustomizingSettings

17 - MenuSettings

19 -Picture

20 -Color

21 -Display

21 -Audio

22 -Others

23 READERSetting

24 FUNC.Setting

24 -SMARTENERGYSAVING

25 -PictureMode

26 -ColorWeakness

27 TROUBLESHOOTING

29 SPECIFICATIONS

39 PresetModes(Resolution)

40 Indicator

41 PROPERPOSTURE

41 ProperpostureforusingtheMonitorset.

ENG

ENGLISH

LICENSE

Eachmodelhasdifferentlicenses.Visitwww.lg.comformoreinformationonthelicense.

ThetermsHDMIandHDMIHigh-DefinitionMultimediaInterface,andthe

HDMIlogoaretrademarksorregisteredtrademarksofHDMILicensingLLC

intheUnitedStatesandothercountries.

ThefollowingcontentisonlyappliedtothemonitorwhichissoldinEuropemarketandwhichneedsto

meettheErPDirective:

*Thismonitorissettobeturnedoffautomaticallyin4hoursafteryouturnedondisplayifthereisnoadjust-

menttodisplay.

*Tomakethissettingbedisabled,changetheoptionto‘Off’inOSDmenuof“AutomaticStandby”.

20M38H 22M38H 24M38H 27MP38VQ 27MP38HQ

ENG

ENGLISH

ASSEMBLING AND PREPARING

ASSEMBLINGANDPREPARING

Unpacking

Checkyourproductboxforthefollowingitems.Ifthereareanymissingaccessories,contactthelocal

dealerwhereyoupurchasedyourproduct.Theillustrationsinthismanualmaydifferfromtheactualproduct

andaccessories.

CD(Owner'sManual)/

Card

(Dependingonthecountry) (Dependingonthecountry)

PowerCord AC-DCAdapter AC-DCAdapter

or

D-SUBCable

(Thiscableisnotincludedinall

countries.)

HDMICable

StandBody StandBase

StandBase

DVI-DCable

(Thiscableisnotincludedinall

countries.)

(Thiscableisnotincludedinall

countries.)

StandBody TwoScrews

ENG

ENGLISH

ASSEMBLING AND PREPARING

 Donotuseanyunapprovedaccessoriestoensurethesafetyandproductlifespan.

 Anydamagesorinjuriesbyusingunapprovedaccessoriesarenotcoveredbythewarranty.

 Theaccessoriessuppliedwithyourproductmayvarydependingonthemodel.

 Productspecificationsorcontentsinthismanualmaybechangedwithoutpriornoticeduetoupgrade

ofproductfunctions.

CAUTION

NOTE

ENG

ENGLISH

ASSEMBLING AND PREPARING

Partsandbuttons

PowerIndicator

 LightingOn:Turnedon

 LightingOff:Turnedoff

Connectionpanel(Seep.13~15)

Button(Seep.16)

(PowerButton)

ENG

ENGLISH

ASSEMBLING AND PREPARING

MovingandLiftingtheMonitor

Whenmovingorliftingthemonitor,followthese

instructionstopreventthemonitorfrombeing

scratchedordamagedandtoensuresafetrans-

portationregardlessofitsshapeorsize.

 Asfaraspossible,avoidtouchingthemoni-

torscreen.Thismayresultindamagetothe

screenorsomeofthepixelsusedtocreate

images.

 Itisadvisabletoplacethemonitorinthe

originalboxorpackingmaterialbeforeat-

temptingtomoveit.

 Beforemovingorliftingthemonitor,discon-

nectthepowercordandallcables.

 Holdthetopandbottomofthemonitorframe

firmly.Donotholdthepanelitself.

 Whenholdingthemonitor,thescreenshould

faceawayfromyoutopreventitbeing

scratched.



 Whenmovingthemonitor,avoidanystrong

shockorvibrationstotheproduct.

 Whenmovingthemonitor,keepitupright,

neverturnthemonitoronitssideortiltit

sideways.

CAUTION

ENG

ENGLISH

ASSEMBLING AND PREPARING

SettinguptheMonitorset

AttachingtheStandBase

1 PlacetheMonitorsetwiththescreenside

downonaflatandcushionedsurface.

Layafoammatorsoftprotectivecloth

onthesurfacetoprotectthescreenfrom

damage.

CAUTION

2

StandBase

StandBody

StandBase

19M38A 20M38A 22M38A 24M38A

19M38D 20M38D 22M38D 24M38D

20M38H 22M38H 24M38H

27MP38VQ 27MP38HQ

AttachtheStandBodytothemonitorset.

AttachtheStandBase.

Tightenthescrewtotherightwithacoin.

AttachtheStandBodytothemonitorset.

UsetwoscrewstofixtheStandBodyand

monitorset.

AttachtheStandBase.

Tightenthescrewtotherightwithacoin.

StandBody

ENG

ENGLISH

ASSEMBLING AND PREPARING

DetachingtheStandBase

1 PlacetheMonitorsetwiththescreenside

downonaflatandcushionedsurface.

StandBase

StandBody

 Thisillustrationdepictsthegeneralmodelof

connection.Yourmonitormaydifferfromthe

itemsshowninthepicture.

 Donotcarrytheproductupsidedownholding

onlythestandbase.Theproductmayfall

andgetdamagedorinjureyourfoot.

CAUTION

StandBody

StandBase

219M38A 20M38A 22M38A 24M38A

19M38D 20M38D 22M38D 24M38D

20M38H 22M38H 24M38H

27MP38VQ 27MP38HQ

PullouttheStandBodyandStandBase

fromthemonitorset.

Turnthescrewtotheleftwithacoin.

PullouttheStandBase.

Turnthescrewtotheleftwithacoin.

PullouttheStandBasefromtheStandBody.

RemovetwoscrewsandpullouttheStand

Bodyfromthemonitorset.

ENG

ENGLISH

ASSEMBLING AND PREPARING

Mountingonatable

1 LiftandtilttheMonitorsetintoitsupright

positiononatable.

Leavea10cm(minimum)spacefromthewall

forproperventilation.

Usingthecableholder

2 ConnecttheAC-DCAdapterandPowerCord

toawalloutlet.

3 Press (Power)buttononthebottomswitch

paneltoturnthepoweron.

10 cm

Unplugthepowercordbeforemovingthe

Monitortoanotherlocation.Otherwiseelectric

shockmayoccur.

CAUTION

Cableholder

or
