LG VX6000 Guía de instalación

VX6000

1.9 GHZ PCS, 800 MHZ CDMA (ALL DIGITAL)

TRAINING MANUAL

PURE TECHNOLOGY

䡲Built-In Web Browser

䡲E911 Emergency Location

Capable

䡲Long Battery Life (3.8 hours

talk time, 6 days standby)

䡲27 Unique Ringers + Vibrate

䡲Productivity Tools: Calendar

with Scheduler, Alarm Clock

䡲Phone Book (199 Entries X 5)

REFRESHING STYLE

䡲Ultra Compact and

Lightweight (only 3.14 oz.)

䡲Two Stylish Colors: Silver

and Black Leather

SIMPLE

FUNCTIONALITY

䡲Two-Way Short Messaging

Service (SMS)

䡲Handy 4-Way Navigation Key

䡲External USB Capable

䡲Built-In Games: Mobile Hawk

and Black Jack

Navigation Key

Scrolls through

menus and

displays the next

or previous

message, entry

or item

Microphone

Self Portraiture Mirror

/Ringer Speaker

Ear Piece

Antenna

My Shortcut

Mobile Web

Messages

easyedgeSM

Indicator

Flashes for

incoming calls

or messages

Lock

Mode Key

Right Soft Key

SEND Key

Manner/

Silence All

Mode

Headset Jack

Provides

connection

for an optional

headset

VX6000

PRODUCT HIGHLIGHTS

END/PWR Key

Powers the

phone on or off,

ends a call or

returns you to

the main menu

Camera

Lens

Voice Dial

(not shown)

Clear Key

OEL Display

Camera

Left Soft Key

䡲Integrated CMOS Digital

Camera with Zoom, Multishot,

Resolution Adjustment, and

Self-Portrait Timer

䡲easyedgeSM Service to Access

Email and Download Pictures,

Ringers and Games*

䡲Multimedia Messaging Service

for Sending Photos with

Attached Messages*

䡲Sleek and Stylish Silver

Clamshell Design

䡲Innovative Rolling External

OEL Color Display and

Full-Color Internal LCD

䡲Customizable Caller ID,

Wallpaper, Power On/Power

Off Images

䡲Easy-to-Read Blue

Backlit Keypad

䡲Voice-Activated Dialing

(30 Entries)

䡲Speed Dialing (99 Entries)

䡲Large Phone Book capable of

storing up to 499 contacts

with up to 5 numbers and 3

email addresses per contact

䡲31 Caller ID Ringers plus

Vibrate and Silent Alert

䡲Two-Way Short Messaging

Service (SMS)

䡲And Much, Much More!!!

*US Cellular Service Required

Phone Book

The internal phone book is capable of storing up to 499 contacts with up to 5 numbers and 3

email addresses per contact.

Adding a New Phone Book Entry

1. From the Contacts (2) menu, select New Number (2).

2. Enter the telephone number for the entry and press .

3. Select a label (Home,Home 2,Ofﬁce,Ofﬁce 2,Mobile,Mobile 2,Pager,

Fax,Fax 2 or None) and press .

4. Enter a name for the entry and press .

5. To exit to the phone book press Left Soft Key for Done.

One-Touch Speed Dialing

One-Touch Speed Dialing: Enables you to dial 9 of your most frequently used numbers using a

single key press. These numbers are stored in your phone book in memory locations 1 through 9.

For locations 1 through 9, you can use one-touch dialing by pressing and holding the

corresponding key to the memory location to be dialed or press a digit, then press .

Two-Touch Speed Dialing: Enables you to dial numbers in your phone book through two keys

(for locations 10 to 99).

1. From the Contacts (2) menu, select Speed Dials (5).

2. Select or enter a slot number and press .

3. Select a name from the list using the Navigation Key and press .

4. Select the desired number and press .

Voice Dials

Allows you to view the list of numbers that have been programmed with voice dialing or add a

voice dial tag to a number in the phone book.

1. From the Contacts (2) menu, select Voice Dials (6).

2. Press Left Soft Key to select a number to add a voice dial tag to and press .

3. Record the voice dial tag by following the phone’s prompts.

Note: Recordings should be made in a quiet place using a clear voice. Hands-free car kits or

headsets should be avoided when recording.

Voice Dial Prompt

Allows you to set the command for voice dialing.

1. From the Settings (9) menu, select Voice Services (7).

2. Select Voice Dial Prompt (1) and press .

3. Select desired option (Key press,Flip open,orDisable) and press .

Enter Number

Cancel Pause

------------------------------

Alex

Christy

Cancel OptionsCancel Options

Please select

<OK> to start

recording.

