Lexmark T640rn Manual de usuario

T640rn

User's Guide

June 2006 www.lexmark.com

Lexmark Confidential until announced

Lexmark and Lexmark with diamond design are trademarks of Lexmark International, Inc., registered in the United States and/or other countries.

All other trademarks are the property of their respective owners.

740 West New Circle Road

Lexington, Kentucky 40550

Safety information

Connect the power supply cord to a properly grounded electrical outlet that is near the product and easily accessible.

Connect the power supply cord to an electrical outlet that is near the product and easily accessible.

Refer service or repairs, other than those described in the user documentation, to a professional service person.

This product is designed, tested, and approved to meet strict global safety standards with the use of specific Lexmark components. The safety features of

some parts may not always be obvious. Lexmark is not responsible for the use of other replacement parts.

CAUTION: Make sure that all external connections (such as Ethernet and telephone system connections) are properly installed in their marked plug-

in ports.

This product uses a laser.

CAUTION: Useofcontrolsoradjustmentsorperformanceofproceduresotherthanthosespecifiedhereinmayresultinhazardousradiationexposure.

This product uses a printing process that heats the print media, and the heat may cause the media to release emissions. You must understand the section

in your operating instructions that discusses the guidelines for selecting print media to avoid the possibility of harmful emissions.

This product uses a printing process that produces ozone. You must understand the section in your operating instructions that discusses the precautions

to take to limit ozone concentration.

This product contains mercury in the lamp (<5mg Hg). Disposal of mercury may be regulated due to environmental considerations. For disposal or recycling

information, contact your local authorities or the Electronic Industries Alliance: www.eiae.org.

This symbol indicates the presence of a hot surface or component.

CAUTION: To reduce the risk of injury from a hot component, allow the surface to cool before touching.

Lexmark Confidential until announced

Contents

Introduction...........................................................................................................................5

Overview of Radio Frequency Identification (RFID)....................................................................................5

Choosing an output device..........................................................................................................................5

Preparing to print..................................................................................................................6

Loading RFID labels....................................................................................................................................6

Printing...................................................................................................................................8

Printing on labels of different sizes..............................................................................................................8

Identifying rejected labels............................................................................................................................8

Understanding the RFID menu.............................................................................................9

Configuring RFID-specific settings..............................................................................................................9

Understanding RFID printer messages.............................................................................11

RFID error messages................................................................................................................................11

RFID service messages.............................................................................................................................12

Notices.................................................................................................................................13

Power consumption...................................................................................................................................15

Index.....................................................................................................................................18

Lexmark Confidential until announced

Contents

Lexmark Confidential until announced

Introduction

Overview of Radio Frequency Identification (RFID)

Radio Frequency Identification (RFID) is an automatic identification method that relies on storing and retrieving data using

RFID tags. The tags, which are incorporated into labels, receive and respond to radio-frequency queries from an RFID

transceiver. This tag support lets you print on labels and simultaneously program embedded RFID tags.

Choosing an output device

Output devices used in printing labels include the 5-bin mailbox, the output expander, the high-capacity output stacker,

adjustable stacker, and the finisher staplesmart. Choose an output device based on the software program, the length of

label needed, and the number of labels that you expect to print at one time. To order an output device, visit the Lexmark

Web site at www.lexmark.com:

Output device Part number

5-bin Mailbox 20G0895

Output expander 20G0894

High-capacity output stacker 20G0896

Adjustable stacker 20G1360

Finisher StapleSmart 20G0897

Note: RFID media should not be directed to the T64x StapleSmart Finisher, if it is used as an output device. The standard

output bin should be used for all RFID media, even if recognized as defective. The T64x StapleSmart Finisher may still

be used for any non-RFID media.

Lexmark Confidential until announced

Introduction

Preparing to print

Loading RFID labels

To load labels:

Note: Do not remove a tray when a job is printing or when the operator panel indicator light is blinking. Doing so may

cause a jam.

1Remove the tray from the printer, and place it on a flat, level surface.

2Squeeze the side guard tab, and slide the guide to the outer edge of the tray.

