Levoit LV-H133 Manual de usuario

Tower True HEPA Air Puriﬁer

Model: LV-H133

Questions or Concerns?

If you have any questions or concerns, please reach out to us at

[email protected]. We hope you enjoy your new air puriﬁer!

USER MANUAL

Table of Contents

Package Contents

Speciﬁcations

Safety Information

Getting to Know Your Air Puriﬁer

Controls

Getting Started

Using Your Air Puriﬁer

About the FIlter

Care & Maintenance

Troubleshooting

Warranty Information

Customer Support

Package Contents

xAir Puriﬁer

xTrue HEPA Combination Filter

(Pre-Installed)

xUser Manual

Specifications

Power Supply AC 220-240V, 50/60Hz

Rated Power 33W

Ideal Room

Size

83 m² / 893 ft²

Note: Eective for

larger rooms, but

puriﬁcation will take

longer.

Operating

Conditions

Temperature:

-10°–40°C / 14°–104°F

Humidity: ≤ 85% RH

Noise Level 25–50dB

CADR (Clean

Air Delivery

Rate)

400 m³/h / 235 CFM

Standby

Power

< 0.8W

Dimensions 31.8 x 31.8 x 60 cm /

12.5 x 12.5 x 23.6 in

Weight 6.75 kg / 14.9 lb

SAFETY INFORMATION

• Only use your air puriﬁer as

described in this manual.

• Do not use your air puriﬁer

outdoors.

• Keep your air puriﬁer away from

water, and wet or damp areas.

Never place in water or other

liquids.

• Keep your air puriﬁer away from

heat sources.

• Do not use where combustible

gases, vapours, metallic dust,

aerosol (spray) products, or fumes

from industrial oil are present.

• Keep 1.5 m / 5 ft away from where

oxygen is being administered.

• Supervise children when they are

near the air puriﬁer.

• Do not place anything into any

opening on the air puriﬁer.

• Do not sit or place heavy objects

on the air puriﬁer.

• Keep the inside of the air puriﬁer

dry. To prevent moisture buildup,

avoid placing in rooms with major

temperature changes.

• Always unplug your air puriﬁer

before servicing (for example,

changing the ﬁlter).

• Do not use your air puriﬁer if it is

damaged or not working correctly,

or if the cord or plug is damaged.

Do not try to repair it yourself.

Contact Customer Support (see

page 15).

To reduce the risk of ﬁre, electric shock, or other injury, follow all instructions and

safety guidelines.

General Safety

• Keep the air puriﬁer near the outlet

it is plugged into.

• Never place the cord near any heat

source.

• Do not cover the cord with a rug,

carpet, or other covering. Do not

place the cord under furniture or

appliances.

• Keep the cord out of areas where

people walk often. Place the cord

where it will not be tripped over.

Plug & Cord

READ AND SAVE THESE

INSTRUCTIONS

• WARNING: To reduce the risk of

ﬁre or electric shock, do not use

this air puriﬁer with solid-state

speed controls (such as a dimmer

switch).

• Not for commercial use. Household

use only.

GETTING TO KNOW YOUR AIR PURIFIER

A. LED Display / Control Panel

B. Air Outlet

C. Housing

D. Power Cord

E. Air Intake

(triangles at the bottom)

Front Back

H I

Function Diagram

A. Fan Speed Button

B. Auto Mode Button

C. Sleep Mode Button

D. Display O Button

E. Check Filter Indicator

F. Timer Button

G. On/O Button

H. Air Quality Indicator

I. Timer Display

J. Fan Speed Indicator

LED Display

F. Air Quality Sensor

G. Air Quality Sensor Cover

H. Filter

I. Filter Cover

CONTROLS

On/O Button

Turns the air puriﬁer on/o.

Fan Speed Button

Cycles through fan speeds:

low, medium, and high.

Auto Mode Button

Turns Auto Mode on/o

(see page 7).

Sleep Mode Button

Turns Sleep Mode on/o (see

page 8).

Display O Button

• Turns the display o.

• Press any button (except

) to turn the display

back on.

Check Filter Indicator

Lights up red to remind you to

check the ﬁlter (see page 10).

Timer Button

Sets the timer (see page 8).