1 OK

2Cancel

Voice Services

1 Voice Dial

2 Answering Mach...

3Train Words

Key press

USING PERSONAL INFORMATION

MANAGEMENT TOOLS

The Organizer

The Organizer menu allows you to view the calendar, schedule an event, program your

handset’s alarm clock, view and compose memos on the notepad, as well as record and play

back voice memos.

Scheduling an Event

1. From the Tools (8) menu, select Schedule (1).

2. Highlight the event date using your Navigation Key and press Left Soft Key to add

a new event.

3. You may set the appropriate start and end times, content, repeat (if any), alarm and

ringer by scrolling to the corresponding ﬁeld and entering the desired information and

pressing .

4. Press Left Soft Key to Save.

Scheduling an Alarm

1. From the Tools (8) menu, select Alarm Clock (2).

2. Select from the list of available alarms, Alarm 1 (1), Alarm 2 (2), Alarm 3 (3) or Quick

Alarm (4).

3. You may set the appropriate time, repeat (if any), and ringer by scrolling to the

corresponding ﬁeld and entering the desired information.

4. Press Left Soft Key to Save.

Recording a Voice Memo

1. From the Tools (8) menu, select Voice Memo (3).

2. Press Left Soft Key for New.

3. Start recording at the tone.

4. Press Left Soft Key for Done to stop recording. By default, your message will

be listed by date and time.

Composing a Notepad Memo

1. From the Tools (8) menu, select Notepad (5).

2. Press Left Soft Key to add.

3. Enter your memo using the keypad and press .

Call History

Call History automatically logs up to 30 numbers for each category of dialed, received, and

missed calls. It is continually updated as new numbers are added to the beginning of the list

and the oldest entries are removed from the bottom of the list.

Making a Call from Recent Calls

1. From the Recent Calls (3) menu, select Dialed Calls (1), Received Calls (2) or Missed

Calls (3) and press .

2. Place a call by selecting the desired entry and press to connect.

Note:To quickly access the list of recent calls press from the main menu.

Tools

1 Schedule

2Alarm Clock

3 Voice Memo

4 My Shortcut

5 Notepad

6 Ez Tip Calc

7 Calculator

Cancel

Please start

recording

after the tone.

Recent Calls

1Dialed Calls

2 Received Calls

3 Missed Calls

4 Erase Calls

5 Call Timer

CAMERA FEATURES

Taking a Photo

Self Timer

1. Press Left Soft Key and select Camera (1) menu.

2. Select Take Photo (1).

3. Press Right Soft Key for Options.

4. Select Self Timer (1).

5. Select 5 sec or 10 sec with the Navigation Key and press .

6. Press Left Soft Key for Start.

7. Press Left Soft Key for Save or press Right Soft Key for Reject.

Setting the Resolution

1. From the Camera (1) menu, select Take Photo (1).

2. Press Right Soft Key for Options.

3. Select Resolution (2).

4. Use the Navigation Key to change the resolution (Lo 160x120, Med 320x240, or

Hi 640x480), press .

Note: Regardless of camera resolution, the phone will store a maximum of 20 pictures.

Changing the Brightness

1. From the Camera (1) menu, select Take Photo (1).

2. Press Right Soft Key for Options.

3. Select Brightness (3).

4. Use the Navigation Key to change the brightness, press Left Soft Key for Done.

Changing the White Balance

1. From the Camera (1) menu, select Take Photo (1).

2. Press Right Soft Key for Options.

3. Select White Balance (4).

4. Use the Navigation Key to change the white balance (Auto,Sunny,Cloudy,

Tungsten, Fluorescent or Darkness), press Left Soft Key for Done.

Changing the File Quality

1. From the Camera (1) menu, select Take Photo (1).

2. Press Right Soft Key for Options.

3. Select File Quality (5).

4. Use the Navigation Key to change the ﬁle quality (Economy, Normal or High),

press .

Turning On/Off the Shutter Sound

1. From the Camera (1) menu, select Take Photo (1).

2. Press Right Soft Key for Options.

3. Select Shutter Sound (6).

4. Use the Navigation key to change the shutter sound (Shutter, Chime or No

Sounds), press .

