Printing Guide

Loading the 250‑or 550‑sheet tray

CAUTION—POTENTIAL INJURY: To reduce the risk of equipment instability, load each tray separately. Keep all other trays

closed until needed.

1Pull out the tray.

Notes:

•When loading folio‑, legal‑, or Oficio‑size paper, lift the tray slightly and pull it out completely.

•Avoid removing trays while a job prints or while Busy appears on the display. Doing so may cause a jam.

2Squeeze and slide the width guide to the correct position for the size of the paper being loaded until it clicks into place.

Printing Guide

Page 1 of 18

Note: Use the paper size indicators at the bottom of the tray to help position the guides.

3Unlock the length guide, and then squeeze and slide the guide to the correct position for the size of the paper being loaded.

Notes:

•Lock the length guide for all paper sizes.

•Use the paper size indicators at the bottom of the tray to help position the guides.

Printing Guide

Page 2 of 18

4Flex the sheets back and forth to loosen them, and then fan them. Do not fold or crease the paper. Straighten the edges on

a level surface.

5Load the paper stack with the printable side facedown.

Note: Make sure the paper or envelope is loaded properly.

•There are different ways of loading letterhead depending on whether an optional staple finisher is installed or not.

Without an optional staple finisher With an optional staple finisher

ABC

One‑sided printing One‑sided printing

ABC

Two‑sided printing

ABC

Two‑sided printing

Printing Guide

Page 3 of 18

•If you are loading prepunched paper for use with the staple finisher, then make sure the holes on the long edge of the

paper are on the right side of the tray.

One‑sided printing Two‑sided printing

ABC

Note: If the holes on the long edge of the paper are on the left side of the tray, then a jam may occur.

•Do not slide the paper into the tray. Load paper as shown in the illustration.

•If you are loading envelopes, then make sure that the flap side is facing up and the envelopes are on the left side of the

tray.

Printing Guide

Page 4 of 18

•Make sure the paper is below the solid line, which is the maximum paper fill indicator.

Warning—Potential Damage: Overfilling the tray can cause paper jams.

Printing Guide

Page 5 of 18

•When using card stock, labels, or other types of specialty media, make sure the paper is below the dashed line, which is

the alternate paper fill indicator.

6For custom‑or Universal‑size paper, adjust the paper guides to lightly touch the sides of the stack, and then lock the length

guide.

7Insert the tray.

8From the printer control panel, set the paper size and paper type in the Paper menu to match the paper loaded in the tray.

Note: Set the correct paper size and type to avoid paper jams and print quality problems.

Printing Guide

Page 6 of 18

Loading the 2100‑sheet tray

CAUTION—POTENTIAL INJURY: To reduce the risk of equipment instability, load each tray separately. Keep all other trays

closed until needed.

1Pull out the tray.

2Adjust the width and length guides.

Loading A5‑size paper

aPull up and slide the width guide to the position for A5.

LGL

OFC

FOLIO

LTR

LGL

OFC

FOLIO

LTR

LGL

OFC

FOLIO

LTR

Printing Guide

Page 7 of 18

bSqueeze and slide the length guide to the position for A5 until it clicks into place.

cRemove the A5 length guide from its holder.

dInsert the A5 length guide into its designated slot.

Note: Press the A5 length guide until it clicks into place.

Printing Guide

Page 8 of 18

Loading A4‑, letter‑, legal‑, oficio‑, and folio‑size paper

aPull up and slide the width guide to the correct position for the size of the paper being loaded.

LGL

OFC

FOLIO

LTR

LGL

OFC

FOLIO

LTR

LGL

OFC

FOLIO

LTR

bIf the A5 length guide is still attached to the length guide, then remove it from its place. If the A5 length guide is not

attached, then proceed to step d.

Printing Guide

Page 9 of 18

cPut the A5 length guide in its holder.

dSqueeze the length guide and slide it to the correct position for the size of the paper being loaded until it clicks into place.

Printing Guide

Page 10 of 18
