Lexmark C720 SERIES Guía de inicio rápido

Lexmark C720

5024-001

Extracted From Service Manual

U.S.A. P/N: 12G3667

5024-001

Edition: March 2001

The following paragraph does not apply to any country where such provisions are

inconsistent with local law: LEXMARK INTERNATIONAL, INC. PROVIDES THIS

PUBLICATION “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR

IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF

MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Some states do

not allow disclaimer of express or implied warranties in certain transactions; therefore,

this statement may not apply to you.

This publication could include technical inaccuracies or typographical errors. Changes

are periodically made to the information herein; these changes will be incorporated in

later editions. Improvements or changes in the products or the programs described may

be made at any time.

Comments may be addressed to Lexmark International, Inc., Department D22A/032-2,

740 West New Circle Road, Lexington, Kentucky 40550, U.S.A or e-mail at

ServiceInfoAndT[email protected]. Lexmark may use or distribute any of the

information you supply in any way it believes appropriate without incurring any obligation

to you. You can purchase additional copies of publications related to this product by

calling 1-800-553-9727. In other countries, contact your point of purchase.

Lexmark, Lexmark with diamond design, MarkNet, and MarkVision are trademarks of

Lexmark International, Inc., registered in the United States and/or other countries.

PCL is a registered trademark of the Hewlett-Packard Company.

PostScript is a registered trademark of Adobe Systems Incorporated.

Other trademarks are the property of their respective owners.

UNITED STATES GOVERNMENT RESTRICTED RIGHTS

This software and documentation are provided with RESTRICTED RIGHTS. Use,

duplication or disclosure by the Government is subject to restrictions as set forth in

subparagraph (c)(1)(ii) of the Rights in Technical Data and Computer Software clause at

DFARS 252.227-7013 and in applicable FAR provisions: Lexmark International, Inc.,

Lexington, KY 40550.

Parts Catalog 7-1

5024-001

7. Parts Catalog

How to Use this Parts Catalog

•SIMILAR ASSEMBLIES: If two assemblies contain a majority of

identical parts, they are shown on the same list. Common parts

are shown by one index number. Parts peculiar to one or the

other of the assemblies are listed separately and identified by

description.

•AR: (As Required) in the Units column indicates that the

quantity is not the same for all machines.

•NP: (Non-Procurable) in the Units column indicates that the part

is non-procurable and that the individual parts or the next higher

assembly should be ordered.

•NR: (Not Recommended) in the Units column indicates that the

part is procurable but not recommended for field replacement,

and that the next higher assembly should be ordered.

•R: (Restricted) in the Units column indicates that the part has a

restricted availability.

•NS: (Not Shown) in the Ref column indicates that the part is

procurable but is not pictured in the illustration.

•PP: (Parts Packet) in the Description column indicates that the

part is contained in a parts packet.

•A part reference within a circle indicates an assembly or a bill-

of-material. An assembly is complete. A bill-of-material contains

unassembled parts.

•NA: Not available/not referenced.

Parts Catalog 7-2

Assembly 1:

Parts Catalog 7-3

5024-001

Assembly 1:

Ref Part

Number Units Description

1 - 1 1 Toner Cartridge -Y

(Supply, customer order only)

Toner Cartridge -M

(Supply, customer order only)

Toner Cartridge -C

(Supply, customer order only)

Toner Cartridge -K

(Supply, customer order only)

OPC Belt Cartridge

(Supply, customer order only)

Fuser Oil Bottle

(Supply, customer order only)

Fuser Cleaner

(Supply, customer order only)

Waste Toner-P

(Supply, customer order only)

Fusing Unit (110V)

(Supply, customer order only)

10 1 Fusing Unit (220V)

(Supply, customer order only)

12 12G7004 1 Transfer Roller

13 12G7005 1 Paper Discharger

14 12G7006 1 Drum Cleaner

15 12G7007 1 Ozone Filter

16 12G7008 1 Power Cord (U.S.)

16 1339517 1

Power Cord, LV U.S., APG, Bolivia,

Canada, Columbia, Costa Rica, Ecuador,

EL Salvador, Guatemala, Honduras,

Mexico, Nicaragua, Panama, Peru,

Venezuela

16 1339518 1 Power Cord, HV, Argentina

Parts Catalog 7-4

Assembly 1 (cont.):

Parts Catalog 7-5

5024-001

Assembly 1 (cont.):

Note: Reference the foldout wiring diagram, in the back of this

manual, for cable replacement detailed information. Then go to

Assembly 6 for parts ordering information.

Ref Part

Number Units Description

1 - 16 1339520 1 Power Cord, HV, Brazil

16 1339524 1 Power Cord, HV, Chili

16 1339528 1 Power Cord, HV, UK, Ireland

16 1339529 1

Power Cord, HV, Austria, Belgium, EURO

English, Finland, France, Germany,

Greece, Netherlands, Norway, Poland,

Portugal, Russia, Slovakia/Czech/Hungary

Spain, Sweden, Turkey

16 1339530 1 Power Cord, HV, Israel

16 1339531 1 Power Cord, HV, Switzerland French,

Switzerland German, Switzerland Italian

16 1339532 1 Power Cord, HV, South Africa

16 1339533 1 Power Cord, HV, Italy

16 1339534 1 Power Cord, HV, Denmark

18 12G7010 1 Paper Cassette

18 12G7232 1 Paper Cassette (250 sheet legal)

19 12G7011 1 Cleaner Cover

20 12G7012 1 Transfer Unit Cover

21 12G7013 1 Transfer Unit (includes 12, 13, 20, 23, 25)

23 12G7014 1 PT1 Sensor Lever

24 12G7159 1 Paper Cassette Paper Stop

25 12G7160 1 Registration Roller Assembly

12G7341 1 Parts Packet, Screws

12G7340 1 Parts Packet, Cable Clamps, Retainers,

Miscellaneous

Parts Catalog 7-6

Assembly 2:

Parts Catalog 7-7

5024-001

Assembly 2:

Ref Part Number Units Description

2 - 1 12G7015 1 Top Cover Assembly (includes 35)

2 12G7016 1 Side Cover (R)

3 12G7017 1 Side Cover (L)

4 12G7018 1 Upper Side Cover (L)

5 12G7019 1 Front Cover

6 12G7020 1 Paper Exit Unit Cover (includes 13)

7 12G7021 1 Paper Exit Front Cover

8 12G7022 1 Base Cover (R)

9 12G7023 1 Base Cover (L)

10 12G7024 1 Rear Cover

11 12G7025 1 Rear Cover (U)

12 12G7026 1 Side F Cover (L)

13 12G7027 1 Paper Exit Upper Cover

14 12G7028 2 Rear Cover (U) Cap

15 12G7029 1 Front Cover Unit (includes 5, 45, 47)

16 12G7030 1 Main Engine (MCTL P.W.B.) Board

17 12G7031 1 High Voltage Unit

20 12G7032 1 Discharge Brush

21 12G7033 1 Cooling Fan (HFAN)

22 12G7034 1 Paper Exit Filter (with Case)

23 12G7035 1 Ozone Filter Cover

24 12G7036 1 Paper Sensor (PT2)

25 12G7037 1 Paper Sensor (FCL)

26 12G7038 1 Paper Exit Unit (includes 6, 7, 13, 20, 21,

22, 24, 25, 27, 28, 30, 31, 40, 42)

Parts Catalog 7-8

Assembly 2 (cont.):
