Lexmark Pro900 Series Manual de usuario

1Unpack printer

Notes:

•Place the printer near the computer

during setup. If you're setting up on

a wireless network, then you may

move the printer after setup is

complete.

•Do not attach the USB cable until

prompted to do so.

•The packaged printhead is shipped

inside the printer.

•Contents may vary by model and

region.

2Remove tape and packing material from all areas of the

printer

Lexmark Pro900 Series Installation

3Install paper tray 2

Note: You can use an optional tray (tray 2)

to increase the paper loading capacity of

the printer.

4Open printer and remove packaged printhead

Lexmark Pro900 Series Installation

5Close printer

6Pull tray 1 completely out of printer

Lexmark Pro900 Series Installation

7Move paper guides to the sides

8For A4 or Legal, extend paper tray

9Load paper and adjust paper guides

Note: Do not load paper past the

maximum height indicator line as shown

in step 2.

Lexmark Pro900 Series Installation

10 Insert paper tray

Note: Repeat the paper loading steps to

load tray 2.

11 Connect power cord only

Note: DO NOT attach the USB cable yet.

CAUTION—POTENTIALINJURY: Read the safety information included with this product before connecting

power or making any cabling connections.

12 Make sure printer is on

Lexmark Pro900 Series Installation

13 Follow prompts on the printer control panel

1Follow the prompts on the printer

control panel.

2After following the prompts, click

Continue below.

14 Install printhead and ink cartridges

If you need to install the printhead and

cartridges, click Continue.

If not, you can close this window.

15 Open printer and remove any tape from latch

Note: The carriage moves to the

printhead installation position as shown.

Lexmark Pro900 Series Installation

16 Squeeze and lift latch

17 Remove printhead from disposable container

18 Insert printhead and close latch until it clicks

Lexmark Pro900 Series Installation

19 Close printer

20 Open printer

Note: The printhead moves to the

cartridge installation position as shown.

Lexmark Pro900 Series Installation

21 First, insert each color ink cartridge. Then, use two hands

to install black cartridge.

22 Close printer

Lexmark Pro900 Series Installation

23 Flip and extend exit tray paper stop

Notes:

•Extend the paper exit tray for

A4/Legal.

•The paper stop holds paper as it exits

the printer.

24 Touch OK to print alignment page

Notes:

•Do not remove the page until

printing stops. The alignment page

may take a while to print and will

move in and out during the process.

•Streaks on the alignment page are

normal and not an indication of a

problem.

•The alignment page that prints may

differ from the one shown.

•Recycle the alignment page.

Lexmark Pro900 Series Installation
