LG VOYAGER Manual de usuario

TOUCH SCREEN MULTIMEDIA PHONE with QWERTY KEYBOARD

Quick Start Guide

Voyager™ is a trademark of Plantronics, Inc. used under license by Verizon Wireless.

Getting to Know Your Phone

Camera/

Video Key

Headset Jack

Volume

Up/Down

Unlock Key

microSD™ Port

BACK SIDE FRONT SIDE LEFT SIDE RIGHT SIDE

Camera

Clear/Voice Command/

Voice Memo Key

Send

Key

Touch Screen

(Adaptive Menu

Interface)

Power/End Key

Retractable

TV Antenna

USB/

Charging Port

Message Phone Menu Contacts

Touch Soft Keys:

Steps in this guide are shown using the touch screen. Refer to the User Guide for more details.

QWERTY Keyboard

Web* Right Soft Key

Left Soft Key

Speakerphone Key

OK Key

Send Key

Power/End Key

Function Key*

(Shortcut Menu)

Shift (Caps) Key

Symbols Key

Space Key

Space/Voice Command/

Text to Speech Key

Vibrate

Mode Key Clear & Back KeyEnter KeyGame Navigation Keys

Navigation Key*

Web

Calendar

Media Center

Picture & Video

*Customizable

Speakers

Touch Protection

The touch screen is automatically locked

when the phone is closed or after the phone

is inactive for 14 seconds (default).

Unlocking the Touch Screen

• Tap the Unlock icon .

– or –

• Slide the Unlock Key on the left side

of the phone down.

Using the Touch Screen

• Use the tip of your nger to touch the center of a touch key.

• It’s not necessary to press hard. A light tap will do.

• Press and drag your nger up or down to scroll.

• A beep will sound when you’ve reached the top or bottom of a menu.

• Press the Power/End Key at any time to return to the idle screen.

Touch Screen Settings

• Tap the Menu icon , Settings & Tools, and then scroll down to

Touch Settings (8) to adjust the touch screen’s auto-lock feature,

vibration, sound, and calibration.

• If the touch screen is not responding as you expect, calibrate the

screen for increased accuracy.

Using the Touch Screen

Calling Someone in Your Contacts List

1. Unlock the phone.

2. Tap the Contacts icon , use the Quick Jump

bar (if needed), and then choose a contact.

3. Tap the phone number you want to dial.

Dialing a Call

1. Unlock the phone.

2. Tap the Phone icon and then use the

virtual keypad to enter a phone number.

3. Tap Call or press the Send Key.

Checking Voicemail

1. Unlock the phone.

2. Tap the Phone icon , then tap and hold .

3. When prompted, enter your password.

Answering Calls

Press the Send Key or tap the Unlock icon

followed by Answer.

Making & Answering a Call

Note: If the phone is ringing or vibrating,

press the Volume Keys to quiet the phone.

Vibrate

Mode

Voicemail

Quick Jump Bar

Subscribing & Watching TV

1. Unlock the phone. Tap the center of the touch screen to access

the Shortcut Menu and then tap Mobile TV .

2. Rotate the phone clockwise.

3. An introductory video clip will play (for the rst time).

4. Tap Subscribe Now. Review the base package and tap Continue.

5. Read the Terms and Conditions and tap Agree. Conrm your

selection and tap Submit.

6. From the V CAST screen, tap the Program Guide icon in the

top left corner. Tap the name of the show you want to watch.

Pull out the TV antenna for enhanced TV reception.

Scroll Up

Scroll Down

Scroll Forward

Back

Info

Options

Scroll Back

1. Unlock the phone.

2. Tap the center of the touch screen to access the Shortcut Menu.

3. Tap Browser .

4. Rotate the phone clockwise.

5. Choose a category or tap WWW to go to a specic web site. Tap

the Touch Here eld and enter the URL using the virtual keyboard.

6. On a web page, drag up or down to scroll, or tap on a section of

the thumbnail for a quick jump.

Browsing the Net

To activate the thumbnail feature:

Tap Menu > Settings (9) > Display (2) > Thumbnail (1) > On or Auto.

Back Refresh Home Zoom Favorites Thumbnail

Note: The browser supports full-screen mode, sending URLs via text messages,

an auto-complete feature, and Spanish input for text and browser searches

(other than URLs).

Getting Music

1. Unlock the phone.

2. Tap the center of the touch screen to access the Shortcut Menu.

3. Tap My Music .

4. Rotate the phone clockwise.

5. Tap Shop to access V CAST Music with Rhapsody.

6. Select a song from one of the categories. To purchase it, tap Buy.

7. Tap Buy This Song to conrm your purchase.

8. Tap Download Now to download the song. You can save songs to

the phone or an optional microSD card. Downloaded songs can be

accessed through My Music.

Note: Refer to the User Guide or Quick Reference Guide for instructions on

how to sync music from your PC to the phone.

1. Unlock the phone.

2. Tap the center of the touch screen to access the Shortcut Menu.

3. Tap My Music .

4. Rotate the phone clockwise.

5. Select a song from one of the categories to play.

6. Use the Volume Keys to adjust the volume when a song is playing.

7. Press the Power/End Key to exit the music player.

Playing Music

Repeat

Shufe

Previous/Rewind

Volume Down

Back

Options

Play/Pause

Next/Fast Forward

Volume Up

Note: When the ip is closed, if you answer a call while playing music, browsing

the net, watching TV/video, or using VZ NavigatorSM and then end the call by

pressing the End Key, the touch screen will lock. You can unlock the phone by

sliding the Unlock Key down.

Taking a Picture/Recording a Video

1. Unlock the phone.

2. To activate camera mode: Press the Key located on the left

side of the phone.

To activate video mode: Press and hold the Key.

3. Rotate the phone clockwise.

4. Use the Volume Keys to zoom.* Tap Options to adjust other

camera/video options.

5. Press the Key to take a photo or record a video.

6. You can save, send, or erase the photo/video.

*Camera setting of 1600x1200 pixels does not support zoom function.
