OWNER’S MANUAL

LED TV*

*LG LED TV refers to an LCD screen with LED backlights.

Please read this manual carefully before operating your TV and retain

it for future reference.

ENGLISH

24LN451B

ENGLISH

TABLE OF CONTENTS

3LICENSES

4INSTALLATION PROCEDURE

5ASSEMBLING AND PREPARING

5 Unpacking

7 Parts and buttons

8 Lifting and moving the TV

9 Setting up the TV

9 - Attaching the Stand Base

9 - Detaching the Stand Base

11 - Mounting on a table

12 - Using the Kensington security system

12 - Tidying cables

12 - Mounting on a wall

14 WATCHING TV

14 Turning the TV on for the first time

16 MAKING CONNECTIONS

16 Connecting an antenna

17 Connecting to a HD receiver, DVD Player,

VCR or Gaming device

17 - HDMI Connection

18 - HDMI to DVI Connection

19 - Component Connection

20 - Composite Connection

21 Connecting a USB Device

22 Connecting to a PC

23 - HDMI connection

24 - HDMI to DVI connection

25 - RGB connection

26 REMOTE CONTROL

28 CUSTOMIZING SETTINGS

28 Accessing the Main Menus

29 USING THE USER GUIDE

29 Accessing the On-Screen User Guide

29 - Using the TV menu

29 - Using the Remote Control

30 MAINTENANCE

30 Cleaning Your TV

30 Screen and frame

30 Cabinet and stand

30 Power cord

31 Preventing “Image burn” or “Burn-in” on

your TV screen

32 TROUBLESHOOTING

32 General

33 SPECIFICATIONS

ENGLISH

LICENSES

Supported licenses may differ by model. For more information of the licenses, visit www.lg.com.

Manufactured under license from Dolby Laboratories. Dolby and the

double-D symbol are trademarks of Dolby Laboratories.

The terms HDMI and HDMI High-Definition Multimedia Interface, and the

HDMI logo are trademarks or registered trademarks of HDMI Licensing LLC

in the United States and other countries.

ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, LLC, a

subsidiary of Rovi Corporation. This is an official DivX Certified® device that

plays DivX video. Visit divx.com for more information and software tools to

convert your files into DivX videos.

ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified® device must be

registered in order to play purchased DivX Video-on-Demand (VOD) movies.

To obtain your registration code, locate the DivX VOD section in your device

setup menu. Go to vod.divx.com for more information on how to complete

your registration.

DivX Certified® to play DivX® video up to HD 1080p, including premium

content.

DivX®, DivX Certified® and associated logos are trademarks of Rovi

Corporation or its subsidiaries and are used under license.

Covered by one or more of the following U.S. patents: 7,295,673; 7,460,668;

7,515,710; 7,519,274

ENGLISH

4INSTALLATION PROCEDURE

INSTALLATION PROCEDURE

1Open the package and make sure all the accessories are included.

2Attach the stand to the TV.

3Connect an external device to the TV.

yImage shown may differ from your TV.

yYour TV’s OSD (On Screen Display) may differ slightly from that shown in this manual.

yThe available menus and options may differ from the input source or product model that you are

using.

yNew features may be added to this TV in the future.

NOTE

ENGLISH

ASSEMBLING AND PREPARING

Unpacking

Check your product box for the following items. If there are any missing accessories, contact the local

dealer where you purchased your product. The illustrations in this manual may differ from the actual

product and accessories.

yThe accessories supplied with your product may vary depending on the model.

yProduct specifications or contents in this manual may be changed without prior notice due to

upgrade of product functions.

NOTE

yDo not use any pirated items to ensure the safety and product life span.

yAny damages or injuries by using unapproved or counterfeit parts or accessories are not covered

by the warranty.

CAUTION

yThe items supplied with your product may vary depending on the model.

yProduct specifications or contents of this manual may be changed without prior notice due to

upgrade of product functions.

yFor an optimal connection, HDMI cables and USB devices should have bezels less than 10 mm thick

and 18 mm width. Use an extension cable that supports USB 2.0 if the USB cable or USB memory

stick does not fit into your TV’s USB port.

NOTE

*A 10 mm

*B 18 mm

ENGLISH

6ASSEMBLING AND PREPARING

Remote Control /

Batteries (AAA)

CD (Owner's Manual) /

Cards

AC-DC Adapter

(See p.26, See p.27)

(See p.11)(See p.11) (See p.11)

Power Cord AC-DC Adapter

( Depending on the country ) (Depending on the country)

Stand Base

(See p.9)

ENGLISH

ASSEMBLING AND PREPARING

Parts and buttons

All of the buttons are touch sensitive and can be operated through simple touch with your finger.

NOTE

Touch button Description

Scrolls through the saved channels.

Adjusts the volume level.

OK Selects the highlighted menu option or confirms an input.

SETTINGS Accesses the main menus, or saves your input and exits the menus.

INPUT Changes the input source.

/ITurns the power on or off.

INPUT

SETTINGS

Connection panel ( on page 16)

Touch Buttons

Remote Control

Sensor

Standby Light

yLighting On: Turned off

yLighting Off: Turned on

(Depending on the

model)

ENGLISH

8ASSEMBLING AND PREPARING

yWhen holding the TV, the screen should face

away from you to prevent the screen from

scratches.

yWhen transporting the TV, do not expose the

TV to jolts or excessive vibration.

yWhen transporting the TV, keep the TV

upright, never turn the TV on its side, or tilt

towards the left or right.

Lifting and moving the TV

When moving or lifting the TV, read the following

to prevent the TV from being scratched or

damaged and for save transportation regardless of

its type and size.

Avoid touching the screen at all times, as

this may result in damage to the screen or

some of the pixels used to create images.

CAUTION

yIt is recommended to move the TV in the

box or packing material that the TV originally

came in.

yBefore moving or lifting the TV, disconnect

the power cord and all cables.

yHold the top and bottom of the TV frame

firmly. Make sure not to hold the transparent

part, speaker, or speaker grill area.

ENGLISH

ASSEMBLING AND PREPARING

Setting up the TV

Image shown may differ from your TV.

Stand Base

Attaching the Stand Base Detaching the Stand Base

yWhen Detaching the stand from TV, Detach

the stand with lifting up the lever in the

direction of the arrow.

NOTE

Stand Base

CAUTION

yLay a foam mat or soft protective cloth

on the surface to protect the screen from

damage.

yWhen attaching the stand to the TV set,

place the screen facing down on a cushioned

table or flat surface to protect the screen

from scratches.

CAUTION

yLay a foam mat or soft protective cloth

on the surface to protect the screen from

damage.

yWhen Detaching the stand to the TV set,

place the screen facing down on a cushioned

table or flat surface to protect the screen

from scratches.

ENGLISH

10 ASSEMBLING AND PREPARING

CAUTION

yDo not carry the TV upside-down as this

may cause it to fall off its stand, resulting in

damage or injury.

yThe illustration shows a general example of

installation and may look different from the

actual product.
