1Unpack printer

Notes:

•Place the printer near the computer

during setup. If you're setting up on

a wireless network, then you may

move the printer after setup is

complete.

•Do not attach the USB cable until

prompted to do so.

•The packaged printhead is shipped

inside the printer.

•Contents may vary by model and

region.

2Remove tape and packing material from all areas of the

printer

Lexmark Pro700 Series Installation

3Open printer and remove packaged printhead

4If necessary, insert correct (1) language overlay and install

(2) protective cover

Lexmark Pro700 Series Installation

5Lock the protective cover in place

6Close printer

Lexmark Pro700 Series Installation

7Pull paper tray completely out of printer

8Move paper guides to the sides

9For A4 or Legal, extend paper tray

Lexmark Pro700 Series Installation

10 Load paper and adjust paper guides

Note: Do not load paper past the

maximum height indicator line as shown

in step 2.

11 Insert paper tray

Lexmark Pro700 Series Installation

12 Connect power cord only

Note: DO NOT attach the USB cable yet.

CAUTION—POTENTIALINJURY: Read the safety information included with this product before connecting

power or making any cabling connections.

13 Make sure printer is on

14 Follow prompts on the printer control panel

1Follow the prompts on the printer

control panel.

2After following the prompts, click

Continue below.

Lexmark Pro700 Series Installation

15 Install printhead and ink cartridges

If you need to install the printhead and

cartridges, click Continue.

If not, you can close this window.

16 Open printer and remove any tape from latch

Note: The carriage moves to the

printhead installation position as shown.

17 Squeeze and lift latch

Lexmark Pro700 Series Installation

18 Remove printhead from disposable container

19 Insert printhead and close latch until it clicks

20 Close printer

Lexmark Pro700 Series Installation

21 Open printer

Note: The printhead moves to the

cartridge installation position as shown.

22 First, insert each color ink cartridge. Then, use two hands

to install black cartridge.

Lexmark Pro700 Series Installation

23 Close printer

24 Flip and extend exit tray paper stop

Notes:

•Extend the paper exit tray for

A4/Legal.

•The paper stop holds paper as it exits

the printer.

25 Press OK to print alignment page

Notes:

•Do not remove the page until

printing stops. The alignment page

may take a while to print and will

move in and out during the process.

•Streaks on the alignment page are

normal and not an indication of a

problem.

•The alignment page that prints may

differ from the one shown.

•Recycle the alignment page.

Lexmark Pro700 Series Installation
