EZ-MAX Plus Quick Start Guide

Page 2

QUI CK START OVERVI EW

Overview

This EZ-MAX Plus Quick Start Guide assumes that you have

already installed your EZ-MAX Plus relay cabinet. This guide also

assumes you have read and familiarized yourself with the EZ-MAX

Plus Programmer Guide.

This guide covers an abbreviated version of the topics listed

below. See the EZ-MAX Plus Programmer Guide for complete

details and instructions on all topics.

•Time and Date—setting the time and date on your relay

cabinet.

•Set All Relays—globally configuring all relays in your

cabinet.

•Blink Warn Timer—configuring the blink warn timer

settings.

•Scheduler—creating a schedule of events.

•Configuring I nputs—configuring low voltage inputs

(occupancy sensors, photocells and switches) and digital

inputs.

EZ-MAX Plus QuickStart.book Page 2 Thursday, January 22, 2009 1:55 PM

WEB VERSION

EZ-MAX Plus Quick Start Guide

Page 3

EZ-MAX Plus QuickStart.book Page 3 Thursday, January 22, 2009 1:55 PM

WEB VERSION

EZ-MAX Plus Quick Start Guide

Page 4

Setting the Time and Date

SET TI ME

You can change the following fields in the Time display:

•12 or 24-hour clock

•Hours

•Minutes

•AM or PM

•Daylight Savings Time Mode:

Step 1: Press the MENU button.

Step 2: Press until the display reads as shown below,

then press SELECT/ SAVE.

Step 3: Press SELECT/ SAVE.

The display will show the current setting for the time.

Step 4: Use to navigate through the fields. Use to

change the settings for each field. For example, use

to change the clock from a 12-hour clock to a 24-hour

clock:

MAIN MENU SELECT

SET TIME/DATE

MAIN MENU SELECT

SET TIME

SET TIME 12 HOUR

4:46PM D: OFF

SET TIME 24 HOUR

16:46S D: US

EZ-MAX Plus QuickStart.book Page 4 Thursday, January 22, 2009 1:55 PM

TI ME/ DATE

WEB VERSION

Setting the Time and Date

EZ-MAX Plus Quick Start Guide

Page 5

Step 5: Press SELECT/ SAVE when you have finished editing the

fields.

SET DATE

Step 1: Press the MENU button.

Step 2: Press until the display reads as below, then press

SELECT/ SAVE.

Step 3: Press until the display reads SET DATE, then press

SELECT/ SAVE

The display will show the current setting for the date, and the

active field will blink.

Step 4: Use to navigate through the fields. Use the

numeric keypad to change the settings for each field.

Step 5: Press SELECT/ SAVE when you have finished editing the

fields.

SET ASTRO CLOCK

Set Astro Clock by City

Follow the steps below to set the Astro Clock by using a quick city

code. See “Quick Codes for 101 Major Cities” on page 32 to see if

your city or a city near you is listed.

MAIN MENU SELECT

SET TIME/DATE

MAIN MENU SELECT

SET DATE

SET DATE MON

12/22/2008

EZ-MAX Plus QuickStart.book Page 5 Thursday, January 22, 2009 1:55 PM

WEB VERSION

EZ-MAX Plus Quick Start Guide

Page 6

Step 1: Press the MENU button.

Step 2: Press until the display reads as below, then press

SELECT/ SAVE.

Step 3: Press until the display reads as below, then press

SELECT/ SAVE.

Step 4: The display should now read as below. Press SELECT/

SAVE.

Step 5: Use the numeric keypad to enter the number that is

listed next to your city name (i.e. 55 for Las Vegas, NV),

and then press SELECT/ SAVE.

MAIN MENU SELECT

SET TIME/DATE

MAIN MENU SELECT

SET ASTRO CLOCK

CITY

LAS VEGAS

EZ-MAX Plus QuickStart.book Page 6 Thursday, January 22, 2009 1:55 PM

TI ME/ DATE

WEB VERSION

Setting the Time and Date

EZ-MAX Plus Quick Start Guide

Page 7

Set Astro Clock by Longitude/ Latitude

Make sure you have the following information for your city before

you begin: current sunrise time, current sunset time, latitude.

This information can be found at www.srrb.noaa.gov/ highlights/

sunrise/ sunrise.html.

Step 1: Press the MENU button.

Step 2: Press until the display reads as shown below

Step 3: Press until the display reads as shown below, then

press

SELECT/ SAVE.

The display should now read:

Step 4: Press until the display reads SUN/ LAT, then press

SELECT/ SAVE.

Step 5: You will now be prompted to set the Sunrise (SR), Sunset

(SS) and Latitude (LAT) for your location. The active field

MAIN MENU SELECT

SET TIME/DATE

MAIN MENU SELECT

SET ASTRO CLOCK

CITY

SET ASTRO CLOCK

SUN/LAT

EZ-MAX Plus QuickStart.book Page 7 Thursday, January 22, 2009 1:55 PM

WEB VERSION

EZ-MAX Plus Quick Start Guide

Page 8

will flash. Use the key to navigate between fields.

Use the numeric keypad to enter in the values.

Step 6: Press the SELECT/ SAVE button when you have finished

editing the fields.

SR=07:01A

SS=08:25P LAT=45

EZ-MAX Plus QuickStart.book Page 8 Thursday, January 22, 2009 1:55 PM

TI ME/ DATE

WEB VERSION

Setting the Time and Date

EZ-MAX Plus Quick Start Guide

Page 9

EZ-MAX Plus QuickStart.book Page 9 Thursday, January 22, 2009 1:55 PM

WEB VERSION

EZ-MAX Plus Quick Start Guide

Page 10

Globally Configuring Relays

SET ALL RELAYS

Use the SET ALL RELAYS menu item to configure all of your

relays at once. Changing settings in this menu will change the

relay type for ALL relays in the cabinet, even if you have already

specified a different relay type to an individual relay.

See the EZ-Max Plus Programmer Guide for details on how to

configure individual relays.

Follow the steps below to configure the three global settings for

your relays.

Step 1: Press the MENU button.

Step 2: I f you aren’t at the default screen, press or until

the display reads as shown below, then press

SELECT/ SAVE.

Step 3: Press until the display reads SET ALL RELAYS, then

press SELECT/ SAVE.

Step 4: Press or to toggle through the relay type choices.

Set your global relay type and press SELECT/ SAVE.

The system automatically saves the configuration change you

just made and displays the next menu item.

MAIN MENU SELECT

SYSTEM SETTINGS

SET ALL RELAYS

ALL RELAY TYPE

LATCH (DEFAULT)

EZ-MAX Plus QuickStart.book Page 10 Thursday, January 22, 2009 1:55 PM

SET ALL RELAYS
