Levoit LV-PUR131 Manual de usuario

True HEPA Air Puriﬁer

Model: LV-PUR131

Questions or Concerns?

Please contact us at [email protected].

USER MANUAL

Power Supply AC 220–240V,

50/60Hz

Rated Power 40W

Eective Range ≤ 48 m² / 516 ft²

Operating

Conditions

-10°–40°C / 14°–104°F

Noise Level 23–52dB

Clean Air

Delivery Rate

(CADR)

230 m³/h / 135 CFM

Standby Power < 0.8W

Dimensions 37.1 x 18.3 x 47 cm /

14.6 x 7.2 x 18.5 in

Weight 5.21 kg / 11.49 lb

Package Contents

Speciﬁcations

1 x Air Puriﬁer

1 x Activated Carbon Filter (Pre-Installed)

1 x Preliminary/True HEPA Combination Filter

(Pre-Installed)

1 x User Manual

Package Contents

Speciﬁcations

Safety Information

Getting to Know Your Air Puriﬁer

Controls

Getting Started

Using Your Air Puriﬁer

About the Filters

Care & Maintenance

Troubleshooting

Warranty Information

Customer Support

Table of Contents

SAFETY INFORMATION

• Only use your air puriﬁer as described

in this manual.

• Do not use your air puriﬁer outdoors.

• Keep your air puriﬁer away from water,

and wet or damp areas. Never place in

water or liquid.

• Keep your air puriﬁer away from heat

sources.

• Do not use where combustible gases,

vapours, metallic dust, aerosol (spray)

products, or fumes from industrial oil are

present.

• Keep 1.5 m / 5 ft away from where

oxygen is being administered.

• Supervise children when they are near

the air puriﬁer.

• Do not place anything into any opening

on the air puriﬁer, unless directed by the

manual.

• Do not sit or place heavy objects on the

air puriﬁer.

• Keep the inside of the air puriﬁer dry.

To prevent moisture buildup, avoid

placing in rooms with major temperature

changes or underneath air conditioners.

To reduce the risk of ﬁre, electric shock, or other injury, follow all instructions and

safety guidelines.

General Safety

• Keep air puriﬁer near the outlet it is

plugged into.

• Never place the cord near any heat

source.

• Do not cover the cord with a rug,

carpet, or other covering. Do not place

the cord under furniture or appliances.

• Keep the cord out of areas where

people walk often. Place the cord

where it will not be tripped over.

Plug & Cord

• Always unplug your air puriﬁer before

servicing (such as when changing

ﬁlters).

• Do not use your air puriﬁer if it is

damaged or not working correctly, or if

the cord or plug is damaged. Do not try

to repair it yourself. Contact Customer

Support (see page 14).

• WARNING: To reduce the risk of ﬁre

or electric shock, do not use this air

puriﬁer with solid-state speed controls

(such as a dimmer switch).

• Not for commercial use. Household use

only.

READ AND SAVE THESE

INSTRUCTIONS

GETTING TO KNOW YOUR AIR PURIFIER

LED DISPLAY

A. LED Display

B. Touch-Control Panel

C. Dust Sensor Lens

D. Dust Sensor Cover

A. On/O Indicator

B. Check Filter Indicator

C. Timer Display

D. Air Quality Indicator

E. Auto Mode

F. Sleep Mode

G. Fan Speed

E. Button Vent

F. Filter Indicator Reset Button

G. Housing

H. Safety Switch

I. Activated Carbon Filter

J. Fine Preliminary Filter

K. True HEPA Filter

L. Back Cover

CONTROLS

On/O Button

• Turns the air puriﬁer on/o.

Display O Button

• Turns the display o.

• Press any button (except

) to turn the display

back on.

Sleep Mode Button

• Turns Sleep Mode on/o

(see page 7).

Timer Button

• Sets or cancels a timer

(see page 7).

Auto Mode Button

• Turns Auto Mode on/o

(see page 7).

Air Quality Indicator

• Displays air quality using the automatic

sensor inside the air puriﬁer.

• The air puriﬁer may take up to 1 minute

to detect air quality.

Fan Speed Button

• Cycles through fan

speeds: low, medium, and

high.

• The fan speed cannot be

changed in Auto or Sleep

Mode.