We b

Camera

1Take Photo

2 0Gallery

3 Send Photo Msg

4 0 Photo Inbox

5 0 Photo Outbox

6 0 Photo Saved

7 Photo Settings

1 Self Timer

2 Resolution

3 Brightness

4 White Balance

5 File Quality

6 Shutter Sound

7 Color Effects

8 Fun Frames

Med 320x240 1X 1/30

Gallery Options

Med 320x240 1X 1/30

Shutter Sound

Shutter

Chime

No Sounds

Changing the Color Effects

1. From the Camera (1) menu, select Take Photo (1).

2. Press Right Soft Key for Options.

3. Select Color Effects (7).

4. Use the Navigation Key to change the color effects (Normal, Antique, Black &

White or Negative), press Left Soft Key for Done.

Fun Frames

1. From the Camera (1) menu, select Take Photo (1).

2. Press Right Soft Key for Options.

3. Select Fun Frames (8).

4. Use the Navigation Key to change the background options and press .

5. Press to take a picture.

6. Press Left Soft Key for Save or press Right Soft Key for Reject.

Taking Multiple Shots

1. From the Camera (1) menu, select Take Photo (1).

2. Press Right Soft Key for Options.

3. Select Multishot (9).

4. Use the Navigation Key to change the multishot options*, press .

5. Press Left Soft Key for Start.

6. Use the Navigation Key to scroll through the images, press Left Soft Key for Save

or press Right Soft Key for Reject.

* In low or medium resolution, a series of 5 or 3 shots can be taken. In high resolution,

a series of 2 shots can be taken.

Photo Gallery

Setting a Picture Display from Picture Gallery

Allows you to choose the kind of background to be displayed on the phone.

1. From the Camera (1) menu, select Gallery (2).

2. Use the or Navigation Key to select an image, press .

3. Press Right Soft Key for Options.

4. Select Set As (3).

5. Use the Navigation Key to set picture as Contacts,Wallpaper,Power On or

Power Off,press .

Renaming a Picture

1. From the Camera (1) menu, select Gallery (2).

2. Use the or Navigation Key to select an image.

3. Press Right Soft Key for Option.

4. Select Rename (6) to rename the image.

5. Erase the previous image name, enter the new image name and press to save.

Deleting a Picture Message

1. From the Camera (1) menu, select Gallery (2).

2. Use the or Navigation Key to select an image.

3. Press the Right Soft Key for Option.

4. Select Erase (7) to delete the image. A conﬁrmation window will appear stating that

the image will be erased from the gallery. Select either Erase (1) or Cancel (2).

We b

Gallery Options

Med 320x240 1X 1/30

Multishot

5 shots

3 shots

Camera

1 Take Photo

2 0 Gallery

3 Send Photo Msg

4 0 Photo Inbox

5 0 Photo Outbox

6 0 Photo Saved

7 Photo Settings

1 Send

2 Online Album

3 Set As

4 Enlarge

5 Lock

6 Rename

7 Erase

8 Erase All

Picture001 1/1

Changing the Backlight Timer

Allows you to select the duration the backlight is on for the displays.

1. From the Display (2) menu, select Backlight (2).

2. Select either Main LCD (1), or Front LCD (2).

3. Select Timer (1).

4. Press Navigation Key to select an option (7 seconds,15 seconds,30 seconds,

Always off,orOn ﬂip open for Main LCD or 5 seconds,1 minute or 3 minutes for the

Front LCD) and press .

Changing the Font Size and Color

Allows you to choose the size and color of the number and text input font.

1. From the Display (2) menu, select Fonts (7).

2. Select Calling Digits (1), or Text Editor (2).

3. Select Size (1), or Color (2).

4. Press Navigation Key to select the size or color of the text and press .

Power Saver

Sets the time duration for keeping LCD turned on.

1. From the Display (2) menu, select Power Saver (9).

2. Press Navigation Key to select an option (2 min,10 min,30 min,Always on) and

press .

Status Light

Notiﬁes you that your phone is working properly. Indicator lamp blinks every 10 minutes if

phone operates under normal conditions.

1. From the Display (2) menu, select Status Light (0).

2. Press Navigation Key to select an option (On or Off) and press .

OTHER NOTABLE SETTINGS

Manner Mode

Use Manner Mode in a public place to disable the ringer and activate Vibration Mode.

1. In the standby mode, activate Manner Mode by pressing the key or the Manner

Mode Key (for 3 seconds) - the phone will vibrate when activated.

2. When set -Manner Mode- will appear on the screen.

3. To release Manner Mode, press the key again; Silence All is activated.

Press the key again until -Normal Mode Activated- is displayed.

Silence All Mode: when activated there are no tones from the keys, and the ringer

does not sound but the alert indicator blinks instead.

