LG 29LN549M Manual de usuario

www.lg.com

OWNER’S MANUAL

LED TV

LG LED TV applies LCD screen with LED backlights.

Please read this manual carefully before operating the your TV and

retain it for future reference.

ENGLISH

28LN549M

29LN549M

P/NO : MFL68021901 (1308-REV00)

Printed in Korea

ENGLISH

TABLE OF CONTENTS

3 LICENSES

4 INSTALLATION PROCEDURE

5 ASSEMBLING AND PREPARING

5 Unpacking

8 Parts and buttons

12 Lifting and moving the TV

13 Setting up the TV

13 - Attaching the Stand Base

13 - Detaching the Stand Base

15 - Attaching the Stand Base

16 - Detaching the Stand Base

18 - Mounting on a table

20 - Tidying cables

22 - Mounting on a wall

24 WATCHING TV

24 Turning the TV on for the first time

26 MAKING CONNECTIONS

26 Connecting an antenna

26 - Connecting an antenna or basic cable

27 - Connecting with a cable box

28 Connecting to a HD receiver, DVD Player,

VCR or Gaming device

28 - HDMI Connection

29 - HDMI to DVI Connection

30 - Component Connection

31 - Composite Connection

32 Connecting a USB Device

33 Connecting to a PC

34 - HDMI connection

35 - HDMI to DVI connection

36 - RGB connection

37 REMOTE CONTROL

39 CUSTOMIZING SETTINGS

39 Accessing the Main Menus

40 USING THE USER GUIDE

40 Accessing the On-Screen User Guide

40 - Using the TV menu

40 - Using the Remote Control

41 MAINTENANCE

41 Cleaning Your TV

41 Screen and frame

41 Cabinet and stand

41 Power cord

42 Preventing “Image burn” or “Burn-in” on

your TV screen

43 TROUBLESHOOTING

43 General

44 SPECIFICATIONS

48 KEY CODES

49 EXTERNAL CONTROL DEVICE

SETUP

49 USB to Serial converter with USB Cable

50 RS-232C with RS-232C Cable (Legacy)

50 - Customer Computer

50 - RS-232C configurations

51 Communication Parameters

51 Command reference list

52 Transmission / Receiving Protocol

ENGLISH

LICENSES

Supported licenses may differ by model. For more information of the licenses, visit www.lg.com.

Manufactured under license from Dolby Laboratories. Dolby and the

double-D symbol are trademarks of Dolby Laboratories.

The terms HDMI and HDMI High-Definition Multimedia Interface, and the

HDMI logo are trademarks or registered trademarks of HDMI Licensing LLC

in the United States and other countries.

ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, LLC, a

subsidiary of Rovi Corporation. This is an official DivX Certified® device that

plays DivX video. Visit divx.com for more information and software tools to

convert your files into DivX videos.

ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified® device must be

registered in order to play purchased DivX Video-on-Demand (VOD) movies.

To obtain your registration code, locate the DivX VOD section in your device

setup menu. Go to vod.divx.com for more information on how to complete

your registration.

DivX Certified® to play DivX® video up to HD 1080p, including premium

content.

DivX®, DivX Certified® and associated logos are trademarks of Rovi

Corporation or its subsidiaries and are used under license.

Covered by one or more of the following U.S. patents: 7,295,673; 7,460,668;

7,515,710; 7,519,274

ENGLISH

4INSTALLATION PROCEDURE

INSTALLATION PROCEDURE

1 Open the package and make sure all the accessories are included.

2 Attach the stand to the TV.

3 Connect an external device to the TV.

 Image shown may differ from your TV.

 Your TV’s OSD (On Screen Display) may differ slightly from that shown in this manual.

 The available menus and options may differ from the input source or product model that you are

using.

 New features may be added to this TV in the future.

NOTE

ENGLISH

ASSEMBLING AND PREPARING

Unpacking

Check your product box for the following items. If there are any missing accessories, contact the local

dealer where you purchased your product. The illustrations in this manual may differ from the actual

product and accessories.

 The accessories supplied with your product may vary depending on the model.

 Product specifications or contents in this manual may be changed without prior notice due to

upgrade of product functions.

NOTE

 Do not use any pirated items to ensure the safety and product life span.

 Any damages or injuries by using unapproved or counterfeit parts or accessories are not covered

by the warranty.

CAUTION

 The items supplied with your product may vary depending on the model.

 Product specifications or contents of this manual may be changed without prior notice due to

upgrade of product functions.

 For an optimal connection, HDMI cables and USB devices should have bezels less than 10 mm thick

and 18 mm width. Use an extension cable that supports USB 2.0 if the USB cable or USB memory

stick does not fit into your TV’s USB port.

NOTE

*A 10 mm

*B 18 mm

ENGLISH

6ASSEMBLING AND PREPARING

28LN549M

Remote Control

Batteries (AAA)

Owner's Manual/ Cards

AC-DC Adapter

(See p.37, See p.38)

(See p.18)(See p.18) (See p.18)

Cable Tie

(See p.20)

Power Cord AC-DC Adapter

( Depending on the country ) (Depending on the country)

Stand Base

(See p.13)

ENGLISH

ASSEMBLING AND PREPARING

Remote Control

Batteries (AAA)

Owner's Manual/ Cards

AC-DC Adapter.

Cable Tie.

(See p.37, See p.38)

(See p.19)(See p.19) (See p.19)

(See p.20)

Power Cord. AC-DC Adapter.

( Depending on the country ) (Depending on the country)

Stand Base

(See p.15, See p.16)

29LN549M

(See p.15, See p.16)

Screws for Assembly

2 EA

(See p.15, See p.16)

Stand Body

ENGLISH

8ASSEMBLING AND PREPARING

Parts and buttons

28LN549M

INPUT

SETTINGS

All of the buttons are touch sensitive and can be operated through simple touch with your finger.

NOTE

Touch buttons Description

Scrolls through the saved channels.

Adjusts the volume level.

OK Selects the highlighted menu option or confirms an input.

SETTINGS Accesses the main menus, or saves your input and exits the menus.

INPUT Changes the input source.

/ ITurns the power on or off.

Remote Control Sensor

Standby Light

 Lighting On:

When Power is turned off

 Lighting Off:

When Power is turned on

Touch Buttons

Front

ENGLISH

ASSEMBLING AND PREPARING

All of the buttons are touch sensitive and can be operated through simple touch with your finger.

NOTE

Touch button Description

Scrolls through the saved channels.

Adjusts the volume level.

OK Selects the highlighted menu option or confirms an input.

SETTINGS Accesses the main menus, or saves your input and exits the menus.

INPUT Changes the input source.

/ ITurns the power on or off.

Remote Control Sensor

Standby Light

 Lighting On:

When Power is turned off

 Lighting Off:

When Power is turned on

Touch Buttons

29LN549M

ENGLISH

10 ASSEMBLING AND PREPARING

28LN549M

RS-232C IN

(CONTROL & SERVICE)

Connection panel (See p.26)

(Depending on the

model)

Rear
