LevelOne WUS-3200 Manual de usuario
LevelOne
WUS-3200
11g Wireless 2-port USB2.0
MFP Server
User’s Manual
Ver 2.00-0511
2
Table of Contents
CHAPTER1 INTRODUCTION............................................................................ 1
1.1 About this Manual .......................................................................................... 1
1.2 Support Services............................................................................................. 1
CHAPTER2 PRODUCT OVERVIEW................................................................. 2
2.1 Package Contents........................................................................................... 2
2.2 WUS-3200 USB MFP Server Product CD ..................................................... 2
2.3 Physical Description ....................................................................................... 3
2.4 Installation Methods....................................................................................... 5
2.5 Features and Benefits..................................................................................... 6
CHAPTER3 BASIC INSTALLATION................................................................. 7
3.1 Connecting the Hardware .............................................................................. 7
3.2 Wireless connection........................................................................................ 7
3.3 Assigning an IP Address to the MFP Server ................................................ 15
3.4 Naming Your USB Devices............................................................................ 20
CHAPTER4 ADDING PRINTERS IN WINDOWS ......................................... 23
4.1 Overview of Installation Methods ................................................................ 23
4.2 Connecting WUS-3200 MFP Server ............................................................ 23
4.3 Setting up Local Windows Printer Driver .................................................... 25
4.4 Adding Network Printers in Windows .......................................................... 25
4.4.5 Using Standard Windows Methods for SMB/CIFS Printing ........................ 35
CHAPTER5 ADDING PRINTERS IN UNIX/LINUX ........................................ 41
5.1 Configuring Host File .................................................................................. 41
5.2 Printing by LPD/LPR ................................................................................... 41
5.3 Using WUS-3200 on BSD UNIX/Linux........................................................ 41
5.4 Using WUS-3200 on RedHat Linux (Fedora Core) ..................................... 43
CHAPTER6 FILE SERVER FUNCTION ......................................................... 50
6.1 Preliminary................................................................................................... 50
6.2 Storage Names.............................................................................................. 50
6.3 Connecting USB Mass Storage to WUS-3200.............................................. 50
6.4 Supported Code Pages ................................................................................. 51
6.5 Adding Your USB Mass Storages to Network with Security.......................... 53
CHAPTER7 SCAN SERVER FUNCTION........................................................ 59
3
7.1 Connecting HP All-in-one MFP to WUS-3200 ............................................ 59
7.2 Using the Shared Scanner in Windows......................................................... 59
7.3 Using the Shared Scanner in Linux.............................................................. 64
CHAPTER8 MFP SERVER CONTROL CENTER.......................................... 66
8.1 Installing MFP Server Control Center......................................................... 66
8.2 Using MFP Server Control Center............................................................... 66
CHAPTER9 MFP SERVER’S WEB PAGES .................................................... 75
9.1 Introduction .................................................................................................. 75
9.2 Using Server’s Web Pages............................................................................ 75
CHAPTER12 TROUBLESHOOTING ................................................................ 87
12.1 LED Indicators............................................................................................. 87
CHAPTER13 RESTORE FACTORY DEFAULT ............................................... 89
13.1 Using Server’s Web Pages............................................................................ 89
13.2 Using MFP Server Control Center............................................................... 90
13.3 Using Init Button .......................................................................................... 90
13.4 Default Parameters List ............................................................................... 91
CHAPTER14 UPGRADE NEW FIRMWARE .................................................... 93
CHAPTER15 INIT BUTTON ............................................................................... 97
CHAPTER16 TECHNICAL SPECIFICATIONS ............................................... 99
CHAPTER17 APPENDIX ................................................................................... 101
1
Chapter1 Introduction
Thank you for purchasing the WUS-3200 USB MFP server. This product is
designed to connect your printers, USB Mass Storage/Memory Card Reader,
and scanners of HP all-in-one printers (MFP), anywhere in your wired or
wireless network, allowing all network users access to shared USB devices
resources.