Programming the Short Cut Key

1. From the Tools (8) menu, select My Shortcut (4).

2. Select your most frequently used function from the list provided and press .

3. Shortcut: Pressing the Navigation Key while in standby mode will quickly access this

function.

shift

Main LCD

1 Timer

2 Brightness

30 Seconds

Menu Contacts

–Manner Mode

Manner Mode

–

Thu, July 26 9:54am

–Manner Mode–

Thu, July 26 9:54am

Tools

1 Schedule

2 Alarm Clock

3 Voice Memo

4My Shortcut

5 Notepad

6 Ez Tip Calc

7 Calculator

Jul, 2003

Su Mo Tu We Th Fr Sa

1 2 3 4 5 6

78 9 10 11 12 13

14 15 16 17 18 19 20

21 22 23 24 25 26 27

28 29 30 31

Add Options

shift

Photo Outbox

View a Saved Picture Message from Photo Outbox

1. From the Camera (1) menu, select Photo Outbox (5).

2. To select a picture message, scroll down with the Navigation Key, then press

to view the picture message.

Resending from the Photo Outbox to Other Recipients

1. From the Camera (1) menu, select Photo Outbox (5).

2. Select a picture message from the Outbox list and press Left Soft Key for Send to.

3. Press Left Soft Key for Contact (1), Online Album (2), or Recent Call (3), to select

a recipient.

4. Press Left Soft Key to send.

Deleting from the Outbox

1. From the Camera (1) menu, select Photo Outbox (5).

2. Use the Navigation Key to select the desired picture message, then press .

3. To delete a picture message from the outbox, press Right Soft Key for Options.

4. Select Erase (3). Select Erase (1) again to conﬁrm.

Resending from Photo Saved

1. From the Camera (1) menu, select Photo Saved (6).

2. Use the Navigation Key to select the desired message.

3. To view the highlighted saved picture message press .

4. If pix is saved from the Inbox, press Left Soft Key for reply, select Photo Msg (1) or

Text Only (2).

5. If pix is saved from the Outbox, press Left Soft Key for Resend.

Photo Settings

Setting the Photo Msg Alert

Set an alert to indicate a photo msg has been delivered to you.

1. From the Camera (1) menu, select Photo Settings (7).

2. Select Photo Msg Alert (4).

3. Use the Navigation Key to select from Silent,Vibrate Once,Vibrate and Sound,

Custom Ring Tone,Low Beep Once,Low Beeps,Loud Beep Once,orLoud Beeps and

press .

Text Entry Mode

Allows you to automatically set the text when sending a pix msg.

1. From the Camera (1) menu, select Photo Settings (7).

2. Select Text Entry Mode (5).

3. Use the Navigation Key to select from T9 Word,Abc,or123 and press .

Quick-Text

Allows you to automatically set the text when sending a picture message.

1. From the Camera (1) menu, select Photo Settings (7).

2. Select Quick-Text (7).

3. Select Left Soft Key to Add New.

4. Enter a custom text message. Press to save message.

Camera

1 Take Photo

20Gallery

3 Send Photo Msg

4 0 Photo Inbox

50Photo Outbox

6 0 Photo Saved

7 Photo Settings

Family

Send to Options

Camera

1 Take Photo

2 0Gallery

3 Send Photo Msg

4 0 Photo Inbox

5 0 Photo Outbox

60 Photo Saved

7 Photo Settings

CONNECTIVITY FEATURES

Downloading easyedgeSM Content

The new VX6000 by LG can store up to 1.5 Mb of content from easyedge, a service that

allows you to access your email and download pictures, ringers and games to your phone.

Note: 1.5 Mb of memory is allocated for easyedge content. Camera memory is separate and

will not affect easyedge memory capacity.

Downloading New Content from easyedge

(Instant Messaging, Games, Ofﬁce Applications, etc.)

Apps

1. Press Soft Key 1.

2. Select easyedge (5).

3. Select Apps (1). Main display of easyedge will appear, press .

4. Select icon and press .

5. Select either Start or Options and press .

Start allows you to download selected applications while displaying the easyedge

application list relayed from the easyedge server in connection.

Options allows you to display download log and the current memory capacity of your

mobile phone.

- Information: displays usable capacity for your mobile phone and the memory

capacity in use.

- View Log: displays easyedge version, MSM Chip, and downloading record.

6. Shortcut: Press the on the navigation key while in standby mode to quickly

start easyedge.

Help

1. Press Soft Key 1.

2. Select easyedge (5) .

3. Select Help (2).

This submenu gives you information about the easyedge selection key.

Accessing the Web

The new VX6000 is enabled by the Openwave UP 4.1 Browser to access the Web.