Air Quality Indicator Chart

Colour Air Quality

Red Bad

Yellow Moderate

Green Good

Blue Very Good

GETTING STARTED

1. Open the back cover of the air puriﬁer

and remove both ﬁlters from their plastic

packaging. [Figure 1.1]

2. Place the Activated Carbon Filter back

into the air puriﬁer, followed by the Fine

Preliminary/True HEPA Combination

Filter. Make sure the pull tabs on both

ﬁlters are facing out. [Figure 1.2]

3. Replace the back cover by lining up

the cover’s feet with the slots in the

bottom of the housing. Make sure that

the triangular piece at the bottom of

the cover is touching the safety switch.

[Figure 1.3]

4. Push the cover closed.

5. Place the air puriﬁer on a hard,

ﬂat surface. Leave 38 cm / 15 in of

clearance on all sides of the air puriﬁer.

[Figure 1.4]

Note: Do not remove the foam piece

attached to the dust sensor cover

unless instructed by Customer Support.

[Figure 1.5]

Figure 1.1

Figure 1.4

Figure 1.5

Figure 1.2

Figure 1.3

Tabs facing

outward

38 cm /

15 in

Safety

switch

38 cm /

15 in

Note:

• For best results, run the air puriﬁer

at high speed for 15–20 minutes

before using a lower speed or Auto

Mode.

• To eectively clean air, keep

windows closed while the air

puriﬁer is operating.

USING YOUR AIR PURIFIER

General Operation

Sleep Mode

1. Press to turn the air puriﬁer

on/o. The air puriﬁer fan will start

automatically at low speed.

2. Optionally, press to increase fan

speed. You can also select Auto or

Sleep Mode, or set a timer.

Sleep Mode uses the lowest possible fan

speed to create a quiet environment.

• Press to turn Sleep Mode on/o.

• Pressing or will also exit Sleep

Mode.

Auto Mode

Timer

Auto Mode uses the dust sensor inside

the air puriﬁer to adjust the fan speed

automatically based on air quality. For

example, if the air quality is bad, the fan will

automatically be set to high speed.

• Press to turn Auto Mode on/o.

• Pressing or will also exit Auto

Mode.

You can set a timer between 1–12 hours.

• Press repeatedly to choose a time

in increments of 1 hour. When you stop

pressing , the display will ﬂash 3 times

and the timer will start.

• The air puriﬁer will automatically turn o

once the timer is ﬁnished.

• To cancel a timer, press repeatedly

until the display reads “-:--” and ﬂashes

3 times.

Auto Mode Chart

Colour Air Quality Fan Speed

Red Bad High

Yellow Moderate Medium

Green Good Low

Blue Very Good Sleep Mode

Automatic Shutoff

Memory Function

As a safety feature, the air puriﬁer will

automatically turn o if the back cover is

removed.

When the air puriﬁer is plugged in, it will

remember its programmed settings while

turned o, and resume those settings when

turned back on.

ABOUT THE FILTERS

A. Fine Preliminary Filter

• Captures large particles such as

dust, lint, ﬁbres, hair, and pet fur.

• Maximises the life of the True

HEPA Filter by protecting it.

B. True HEPA Filter

• Removes at least 99.97% of

airborne particles 0.3 micrometres

(µm) in diameter.

• Filters small particles such as

mould spores, tiny dust particles,

parts of smoke, and allergens such

as pollen, dander, and mites.

C. High-Eciency Activated Carbon Filter

• Physically adsorbs smoke,

odours, and fumes.

• Filters compounds such as

formaldehyde, benzene,

ammonia, hydrogen sulphide,

and volatile organic compounds

(VOCs).

This air puriﬁer uses a 3-stage ﬁltration system to purify air.

CARE & MAINTENANCE

Check Filter Indicator

Cleaning the Filters

Cleaning the Air Purifier

A. The Fine Preliminary Filter should be

cleaned once a month to increase

eciency and extend the life of your

ﬁlter. Clean the Fine Preliminary Filter

using a brush or vacuum hose to

remove hair, dust, and large particles.

B. Do not clean the True HEPA Filter. Fine

dust or bacteria may be released back

into the air if cleaning is attempted. Only

clean the Fine Preliminary Filter.

C. The Activated Carbon Filter does not

require cleaning.

Wipe the outside of the air puriﬁer with a dry

cloth. Do not clean with water or any other

liquid, to avoid risk of electric shock.

A B

Replacing the Filters

1. Unplug the air puriﬁer, then remove the

back cover.

2. Remove the old ﬁlters and properly

dispose of them.

3. Unwrap the new ﬁlters. Place the

Activated Carbon Filter inside the

housing. Make sure the pull tabs are

facing out.

4. Install the Fine Preliminary/True HEPA

Combination Filter into the housing.

Make sure the pull tabs are facing out.

