LG LW690 Manual de usuario

P/NO : MFL67142201(1.1)

LG-LW690

Printed in Korea

LG and the LG logo are registered trademarks of LG

Group and its related entities. All other trademarks are the

property of their respective owners.

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

The Basics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Connecting to Networks and Devices . . . . . . . . . . . . . . . . .27

Placing and Receiving Calls . . . . . . . . . . . . . . . . . . . . . . . .37

Web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43

Communication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50

Entertainment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73

Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .84

Important Health Information and Safety Precautions . . .90

Technical Details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .94

Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .97

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .114

FAQ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .116

LIMITED WARRANTY STATEMENT . . . . . . . . . . . . . . . .127

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .131

Contents

NOTE

The user interface of Google applications (Google Search, Google Maps,

Navigation, etc.) can vary depending on its software version.

WARNING

With the Android operating system, some available Market applications only operate

correctly with phones that have a specific screen resolution. Please be advised that some

of the applications on the Android Market maynot be available for your phone due an LCD

resolution requirement that does not match your phone. In addition, please be aware that

3rd party applications with programming defects may cause issues with your phone,

including lockups and resets.

2The Basics

Proximity Sensors

senses proximity towards other objects (such as your head) so that

touch commands arenotaccidentally activated during a call.

Note *Do notblock the sensor or near the sensor area with a film cover or phone case.

*The use of a film cover produced by other manufacturers other than LG can

cause a disturbance in touch operation, the display, etc.

Quick Keys

Phone Key opens the Phone Application for access to the dialpad, Call log, Contacts,

and Favorites.

Contacts Key opens the Contacts Application.

Messaging Key opens the Messaging Application.

-Browser

Key opens the Browser Application.

Menu Key

Opens an options menu with options that affect the current screen or

application.

Home Key

returns to the Home screen. If you're already viewing one of the Home screen

extension panes, it navigates you to the central Home screen pane. Press and hold to view

the most recently used applications.

5. Power/Lock

Key

locksthe screen. Press and hold to open the phone options menu for the

following options: Silentmode, Airplane mode, and Power off.

Earpiece

letsyou hear callers and automated prompts.

Touchscreen

displaysall the information needed to operate your phone, such as

applications, call status, date, time, signal status, and battery strength.

Phone Overview

Front View

Proximity

Sensors

Menu Key

Quick Keys

-Phone Key

-Contacts Key

-Messaging Key

-Browser Key

Home Key

Earpiece

Power/Lock Key

Touchscreen

Search Key

Back Key

Applications

Launcher Key

The Basics

11.

Volume Keys

allow you to adjust the ringer and media volumes or to adjust the in-call

volume during a call.

12.

Camera Key

activates the camera. Once the Camera function is open, you can access the

Video recorder function as well.

13.

3.5mm HeadsetJack

allowsyou to plug in an optional headset for convenient, hands-free

conversations. The 3.5mm jack also allows you to plug in headphones to listen to music.

14.

Camera Lens

use for taking pictures and recording videos. Keep clean for optimal

performance.

15.

Back Cover

encloses the battery compartment.

16.

Microphone

transmits your voice to the other caller and to Voice-activated functions.

17.

Accessory/Charger Port

allowsyou to connect the phone charger, USB cable, or other

compatible accessories.

Rear View

3.5mm Headset

Jack

CameraLens

Back Cover

Microphone

Accessory/

Charger Port

Applications Launcher Key

opens the Launch screen, where you can view installed

applications.

Search Key

opens the Quick Search Box

from the Home screen to search the phone

and the web. In many applications, you may press this key to search within the application

itself. Touch and hold to open Google search by voice.

10.

Back Key

returns to the previous screen. Also closes pop-up display items such as menus

and dialog boxes.

Camera Key

Volume Keys

Installing the Battery and microSD Card

NOTE

It is important to fully charge the battery before initial use of the phone.

1. Hold the phone with both hands and use the fingertip cutout at

the top of the phone to pull open the battery cover.

2. Use the fingertip cutout in the battery compartment to lift the

bottom edge of the battery out.

3. Locate the microSD card slot. Slide the slot protection upwards

to unlock it and flip it up to open it. Then insert the memory card

into the slot, making sure the gold contact area is facing

downwards. Flip the slot protection down and slide it downwards

to lockit.

NOTE

The microSD card can be easily damaged by improper operation. Please be

careful when inserting, removing or handling it.

4. Align the battery contacts with the terminals at the top of the

battery compartment, then press the battery into place.

5. Replace the battery cover over the back of the phone. Apply a

steady downward pressure until it clicks into place.

WARNING!

On the Android OS 2.2.1 operating system, you can download applications

from Android Market and can store them on your microSD card as well as

on the device. Due to this feature, if you skip the unmount procedure, it

can cause an error because information between the microSD card and the

device is accorded improperly.In the worst case, the microSD card can be

corrupted or damaged.

The Basics

Charging the Phone

Your LG Optimus C comes with a wall/USB charger and a USB

cable which connect together to charge your phone. To charge your

phone:

NOTICE

Please use only an approved charging accessory to charge your LG phone.