1.1 About this Manual
This manual provides introductory information as well as detailed instructions
on how to set up and manage the print server in various network
environments. To fully benefit from this manual, you should be familiar with
basic networking principles.
These instructions are based on the settings in a new MFP server. To reload
the Factory Parameters, you can perform a Factory Default, which will restore
most of the settings. See “Factory Default” on page.
1.2 Support Services
Should you require any technical assistance, please contact your product
reseller. Or you can visit our website at http://www.level1.com for latest
product information.
This manual is subject to change without notice.
2
Chapter2 Product Overview
2.1 Package Contents
Verify that nothing is missing from the WUS-3200 USB MFP server package
by using the checking list below. Please contact your dealer if anything is
missing or damaged. All packing materials are recyclable. Please confirm
the items in the Package below:
●One WUS-3200 USB 2.0/MFP Server.
●One WUS-3200 MFP Server Control Center Software CD.
●One AC Adaptor.
●This Quick Installation Guide.
2.2 WUS-3200 USB MFP Server Product CD
The WUS-3200 USB MFP Server Product CD provides an easy-to-use control
center software for Windows PC, and user documents.
2.2.1 Start-up Procedures for Windows
If your computer is configured to auto start CDs, the WUS-3200 USB MFP
Server Product CD will start automatically when inserted. You can also
navigate to the CD and start the autorun.exe file from within the Windows file
manager.
3
2.3 Physical Description
2.3.1 Ethernet Connector
The network connector of WUS-3200 is designed for 10 Mbps or 100 Mbps
Ethernet networks and connects to the network via a twisted pair category 5
cable (10baseT and 100baseTX) or better.
2.3.2 Wireless
The wireless network access (802.11b/g) is enabled by inner antenna.
2.3.3 USB Host Ports
WUS-3200 has two USB host ports which are USB 1.1/2.0 low, full and high
speed compliant and successfully tested with USB 1.1/2.0 printers, Mass
Storage and HP all-in-one (HPAIO) series printers (MFP).
2.3.4 Init Button
The Init button is used for:
printing a page of configuration report to check the connection to the
printer and showing the MFP server settings
performing a Factory Default of the MFP server, which will restore
USB Port 1
USB Port 2 Init Button
Power Adaptor
Connector
Ethernet
Connector
Indicators
PowerLAN
WLAN
USB1USB2
4
most of the parameters and settings to factory default values
performing the new firmware upgrade using in fallback. Please refer
to Chapter 14, procedure C for detail description.
2.3.5 Indicators
Power Indicator is lit while power is applied. If it is not lit, or if it blinks,
there is a problem with MFP server or Power Adapter.
LAN Indicator is lit while Ethernet network is applied. If it is not lit, it
indicates that the server does not connect to Ethernet network.
Wireless Indicator is lit while wireless network is applied. If it is not lit,
it indicates that the server does not connect to wireless network (in
the last firmware implementation, wireless station mode access is
disable while Ethernet network is applied).
USB1 Indicator is lit while an USB device connects to USB1 Port of
MFP server. If it is not lit, or if it blinks, there is a problem with the USB
device or the MFP server.
USB2 Indicator is lit while an USB device connects to USB2 Port of the
MFP server. If it is not lit, or if it blinks, there is a problem with the USB
device or the MFP server.
5
2.4 Installation Methods
2.4.1 Installation and Integration
Refer to the table below to select the appropriate installation method. MFP
Server Control Center tool is available on the WUS-3200 USB MFP Server
Product CD or from LevelOne’s web site.