3Flex the label sheets back and forth to loosen them, and then fan them. Do not fold or crease the label sheets.

Straighten the edges on a level surface.

4Place the label sheets with the print side facing down and the labels positioned at the back of the tray.

5Squeeze the rear guide tab, and slide the guide to the correct position for the size label sheets you are loading.

6Insert the tray into the printer.

The increased thickness of RFID labels reduces the input and output bin capacity. Test your software program to ensure

that you understand the reduced input and output bin capabilities. For information on label construction, see the Card

Stock and Label Guide on the Lexmark Web site at www.lexmark.com/publications.

Lexmark Confidential until announced

Preparing to print

Proper tag orientation for printing

The following are examples of tag locations known to work correctly:

Tag manufacturer (EPC class 1

generation 2 specification only) Tag location Orientation

Symbol G2 4 x 4 1.5–8.5 in. from the left edge NA

Raflatec 3.7–7.5 in from the left edge Parallel to the long edge of the label sheet

Avery Dennison 3.7–7.5 in. from the left edge Parallel to the long edge of the label sheet

Texas Instruments 4.7–7.8 in. from the left edge Parallel to the long edge of the label sheet

Alien 3.7–7.5 in from the left edge Parallel to the long edge of the label sheet

Notes:

•Tags must be built to EPC class 1 generation 2 specifications.

•A tag must be located within the first two-thirds of the label sheet.

Lexmark Confidential until announced

Preparing to print

Printing

Printing on labels of different sizes

Label size/type Input options Output options Rejected label output

Less than 7 in. 250-sheet tray •5-bin Mailbox

•Output expander

•High-capacity output stacker

•Adjustable stacker

Set the default Reject Bin so that all rejected labels

are sent to the same output device.

1Select RFID Settings using the Menu button.

2Select Reject Bin.

3Select one of the listed output bins to use as

the default.

4Exit the menu.

Less than 9 in. Any tray

9–14 in. Any tray

Identifying rejected labels

Whena labelis rejected,a printedgrid appearsat thebottom ofthe labelsheet asshown inthe followingdiagram. However,

this only applies to label sheets greater than 9 inches.

Lexmark Confidential until announced

Printing

Understanding the RFID menu

Configuring RFID-specific settings

The RFID menu is used to configure RFID-specific settings. It is located on the operator panel between the Help and

Network/Ports menus.

Note: RFID settings appear on the menu settings page. For information on printing a menu settings page, see the User's

Guide available on the Software and Documentation CD.

Press to access the Menu options. Select RFID Menu from the list.

The RFID Menu setting appears.

RFID Settings

Retry Count

Stop on Error

Mark on Error

Reset Label Count

RFID settings menu

Use the “RFID” Menu to define the following:

•Labels loaded in each label tray

•Default label source

•Output bin

Retry count

Menu selection Purpose Option Comments

Retry Count Determines how many times to retry programming anew label

when label fails to program. A retry will occur on a new RFID

sheet

0–255 Zero is the default value.

Stop on Error

Menu selection Purpose Option Comments

Stop on Error Determines whether or not to stop printing and post a message

on the operator panel when the Retry County is exhausted Yes

No Yes is the default value.

Lexmark Confidential until announced

Understanding the RFID menu

Reject Bin

Menu selection Purpose Option Comments

Reject Bin Determines where to send sheets with

RFID labels that failed to program

correctly Standard Bin and Disabled are

displayed if no option bins are installed

Disabled Standard Bin

Bin 1

Bin 2

Bin 3

Bin 4

Bin 5

Bin 6

Bin 7

Bin 8

Bin 9

Bin 10

Disabled is the default value.

Mark on Error

Menu selection Purpose Option Comments

Mark on Error Tells the printer to print a grid on the bottom of any media when

a defective label is detected Yes

No Yes is the default value.

Reset Label Counters

Menu selection Purpose Option Comments

Reset Label Counters Clears the current version of label

counters (passed and failed). Reset is

the only menu selection

Value

Reset When Reset is selected, a “Contents will

be lost” confirmation prompt appears.

Lexmark Confidential until announced

Understanding the RFID menu
