LG HBM-560 Manual de usuario
FCC CONCERNS
RF Exposure Statement:
The antenna(s) used for this device must not be co-located or operating in conjunction
with any other antenna or transmitter.
Do not
Any changes or modifications to the equipment not expressly approved by
the party responsible for compliance could void user’s authority to operate
the equipment.
The LG Bluetooth® headset HBM-560 is a light weight wireless Headset
utilizing Bluetooth® technology.
This product can be used as an audio accessory for devices supporting
either the Headset or Handsfree Bluetooth® Profiles.
■Included in package
■Change direction
■Charging
- Remove the cover on the charging port and connect the charger.
- When the charger is connected, with power on or off, the headset will
turn off. While charging, the LED indicator will show a solid blue light.
- The buttons will not function while the device is charging.
- It takes 2 hours to fully charge the headset.
- When charging is complete, the LED indicator will turn off.
■Low battery
- The LED indicator will blink blue when the battery power is low.
- When the battery is not charged, the LED indicator will blink blue and
then turn off.
■Power on
- Press and hold the PWR/END button for 2 seconds.
●The headset will turn on and a booting tone will play.
■Power off
- Press and hold the PWR/END button for at least 2 seconds.
● A shutdown tone will play, the Bluetooth® link will disconnect, and the
headset will turn off.
■Pairing
- Prior to using the Headset for the first time, you must pair it with a
Bluetooth-enabled handset.
- Enter the pairing mode with pressing and holding the CALL button for 5
seconds.
● You will hear two short beeps and the LED indicator will show a solid
blue light, when the device enters Pairing Mode.
▶Using your Handset, find the Bluetooth® Menu and "search for" or
"add” new devices.
▶Select ”LG HBM-560” from the list of devices and pair it with your
handset.
▶When asked for the Pass/PIN code during the pairing procedure,
please enter “0000” (4Zeros).
● Once pairing has completed successfully, you will hear a beep.
▶After pairing successfully, be sure to “Connect” to the HBM-560.
● If you want to pair with other devices in the future, the headset must be
placed in Pairing Mode.
● If the HBM-560 is in "Pairing Mode" for 3 minutes, without being paired
to a device, the Headset will automatically turn off.
■Auto Reconnect
When the HBM-560 turns off accidentally or intentionally during connected
condition, the headset and handset will disconnect.
The Headset and handset will automatically reconnect without pairing
when the HBM-560 turns on. HBM-560 will enter the pairing mode if
there’s no device to connect (Easy Pairing)
[ Out of range ]
- When the HBM-560 and your handset are separated by a distance of 33
feet (10meters) or more, the headset and handset will disconnect. When
the handset and HBM-560 are brought back within the required distance,
the HBM-560 will automatically reconnect with the handset.
- If the headset and handset do not automatically reconnect when they are
back within the required range, briefly press the CALL button to reconnect
manually.
■Volume control
- Briefly press the VOLUME UP or VOLUME DOWN button to adjust the
speaker volume.
- There are eight levels of speaker volume.
■Answering a call
- When there is an incoming call, the Headset will ring.
- Briefly press the CALL button to answer an incoming call.
Making a call
- If you make a call from the Handset, the call will (subject to phone
settings) transfer automatically to the Headset. If not automatically
transferred, you can transfer the call manually by briefly pressing the
CALL button on the HBM-560 (headset and handset must be paired).
Voice dialing*
- Briefly press the CALL button. (You will get the best results if you record
the voice dialing tag through your Headset.)
NOTE : If the Handset does not support the Voice Dial, the Headset will
activate the last number redialing.
Last number redial*
- Press and hold the CALL button for 1second to activate "Last Number
Redial". The headset will beep, and call the last number dialed.
Ending a call
- Briefly press the CALL button.
Transferring a call*
- While on a call on your handset, briefly press the CALL button on the
HBM-560 to transfer the audio to the headset.(headset and handset must
be paired).
- And to transfer a call from the Headset to Handset, press and hold
VOLUME UP button for 5 seconds.
Call waiting*
- Answer a second call without hanging up the first call by pressing the
CALL button for 1seconds. Press the CALL button for 1seconds to return
to the original call.
- Briefly press the CALL button to terminate the active call.
Call reject*
Activate call reject by pressing the CALL button for 1 second when
receiving a call.
* It is possible to use these functions only when your Handset supports
them.
For further information about using these features please consult your
Handset's user manual.
Function HBM-560 Status Action
Power on Power off Press the PWR/END button for at
least 2 seconds
Power off Power on Press the PWR/END button for at
lea
Volume Up Talking Briefly press the Volume Up
button
Volume Down Talking Briefly press the Volume Down
button
Transferring a call Talking
- Handset to Headset
Briefly press the CALL button
- Headset to Handset
Press and hold the VOLUME
UP button for 5 seconds
Answering a call Ringing Briefly press the CALL button
Ending a call Talking Briefly press the CALL button
Call waiting Talking Press the CALL button for 1
second
Last number
redialing Idle Press the CALL button for 1
second
Voice dialing
(Handset must support) Idle Briefly press the CALL button
Call Reject Ringing Press the CALL button for 1
second
Pairing mode Power Off or Idle Press the CALL button for 5
seconds