Fan Speed

Indicator Fan Speed

Low

Medium

High

GETTING STARTED

1. Remove the ﬁlter cover. Pull the ﬁlter

from the housing. [Figure 1.1]

2. Take the ﬁlter out of its plastic

packaging, then reinstall it into the

housing. Make sure the pull tabs on the

ﬁlter are facing out. [Figure 1.2]

3. Replace the ﬁlter cover by lining up the

cover’s feet with the slots in the bottom

of the housing. [Figure 1.3]

4. Push the cover securely closed.

[Figure 1.4]

Note:

• If you are not planning to use the air

puriﬁer for a long period of time, keep

the ﬁlter clean by leaving it inside its

plastic packaging until it is ready to be

used.

Figure 1.1

Figure 1.4

Figure 1.2

Figure 1.3

Figure 2.1

Figure 2.2

USING YOUR AIR PURIFIER

1. Place the air puriﬁer on a level surface.

[Figure 2.1] Leave 38 cm / 15 inches of

clearance on all sides of the puriﬁer.

[Figure 2.2]

2. Plug in. Tap to turn on the air

puriﬁer. The fan will start automatically.

3. Optionally, tap to change fan

speed. You can also select Auto Mode

or Sleep Mode, or set a timer.

a. For best results, or to address a

speciﬁc air quality issue such as

smoke, run the air puriﬁer at high

speed for 15–20 minutes before

using a lower speed or Auto Mode.

b. To eectively clean air, keep

windows and doors closed while

the air puriﬁer is on.

4. Tap to turn o the air puriﬁer.

Auto Mode adjusts the fan speed

automatically based on air quality. For

example, if the air quality is bad, the fan will

be set to high speed.

• Tap to turn Auto Mode on/o.

• Tapping or will also exit Auto

Mode.

General Operation

Auto Mode

15 in /

38 cm

Air Quality Indicator Chart

Indicator

Colour Air Quality Fan Speed

Blue Very Good Sleep Mode

Green Good Low

Orange Moderate Medium

Red Bad High

This indicator uses an automatic sensor to

display the air quality. This sensor uses an

infrared light to detect airborne particles

The air puriﬁer will take 30 seconds to

detect the air quality each time it is turned

on. During this time, the air quality indicator

colour will be blue. After 30 seconds, the air

quality indicator colour will change based

on the detected air quality.

Air Quality Indicator

Note:

• You can change the fan speed at any

time while the timer is counting down.

The timer will work with any mode.

• Pressing or unplugging the air

puriﬁer will cancel the timer.

Note: The air puriﬁer will not remember

timers.

USING YOUR AIR PURIFIER (CONT.)

Sleep Mode Memory Function

Timer

1. Tap repeatedly (or press and hold

) to set a time.

2. Once you choose a time, the timer will

ﬂash 5 times and start counting down.

3. The air puriﬁer will automatically power

o once the timer is ﬁnished.

4. To cancel a timer, tap repeatedly

until the timer reads “- - - -”. The timer

will ﬂash 5 times to conﬁrm cancellation.

Sleep Mode uses the lowest possible fan

speed to operate quietly.

• Tap to turn Sleep Mode on/o.

• Tapping or will also exit Sleep

Mode.

You can set a timer between 1–12 hours.

The air puriﬁer will remember its

programmed settings while turned o and

resume those settings when turned back

on. The air puriﬁer must remain plugged in

for the memory function to work.

ABOUT THE FILTER

A. Nylon Pre-Filter

• Captures large particles such as

dust, lint, ﬁbres, hair, and pet fur.

• Maximises the life of the True

HEPA Filter by protecting it.

B. H13 True HEPA Filter

• Removes at least 99.97% of

airborne particles 0.3 micrometres

(µm) in diameter.

• Filters small particles such as

mould spores, ﬁne dust, smoke

particles, and allergens such as

pollen, dust mites, and pet dander.

C. High-Eciency Activated Carbon Filter

• Physically adsorbs smoke,

odours, and fumes.

• Filters compounds such as

formaldehyde, benzene,

ammonia, hydrogen sulphide,

and volatile organic compounds

(VOCs).

The True HEPA Combination Filter uses a 3-stage ﬁltration system to purify air.

