LG Digital Signage

(MONITOR SIGNAGE)

Affichage dynamique numérique LG

(MONITEUR DE SIGNALISATION)

Señalización digital de LG

(MONITOR SIGNAGE)

*MFL69460212*

AAA

(M3 x L6)

75UH5C 75UM3C

86UH5C

ENGLISH Easy Setup Guide

Please read this manual carefully before operating your set and retain it for future reference.

FRANÇAIS Guide de configuration rapide

Veuillez lire ce manuel attentivement avant d’utiliser l’appareil et conservez-le pour pouvoir vous y

reporter ultérieurement.

ESPAÑOL Guía Rápida

Lea atentamente este manual antes de poner en marcha el equipo y consérvelo para futuras

consultas.

Depending on country / Selon le pays / Segun el pais

English You can download the web manuals for this product at the

following websites. (Keyword : UH5C, UM3C)

Français Vous pouvez télécharger en ligne les guides pour ce produit à

partir des sites Web suivants. (Mots-clés : UH5C, UM3C)

Español Puede descargar los manuales web de este producto en los

siguientes sitios web. (Palabra clave : UH5C, UM3C)

•www.lg.com

English

Dimensions

(Width x Height x

Depth) / Weight

75UH5C

75UM3C

Head

1682 mm x 960 mm x 73.9 mm / 41.5 kg

(66.2 inches x 37.7 inches x 2.9 inches / 91.4 lbs)

86UH5C 1926.2 mm x 1097.2 mm x 78.3 mm / 49 kg

(75.8 inches x 43.1 inches x 3.0 inches / 108.0 lbs)

Français

Dimensions

(largeur x hauteur x

profondeur) / Poids

75UH5C

75UM3C

Écran 1 682 mm x 960 mm x 73,9 mm / 41,5 kg

(66,2 po x 37,7 po x 2,9 po / 91,4 lb)

86UH5C 1 926,2 mm x 1 097,2 mm x 78,3 mm / 49 kg

(75,8

x 43,1

x 3,0

/ 108,0

)

Español

Dimensiones

(ancho x alto x

profundidad) / Peso

75UH5C

75UM3C

Cabezal 1 682 mm x 960 mm x 73,9 mm / 41,5 kg

86UH5C 1 926,2 mm x 1 097,2 mm x 78,3 mm / 49 kg

Alimentación 75UH5C

75UM3C AC 100-240 V ~ 50/60 Hz 2,7 A

86UH5C AC 100-240 V ~ 50/60 Hz 3,5 A

AUDIO OUTDVI OUT