Function OS Method Description
Standard
Windows Add
Printer Wizard
Installation of LPR, Raw TCP
(JetDirect), Local Port Using
SMB, and IPP
Windows MFP Server
Control Center
Tool
Installation of LPR, Raw TCP,
Local Port Using SMB
Apple MAC
OS x Printer Setup Tool LPR, Raw TCP (JetDirect)
SMB, IPP
Edit /etc/printcap
File
Using vi or other editors to
edit the printcap file
Print
Server
Unix/Linux RedHat Linux
Printer System
Manager
Using X-Windows Interface
to operate
Windows None Don’t need installation
Apple MAC
OS X None
File
Server
Unix/Linux Samba Use smbclient in Samba
Windows
MFP Server
Control Center
tool
Installation of SANE Client
and SANE-Twain Driver
Apple MAC
OS X
Download and
install SANE Use terminal
Scan
Server
Unix/Linux
Download and
install SANE
Frontends
Use SANE Applications such
as XSANE
2.4.2 Configuration and Management
WUS-3200 USB MFP server can be configured and managed from its internal
web pages, using HTTP or from user software: WUS-3200 MFP Server Control
6
Center, using Windows. These web pages or PC tools offer you a
management tool that is suitable for all supported network environments.
2.5 Features and Benefits
WUS-3200 provides the following features and benefits:
1. Reliability: The MFP server provides high performance and
reliability combined with low power consumption.
2. Flexibility: The MFP server supports print/File/Scan sharing in all
major computer systems and environments.
3. Portability: Wireless connectivity eases the setup and movement
of the MFP + MFP server in your home or office environment.
4. Easy to Install: The MFP server installs, operates and is managed
in a reliable and easy fashion.
5. Security: You can assign administrator name and password to
restrict login, and wireless access can be secured by WEP64, WEP128,
or WPA-PSK/TKIP.
6. Monitoring: The MFP server’s web pages and user software allow
you to continuously monitor MFP status.
7. Future Proof: The firmware stored in the MFP server Flash memory
can be upgraded over the network. This allows you to quickly update
and enhance its operational features when new MFP server software
becomes available.
7
Chapter3 Basic Installation
3.1 Connecting the Hardware
1. Make sure that your USB devices are switched off and that the MFP
server’s Power Adapter is disconnected.
2. Connect the USB devices to the USB ports using the USB cables.
3. Connect the MFP server to the network using a twisted pair category 5
cable, 10baseT or 100baseTX (after the wireless parameters are set
correctly, that cable should be removed to let wireless station mode
work).
After the wireless parameters are set correctly, that cable should be
removed to let wireless station mode work. However, LAN access is still
referable, and can work together with wireless ad-hoc mode.
4. Turn on the USB devices and make sure it is ready for use.
5. Connect the Power Adapter to the server. The power indicator will light
up and USB1 and USB2 indicators will flash in turn. When the Link
indicator lights up, the server is correctly connected to the network.
When US B1 an d USB2 indicators do not flash, th e ser ve r starts to wo rk
normally.
6. If you connected USB HP printers to server, please press the Init
button for 3 seconds on the server once to print a page of server
configuration report.
3.2 Wireless connection
3.2.1 Preliminary
Before you can access wireless network, wireless parameters should
be set correctly. You have to setup the first wireless parameter set
through LAN connection.
Wireless access can be set as 1. Infrastructure (station) mode, which
need an access point to route network messages, or 2. Ad-hoc mode,
which connect nearby wireless PC/devices with the same SSID
(Service Set ID).
Wireless access can be secured by WEP64, WEP128, or
WPA-PSK/TKIP.
In infrastructure mode, if network administrator wants to change any
security related parameters, WUS-3200 should be changed first,
Tabla de contenidos
Otros manuales de Servidor de LevelOne
LevelOne
LevelOne FNS-1000 Manual de usuario
LevelOne
LevelOne FUS-3100 Manual de usuario
LevelOne
LevelOne ServCon FPS-3003 Manual de usuario
LevelOne
LevelOne FUS-3100 Manual de usuario
LevelOne
LevelOne FUS-3101 Manual de usuario
LevelOne
LevelOne FPS-1031 Manual de usuario
LevelOne
LevelOne 4-bay Sata NAS w/2 Gigabit Ethernet... Manual de usuario
LevelOne
LevelOne FUS-3100 Manual de usuario
LevelOne
LevelOne FCS-7011 Manual de usuario