1. From the Web (6) menu, select Start Browser (1).

2. A reminder of the charge will appear; select Yes (1) to launch MiniBrowser, if required.

After a few seconds, you will see the Home Page.

3. You can end a MiniBrowser session by pressing .

4. Shortcut: Press the on the Navigation Key while in standby mode to quickly launch

the Browser.

Messages

Send New

Allows you to send text messages and emails.

1. From the Messages (4) menu, select New Message (2).

2. Press Left Soft Key for Contacts to select pre-programmed recipient or select Address

and enter an email address or phone number and press .

3. Select Message and press .

4. Enter a custom text message, up to 160 characters. Press to complete the message.

5. Press Right Soft Key and select Send from the menu.

We b

easyedge

1Apps

2 Help

Mobile Web

1Start Browser

2 Web Messages

3 Web Settings

CUSTOMIZABLE FEATURES

Changing the Sound Settings

Selecting a Built-in Ringer

1. From the Settings (9) menu, select Sounds (1).

2. Select Ringers (1).

3. Select Caller ID (1), No Caller ID (2) or Restrict (3).

4. Choose from the list of available default ringers and press .

Note: The ringer list includes both downloaded and default ring tones. Downloaded ringers

will be indicated by all lower case names while default ringers will have the ﬁrst letter of

their name capitalized.

Changing the Display Settings

Changing the Banner

Allows you to enter a string of characters (up to 16) to be displayed on the LCD screen.

1. From the Settings (9) menu, select Display (2).

2. Select Banner (1).

3. For actions, press Right Soft Key:T9Word (1), Abc (2), 123 (3), Symbols (4), or Smiley (5).

4. Enter the desired greeting and press .

Changing the Screen Display Image

Allows you to choose the kind of background to be displayed on the phone.

1. From the Display (2) menu, select Screens (3).

2. Select Wallpaper (1), Power On (2) or Power Off (3).

3. Select from the list of seven default images, press to save.

4. For More images, press Right Soft Key:Default (1), Graphics (2), Gallery (3).

Changing the Menu Style

Allows you to choose whether you want the menu to show as a list or as icons.

1. From the Display (2) menu, select Menu Style (4).

2. Select either Icon or List and press .

Changing the Theme Color

Allows you to choose the color of the background screen.

1. From the Display (2) menu, select Theme Colors (6).

2. Press Navigation Key to select desired option (Default,Green,Violet or Orange)

and press .

Changing the External OEL Display Pattern

Allows you to choose different patterns for the external OEL display.

1. From the Display (2) menu, select Backlight (2).

2. From the Front LCD (2) menu select Patterns (2).

3. Select Incoming Calls (1), Missed Calls (2), New SMS Alert (3), Reminders (4)

or Standby (5).

4. Press Navigation Key to select desired pattern (Pattern0 (1), Pattern1 (2), Pattern2

(3), Pattern3 (4), Pattern4 (5)) and press .

Settings

1Sounds

2 Display

3 System

4 Security

5 Call Setup

6 1x Data

7 Voice Services

Banner

Cancel T9Word

------------------------------

Display

1 Banner

2 Backlight

3 Screens

4 Menu Style

5 Clocks

6 Theme Colors

Icon

Otros manuales para VX6000

Tabla de contenidos

Manuales populares de Teléfono móvil de otras marcas

Zte

Zte BLADE A520 Manual de usuario

Nokia

Nokia Lumia 620 Manual de usuario

Blackbe;rry

Blackbe;rry KEYone Manual de usuario

Bea-fon

Bea-fon X5 Premium Manual de usuario

Blackbe;rry

Blackbe;rry 8707 Series Manual de usuario

Blackbe;rry

Blackbe;rry Storm Instrucciones de funcionamiento

LifeWatch

LifeWatch V Manual de usuario

Bea-fon

Bea-fon SILVER LINE SL860 Manual de usuario

IKI Mobile

IKI Mobile KF4.5i Manual de usuario

Hitech

Hitech HT-850 Manual de usuario

Yezz

Yezz Fashion F10 Manual de usuario

Point Mobile

Point Mobile PM60 Manual de usuario

Blackbe;rry

Blackbe;rry Q10 Manual de usuario

Blackbe;rry

Blackbe;rry Bold 9900 Manual de usuario

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Manual de usuario

ISAFE MOBILE

ISAFE MOBILE IS655.2 Manual de usuario

Blackbe;rry

Blackbe;rry CURVE 8300 - SMARTPHONE Manual de usuario

Blackbe;rry

Blackbe;rry 8707 - VERSION 4.1 Manual de usuario
