SIMPLE MANUAL
DVD Home
Theater
Please read this manual carefully before operating your set and retain it for
future reference.
To view the instructions of advanced features, visit
http://www.lg.com and then download Owner’s Manual.
Some of the content in this manual may differ from your unit.
MODEL
LHD687BG
ENGLISH FRANÇAIS PORTUGUÊS
LHD687-FC.DGHALLK_SIM_ENG_MFL71688103.indd 1 2020-02-22 1:55:04
Front Panel Rear Panel
MIC 1/2···················· Connect a microphone.
PORT. IN ··············Connect to a Portable device.
USB Port····················Connect a USB device.
R··························Disc Tray Open / Close
T·······················Starts / Pauses playback.
I·································Stops playback.
F············· Changes the input source or function.
- / +·······························Adjusts volume.
1/! ······························Power On / Off
Speaker design and connection method may
be different according to models.
,
Speaker Connection1
SPEAKERS ··················· Connect to speakers.
HDMI OUT TO TV··················· Connect to TV.
AUX (L/R) INPUT······ Connect to analogue device.
VIDEO OUT ························ Connect to TV.
OPTICAL IN ·············· Connect to digital device.
ANTENNA FM ·········· Connect to radio antenna.
Make sure to properly align and connect the
optical cable; improper alignment may cause
damage to the jack.
Unit
LHD687-FC.DGHALLK_SIM_ENG_MFL71688103.indd 2 2020-02-22 1:55:06
Home menu appears on the TV screen. Enjoy various
functions on the unit.
Home Menu
TV Connection2
HDMI & Optical Connection
aConnect the Unit to the TV using HDMI &
Optical cable.
bSet the input selector to HDMI on the TV.
cSet up [External Speaker (Optical)] on your
TV setting menu.
dFollow the instructions on the TV screen
using remote control.
3
For more information, download the online owner’s manual. http://www.lg.com
LG Sound Sync
(Wireless)
TV
LHD687-FC.DGHALLK_SIM_ENG_MFL71688103.indd 3 2020-02-22 1:55:07
Specication
Power
requirements Refer to main label.
Power
consumption Refer to main label.
Dimensions
(W x H x D)
Approx. 360 mm x 58 mm
x 298.5 mm
Bus Power Supply
(USB) 5 V 0 500 mA
Amplier
(Total RMS output
power)
1,250 W RMS
Design and specications are subject to change without
notice.
Replacement of battery
Additional Information
LHD687-FC.DGHALLK_SIM_ENG_MFL71688103.indd 4 2020-02-22 1:55:08