CARE & MAINTENANCE

Cleaning the Air Purifier

Cleaning the Air Quality Sensor

Resetting the Check Filter

Indicator

Check Filter Indicator

1. Wipe the outside of the air puriﬁer with

a dry cloth. Do not clean with water or

any other liquid to avoid risk of electric

shock.

2. Clean the outside of the ﬁlter with a

brush or vacuum hose each month

to prevent buildup of hair or dust. Do

not clean the ﬁlter with water or other

liquids.

Figure 3.1

If the air quality sensor is blocked by

accumulated dust, the air quality indicator

may not work correctly.

Reset the Check Filter Indicator when:

• lights up.

1. Replace the ﬁlter (see page 11).

2. Turn on the air puriﬁer.

3. Press and hold for 3 seconds.

4. The light will turn o after the ﬁlter

indicator is successfully reset.

• The ﬁlter was changed before lit up.

1. Press and hold for 3 seconds

until lights up.

2. Press and hold again for 3

seconds.

3. The light will turn o after the ﬁlter

indicator is successfully reset.

will light up as a reminder to check the

ﬁlter. The indicator is automatic. You may

not need to change your ﬁlter yet, but you

should check it when lights up.

1. Unplug the air puriﬁer.

2. Open the sensor cover.

3. Clean the sensor lens with a damp

cotton swab. [Figure 3.1]

4. Dry the sensor lens with a dry cotton

swab.

5. Close the sensor cover.

Storage

If not using the air puriﬁer for an extended

period of time, wrap the ﬁlter in plastic

packaging and store in a dry place to avoid

moisture damage.

lens inside

opening

Otros manuales para LV-H133

Tabla de contenidos

Otros manuales de Purificador de aire de Levoit

Levoit

Levoit LV-PUR131S Manual de usuario

Levoit

Levoit Vital 100 Manual de usuario

Levoit

Levoit LV-H133 Manual de usuario

Levoit

Levoit Classic 300S Manual de usuario

Levoit

Levoit Core 300 Manual de usuario

Levoit

Levoit LV-PUR131S Manual de usuario

Levoit

Levoit Tower Pro True Manual de usuario

Levoit

Levoit LAP-C201S-AUSR Manual de usuario

Levoit

Levoit Pet Care True HEPA Core P350 Manual de usuario

Levoit

Levoit LV-PUR131 Manual de usuario

Levoit

Levoit Vital 100 Manual de usuario

Levoit

Levoit LV-H135 Manual de usuario

Levoit

Levoit Vital 100S Manual de usuario

Levoit

Levoit LV-H131S-RXW Manual de usuario

Levoit

Levoit Core 200S Manual de usuario

Levoit

Levoit LV-PUR131S Manual de usuario

Levoit

Levoit LV-PUR131 Manual de usuario

Levoit

Levoit LV-H126 Manual de usuario

Levoit

Levoit LV-H132 Manual de usuario

Levoit

Levoit EverestAir LAP-EL551S-AUS Manual de usuario

Levoit

Levoit Core 300 Manual de usuario

Levoit

Levoit Core 200S Manual de usuario

Levoit

Levoit LV-H128 Manual de usuario

Levoit

Levoit LV-PUR131S Manual de usuario

Manuales populares de Purificador de aire de otras marcas

IKEA

IKEA UPPÅTVIND Manual de usuario

Nash

Nash AP-1 PureSmart Manual de usuario

LG PH-U450 Series Manual de usuario

DeLonghi

DeLonghi DDSX 220WFA Manual de usuario

Mitsubishi Electric

Mitsubishi Electric MA-E85R-E Manual de usuario

Sharp

Sharp FU-40SE Manual de usuario

Philips

Philips AC2721 Manual de usuario

Hitachi

Hitachi EP-A3000 Manual de usuario

TruSens

TruSens Z-2000 Manual de usuario

Motorola

Motorola MBP87SN Manual de usuario

Beko

Beko ATP 7100I Manual de usuario

Carrier

Carrier INFINITY 1620 Manual de usuario

AtmosAir

AtmosAir P2002 Manual de usuario

Winix

Winix NK300 Manual de usuario

Friedrich

Friedrich C-90A Instrucciones de funcionamiento e instalación

Surgically Clean Air

Surgically Clean Air JADE2.0 Manual de usuario

Base aire

Base aire 555 Pro Manual de usuario

Champion

Champion CP25 Manual de usuario