5. Replace the back cover. The air puriﬁer

will not turn on unless the back cover is

replaced correctly.

6. Reset the Check Filter Indicator (see

page 11).

The Check Filter Indicator will light up as a

reminder to check the ﬁlters. Depending on

how often you use the air puriﬁer, the indicator

should turn on within 6–8 months. You may not

need to change your ﬁlters yet, but you should

check them when the indicator light turns on.

Reset the Check Filter Indicator by pressing the

black Filter Indicator Reset Button in the vent on

the side of the air puriﬁer (see page 11).

When Should I Replace the

Filters?

The ﬁlters should be replaced every 6–8

months. You may need to replace your ﬁlters

earlier or later depending on how often you

use your air puriﬁer. Using your air puriﬁer in an

environment with relatively high pollution may

mean you will need to change the ﬁlters more

often.

You may need to replace your ﬁlters if you

notice:

• Increased noise when the air puriﬁer is on

• Decreased airﬂow

• Unusual odours

• Visibly clogged ﬁlters

Cleaning the Dust Sensor Lens

1. Unplug the air puriﬁer.

2. Open the dust sensor cover. [Figure 2.1]

3. Use a cotton swab dipped in water to

clean the dust sensor lens. [Figure 2.2]

4. Wipe the lens dry with a dry cotton

swab.

Note: Do not remove the foam piece

attached to the dust sensor cover

unless instructed by Customer Support.

[Figure 2.3]

CARE & MAINTENANCE (CONT.)

Figure 2.2

Figure 2.3

To maintain the performance of

your air puriﬁer, only use ocial

Levoit ﬁlters. To buy replacement

ﬁlters, go to Amazon and search

B077GQ6PW8.

Figure 2.1

Otros manuales para LV-PUR131

Tabla de contenidos

Otros manuales de Purificador de aire de Levoit

Levoit

Levoit Core 200S Manual de usuario

Levoit

Levoit VeSync Core 600S Series Manual de usuario

Levoit

Levoit Core LAP-C161-WAS Manual de usuario

Levoit

Levoit True HEPA Core 300-RAC Manual de usuario

Levoit

Levoit Core 300 Manual de usuario

Levoit

Levoit LV-PUR131S Manual de usuario

Levoit

Levoit Core 300 Manual de usuario

Levoit

Levoit Core 400S Series Manual de usuario

Levoit

Levoit LV-PUR131S Manual de usuario

Levoit

Levoit LV-H126 Manual de usuario

Levoit

Levoit Core 300 Manual de usuario

Levoit

Levoit LV-H132 Manual de usuario

Levoit

Levoit LAP-C201S-AUSR Manual de usuario

Levoit

Levoit Core 200S Manual de usuario

Levoit

Levoit LV-PUR131 Manual de usuario

Levoit

Levoit LV-H132 Manual de usuario

Levoit

Levoit LV-PUR131 Manual de usuario

Levoit

Levoit Pet Care True HEPA Core P350 Manual de usuario

Levoit

Levoit LV-H128 Manual de usuario

Levoit

Levoit EverestAir LAP-EL551S-AUS Manual de usuario

Levoit

Levoit Vital 100 Manual de usuario

Levoit

Levoit LV-H132 Manual de usuario

Levoit

Levoit Vista 200-RXW Manual de usuario

Levoit

Levoit LV-PUR131 Manual de usuario

Manuales populares de Purificador de aire de otras marcas

IKEA

IKEA UPPÅTVIND Manual de usuario

Nash

Nash AP-1 PureSmart Manual de usuario

LG PH-U450 Series Manual de usuario

DeLonghi

DeLonghi DDSX 220WFA Manual de usuario

Mitsubishi Electric

Mitsubishi Electric MA-E85R-E Manual de usuario

Sharp

Sharp FU-40SE Manual de usuario

Philips

Philips AC2721 Manual de usuario

Hitachi

Hitachi EP-A3000 Manual de usuario

TruSens

TruSens Z-2000 Manual de usuario

Motorola

Motorola MBP87SN Manual de usuario

Beko

Beko ATP 7100I Manual de usuario

Carrier

Carrier INFINITY 1620 Manual de usuario

AtmosAir

AtmosAir P2002 Manual de usuario

Winix

Winix NK300 Manual de usuario

Friedrich

Friedrich C-90A Instrucciones de funcionamiento e instalación

Surgically Clean Air

Surgically Clean Air JADE2.0 Manual de usuario

Base aire

Base aire 555 Pro Manual de usuario

Champion

Champion CP25 Manual de usuario
