OWNER’S MANUAL

LED LCD TV

Please read this manual carefully before operating your set and retain it

for future reference.

LM96**

LM95**

LM86**

A-2 TABLE OF CONTENTS

TABLE OF CONTENTS

A-3 SETTING UP THE TV

A-3 Attachingthestand

A-7 Tidyingcables

B-1 MAKING CONNECTIONS

B-1 Antennaconnection

B-2 Satelliteconnection

B-3 HDMIconnection

B-5 - ARC(AudioReturnChannel)

B-6 DVItoHDMIconnection

B-8 MHLconnection

B-10 RGB-PCconnection

B-11 Componentconnection

B-13 Compositeconnection

B-14 Euroscartconnection

B-18 Audioconnection

B-19 - Digitalopticalaudioconnection

B-21 USBconnection

B-22 CImoduleconnection

B-24 Headphoneconnection

B-31 SPECIFICATIONS

LANGUAGE LIST

English

Deutsch

Français

Italiano

Español

Português

Nederlands

Ελληνικά

COMMON

LANGUAGE

COMMON

A-3

SETTING UP THE TV

ImageshownmaydifferfromyourTV.

Attaching the stand

Front

Top View

4EA

M4x20

 WhenattachingthestandtotheTVset,

placethescreenfacingdownonacushioned

tableorflatsurfacetoprotectthescreen

fromscratches.

CAUTION

 Makesurethatthescrewsareinserted

correctlyandfastenedsecurely.Iftheyare

notfastenedsecurelyenough,theTVmay

tiltforwardafterbeinginstalled.

 Donotusetoomuchforceandovertighten

thescrews;otherwisescrewmaybe

damagedandnottightencorrectly.

CAUTION

4EA

M4x20

 RemovethestandbeforeinstallingtheTVon

awallmountbyperformingthestand

attachmentinreverse.

NOTE

47/55LM96**

Stand base

Stand body

Stand rear cover

A-4 SETTING UP THE TV

Front

Top View

4EA

M4x20

42/47/55LM86**

Stand base

Stand body

Stand rear cover

 WhenattachingthestandtotheTVset,

placethescreenfacingdownonacushioned

tableorflatsurfacetoprotectthescreen

fromscratches.

CAUTION

Wrapping bag

A-5

SETTING UP THE TV

4EA

M4x20

 RemovethestandbeforeinstallingtheTVon

awallmountbyperformingthestand

attachmentinreverse.

NOTE

Protection pad

 Makesurethatthescrewsareinserted

correctlyandfastenedsecurely.Iftheyare

notfastenedsecurelyenough,theTVmay

tiltforwardafterbeinginstalled.

 Donotusetoomuchforceandovertighten

thescrews;otherwisescrewmaybe

damagedandnottightencorrectly.

CAUTION

A-6 SETTING UP THE TV

Front

4EA

M5x35

 WhenattachingthestandtotheTVset,

placethescreenfacingdownonacushioned

tableorflatsurfacetoprotectthescreen

fromscratches.

CAUTION

4EA

M4x20

72LM95**

Stand base

Stand body

Stand rear cover

Top View

 Makesurethatthescrewsareinserted

correctlyandfastenedsecurely.Iftheyare

notfastenedsecurelyenough,theTVmay

tiltforwardafterbeinginstalled.

 Donotusetoomuchforceandovertighten

thescrews;otherwisescrewmaybe

damagedandnottightencorrectly.

CAUTION

 RemovethestandbeforeinstallingtheTVon

awallmountbyperformingthestand

attachmentinreverse.

NOTE

A-7

SETTING UP THE TV

Tidying cables

1 Gatherthecableswiththestandrearcover. 1 Installthecableholderasshown.

47/55LM96**, 42/47/55LM86** 72LM95**

2 Installthecableholderasshown.

2 Gatherandbindthecableswiththecable

holder.

Cable holder

3 Gatherandbindthecableswiththecable

holder.

3 Pullthecablemanagementonthestandrear

coverandorganizecables.Then,putitback.

Stand rear cover

 DonotmovetheTVbyholdingthecableholder,asthecableholdersmaybreak,andinjuriesand

damagetotheTVmayoccur.

CAUTION

Cable holder

Cable management