Improper handling of the accessory/charger port, as well as the use of an incompatible

charger, may cause damage to your phone and void the warranty.

1. Connect the USB cable into the wall/USB charger. When

connecting, as shown, the LG logo on the USB cable should

face toward you.

2. Plug the USB cable (as shown below) into the phone's

accessory/charger port.

Charging with USB

You can use your computer to charge your phone. To be able to

charge with the USB cable, you need to have the necessary USB

drivers installed on your PC first. Connect one end of the USB

cable to the accessory/charger port on your phone and connect

the other end to a USB port on your PC. It is best to use the rear

USB port when connecting to a desktop PC. The USB hub should

be powered by an external power source.

NOTES

●

Low-power USB ports are not supported, such as the USB port on your

keyboard or bus-powered USB hub.

USB Cable

Wall/USB charger

Optimizing Battery Life

You can extend your battery's life between charges by turning off

features that run in the background. You can also monitor how

applications and system resources consume battery power.

To check the battery charge level

©From the Home screen, press the Menu Key and touch

Settings > About phone > Status.

The battery status (charging or discharging) and level (as a

percentage of fully charged) will be displayed at the top of

the screen.

Tomonitor and control what uses the battery

The Battery use screen allows you to see which applications are

consuming the most battery power. Information on this screen

allows you to identify downloaded applications you may want to

turn off when not being used, so you can get the most out of your

battery power.

©From the Home screen, press the Menu Key and touch

Settings > About phone > Battery use.

©Touch an application in the Battery use screen to see the

details about its power consumption.

To change your phone settings

©From the Home screen, press the Menu Key ,then

touch Settings.You can change all your phone settings from

here.

The Basics

Turning the Phone On and Off

Turning the phone on

©Press and hold the Power/Lock Key for a couple of

seconds until the LCD screen turns on.

NOTE

When you turn on your phone for the first time, follow the instructions on

the screen to activate your device.

Turning the phone off

1. Press and hold the Power/Lock Key until the pop-up

menu appears.

2. Touch Power off in the pop-up menu.

3. Touch OK to confirm that you want to turn off the phone.

Tounlock the phone

If you don

’

tuse the phone for a while, the screen and backlight

will shut off to conserve battery power. To unlock the phone:

1. Press the Power/Lock Key .

Your Lock Screen will appear.

2. Touchand drag the Unlock icon to the right.

The last screen you were working on opens.

NOTE

This is the default Lock Screen. If you have set up an

Unlock Pattern, use your fingertip to draw the

pattern. If a PIN or Password is set, enter it.

To turn the phone sounds off

If you're in a place where your phone sounds may disturb others,

you can quickly silence your phone from the lock screen.

1. Press the Power/Lock Key .

2. Drag the Sounds off icon to the left.

To turn the phone sounds back on, drag the Sounds on icon

to the left.

Creating a Google Account

Your Google Account

You must create and/or sign into a Google Account to use GmailTM,

Google TalkTM,Google CalendarTM,and other Google Apps; to

download applications from Android MarketTM;to back up your

settings to Google servers; and to take advantage of other Google

services on your device.

If you don’t have a Google Account, you will be prompted to create

one. If you have an enterprise account through your company or

other organization, your IT department may have special instructions

on howto sign into that account.

1.From a computer, or from your device's browser, navigate to

www.google.com.

2. On the main page, select Sign in > Create an account now.

3. Follow the onscreen prompts to create your free account.

4. Log into your provided email address, locate the email from

Google, and respond to the new email to both confirm and

activate your new account.

8The Basics

Otros manuales para LW690

Este manual sirve para los siguientes modelos

Tabla de contenidos

Manuales populares de Teléfono móvil de otras marcas

Zte

Zte BLADE A520 Manual de usuario

Nokia

Nokia Lumia 620 Manual de usuario

Blackbe;rry

Blackbe;rry KEYone Manual de usuario

Bea-fon

Bea-fon X5 Premium Manual de usuario

Blackbe;rry

Blackbe;rry 8707 Series Manual de usuario

Blackbe;rry

Blackbe;rry Storm Instrucciones de funcionamiento

LifeWatch

LifeWatch V Manual de usuario

Bea-fon

Bea-fon SILVER LINE SL860 Manual de usuario

IKI Mobile

IKI Mobile KF4.5i Manual de usuario

Hitech

Hitech HT-850 Manual de usuario

Yezz

Yezz Fashion F10 Manual de usuario

Point Mobile

Point Mobile PM60 Manual de usuario

Blackbe;rry

Blackbe;rry Q10 Manual de usuario

Blackbe;rry

Blackbe;rry Bold 9900 Manual de usuario

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Manual de usuario

ISAFE MOBILE

ISAFE MOBILE IS655.2 Manual de usuario

Blackbe;rry

Blackbe;rry CURVE 8300 - SMARTPHONE Manual de usuario

Blackbe;rry

Blackbe;rry 8707 - VERSION 4.1 Manual de usuario
