LG GX200 Manual de usuario

www.lgmobile.com P/N : MMBB0360105 (1.0)

GX200

Some of the contents in this

manual may differ from your

phone depending on the

software of the phone or

your service provider.

E N G L I S H

fgUnh

Bluetooth QD ID B016135

GX200 User Guide - English

This guide will help you understand your new mobile phone. It will

provide you with useful explanations of features on your phone.

Some of the contents in this manual may differ from your phone

depending on the software of the phone or your service provider.

When you subscribe to a cellular network, you are provided with a SIM

card loaded with your subscription details, such as your PIN, any optional

services available and many others.

Important! ›The SIM card and its contacts can be easily damaged by

scratches or bending, so be careful when handling, inserting or

removing the card. Keep all SIM cards out of the reach of small

children.

›USIM is not supported in this phone.

Illustrations

1 Open the battery cover

2Insert your SIM card

3 Close the battery cover

4Charge your battery

Fully Charge the battery before using it for the rst time

Installing the SIM Card and Charging the Battery

SIM

Left soft key and Right soft key:

Each of these keys performs the

functions indicated by the text on

the display immediately above them.

Send Key: You can dial a phone

number and answer incoming calls.

End/ Power on key: Allow you to

power the phone on or off, end calls,

or return to Standby Mode.

Navigation key: Use for quick access

to phone functions.

Alphanumeric keys: Dial a number

in standby mode and input numbers

or characters in edit mode.

MicroSD slot

Volume key

Charger port/

Micro USB port/

Earphone jack

Wrist strap eyelet

Earpiece

SIM1 LED Indicator

Main display

Left soft key

Send Key

Alphanumeric

keys

SIM2 LED Indicator

Navigation key

Right soft key

End/Power on key

Phone Components

Dual SIM key

Icon Description

Tells you the strength of

the network signal.

Bluetooth connectivity is

powered on.

Your phone is locked.

The alarm clock is set.

Roaming sevice is used

Indicates new text

message(s).

The normal profile is

activated.

Icon Description

The silent profile is

activated.

The outdoor profile is

activated.

The flight mode profile is

activated.

The headset setting is used.

Indicates the battery

charge level.

On-Screen Icons

ed.

Turning Your Phone On and O

1Hold down the [End] key until the phone switches on.

2To switch the phone off, hold down the [End] key until the power-

off image displays.

Making a call

1In the standby mode, enter the area code and the phone number.

2Press the [Send] key to call the number.

Answering a call

1Press the [Send] key to answer the call when the phone rings.

2If the Any Key menu option has been set, any key press will answer a

call except for the [End] key or the right soft key.

Making an international call

1In the standby mode, long press the 0 key until a + (international prefix

character) sign is displayed.

2Enter the country code, the area code, and the phone number.

3Press the [Send] key to call.

Activating and switching SIM cards

Your phone supports the Dual SIM cards mode, enabling you to use two

SIM cards at the same time without changing them. When there are two

SIM cards installed, you can activate one of two or both SIM cards. The

SIM Switching function allows you to select the default SIM card for call or

message in Contact, Call logs and Message box.

1Select [Settings] from the main menu, and then select [Dual SIM].

2Select [SIM Switching] to set the switching mode.

•Auto: SIM card is switched automatically.

•User setting: Use the up and down navigation key to set Default calling

by and Default messaging by.

Use the left and right navigation key to switch the SIM card you want

to assign and press [Options] to save your desired setting.

Note:

If there is only one SIM card installed, this SIM card would be activated as

default.

Entering Text

You can enter alphanumeric characters by using the keypad. To change

modes, press the key.

let

dic

T9 Mode

This mode allows you to enter words with only one keystroke per

letter. Each key on the keypad has more than one letter. The T9 mode

automatically compares your keystrokes with an internal linguistic

dictionary to determine the correct word, thus requiring far fewer

keystrokes than the traditional ABC mode. The input method is display at

the upper right corner of your phone.

Indicator Function (English

Smart mode)

T9 Smart Abc

T9 Smart abc

T9 Smart ABC

Numeric

Indicator Function (English

Smart mode)

Multitap Abc

Multitap abc

Multitap ABC

FM Radio (This function may be dierent in

dierent regions.)

1Select [Multimedia] from the main menu, and then select [FM radio].

2Use the navigation key to search for radio channels. You can also press

[Options] and select [Preset auto search] to automatically search for

available radio channels.

3Press [Options] to edit the channel list. Your phone provides the

following options for FM radio:

•Channel list: Bookmark up to 9 radio channels by entering the channel

name and frequency.

• Manual input: Key in the radio channel frequency manually.

• Preset auto search: Automatically search for available radio channels

and store them to the channel list.

FM Radio (This function may be dierent in

dierent regions.) (Continued)

• Settings: Change the background play, the skin of FM radio, the switch

of loud speaker, the record format as AMR,AWB or WAV, the audio

quality, an d the record storage.

• Record: Record your favorite radio programs.

• Append: Resume t he previous recorded file and continue to record at

the same file.

• File list: Manage the previous recorded files.

Anti-theft mobile tracker[ATMT]

1The ATMT function provides you with the ability to have a tracking

system in place for your phone incase you lose or misplace it.

2When an unauthorized person uses your phone, a SMS is triggered

from your phone and the message is sent to your pre-defined phone

number.

3You can set the ATMT function by the following steps:

•Select [Settings] from the main menu, and then select [Security].

• Select [Anti-theft mobile tracker]

• Set ATMT and select ON

• Enter default ATMT code

Note:

› In case you want to use your phone with some other SIM card, make sure

to set the ATMT OFF.

› It is recommended to enter the Number for ATMT with the country code

(e.g. for INDIA +91 followed by phone number)

› Default ATMT code is “0000”.
