Letsfit IW1 Manual de usuario
10000
10
FRI
IW1
Smart Watch
User Manual
Thank you for purchasing our products. This manual addresses the
safety guidelines, warranty, and operating instructions. Please
review this manual thoroughly before operating your device.
All pictures in this manual are for illustration purpose only. Actual product
may vary due to product firmware upgrade and app upgrade.
Table of Contents
English Version .................................................... 1
Getting Started................................................................1
What’s in the Box ...............................................................1
What’s in this Document ....................................................1
Setting up Your Watch..................................................1
Charging Your Watch .........................................................1
Disassembling / Assembling Your Watch...........................2
Wearing Your Watch......................................................4
Using Your Watch...........................................................5
App Installation ..................................................................5
Account Registration and Login ........................................6
Pairing the Watch with Your Phone....................................7
App Interfaces....................................................................9
Getting to Know Your Watch.....................................11
Basic Operation ................................................................11
Watch Interfaces ...............................................................11
Function Introduction..................................................13
1. Tracking Sports .............................................................14
2. Tracking Daily Activity Data...........................................15
3. Monitoring Heart Rate...................................................15
4. Measuring Blood Oxygen Level ....................................16
5. Breathing Guide ............................................................17
6. Setting Alarms ...............................................................17
7. Controlling Phone Music ...............................................17
8. More Functions .............................................................18
8.1 Call Notification.......................................................18
8.2 Message Notification...............................................18
8.3 Sedentary Reminder ..............................................18
8.4 Stopwatch ...............................................................18
8.5 Timer.......................................................................19
Basic Specifications.....................................................
19
FAQs ..................................................................................
20
Warranty ...........................................................................
22
Important Safety Instructions
...................................22
- 1 -
What’s in the Box
Getting Started
Setting up Your Watch
What’s in this Document
This manual gets you started quickly with setting up your watch.
Setup ensures that your watch can synchronize its data with the
Letsfit app, where you can get detailed information on your
stats, view historical trends, log sleep, and more. As soon as
setup is complete, you’re ready to start moving. The remainder
of the manual walks you through every function on your IW1.
Charging Your Watch
Please fully charge your watch before initial use.
1. Insert the USB plug of the charging cable into the USB port
on your computer or a UL-certified USB wall charger.
2. Hold the other end of the charging cable near the port on
the back of the watch until it attaches magnetically.
3. Make sure the pins on the charging cable lock securely with
the port. The connection is secure when the watch vibrates
and the battery icon with percent charged appears on the
screen.
Charging cable User manualSmart watch
(IW1 with bands)
Quick start
guide
Quick Start
Guide
IW1
Smart Watch
User Manual
Thankyou for purchasing our products. This manual addresses the
safetyguidelines, warranty, and operating instructions. Please
reviewthis manual thoroughly before operating your device.
Allpictures in this manual are for illustration purpose only. Actual product
mayvary due to product firmware upgrade and app upgrade.
1
- 2 -
When the watch shows that the battery is
low, connect the watch to a USB port with
5V-500mA.
While the watch charges, there is a battery
progress circle on the screen and you can
check the battery level at any time.
4. Remove the watch from the power supply once fully charged.
● USB charger requirement: DC USB port (5V-500mA)
● Charging time: Approximately 2 hours
Disassembling / Assembling Your Watch
Disassembly
1. To remove the wristbands, turn over the watch and find the
quick-release lever.
2. While pressing the quick-release lever inward, gently pull the
wristband away from the watch to release it.
- 3 -
3. Repeat on the other side.
Assembly
1. To reattach the wristbands, slide the pin (the side opposite
the quick-release lever) into the notch on the watch. Attach
the wristband with the clasp to the top of the watch.
2. While pressing the quick-release lever inward, slide the
other end of the wristband into place.
3. When both ends of the pin are inserted, release the
quick-release lever.
All-day Wear and Exercise
Wearing Your Watch
- 4 -
For all-day wear when you’re not exercising, wear the device
on your wrist horizontally, a finger’s width below your wrist
bone and lying flat, the same way you would put on a watch.
For optimized heart rate tracking, keep these tips in mind:
1. Experiment with wearing the watch higher on your wrist during
exercise. Because the blood flow in your arm increases the
farther up you go, moving the watch up a couple of inches can
improve the heart rate signal. Also, many exercises such as
bike riding or weight lifting require you to bend your wrist
frequently, which is more likely to interfere with the heart rate
signal if the watch is lower on your wrist.
2. Do not wear your watch too tight. A tight band restricts blood
flow, potentially affecting the heart rate signal. This being
said, the watch should also be slightly tighter (snug but not
constricting) during exercise than during all-day wear.
- 5 -
Using Your Watch
App Installation
Use the watch with our customized Letsfit app. You can
download Letsfit from App Store / Google Play or scan the QR
codes below to download.
AndroidiOS
Letsfit
Note:
The Letsfit app is only compatible with smartphones, not
tablets or PCs.
● iOS 11.0 & higher
● Android 6.0 & higher
● Bluetooth 4.0 & higher
Smart Phone System Requirements
- 6 -
Account Registration and Login
Please register an account with a valid email address. After
registration, check your email box to complete email
verification, and then tap "Verified" to log in.
- 7 -
Please pair the watch with your phone in the Letsfit app,
NOT in the Bluetooth settings of your phone.
1. Enable the Bluetooth of your smartphone.
2. Open the Letsfit app on your smartphone and go to the
"Settings" page, tap "+ Pair new device".
3. Tap "IW1", and your smartphone starts scanning.
4. Select the watch language on the watch and enter the QR
code interface as instructed.
5. Use the Letsfit app to scan the QR code displayed on your
watch to connect the watch to your smartphone.
Pair the watch with your
smartphone in the Letsfit app
Do NOT pair the watch
with your smartphone
in your phone’s
Bluetooth settings
iOS Android
Pairing the Watch with Your Phone
- 8 -
1 2 3
+ Pair new device
IW1
Notes:
● You can also search this device in the app to pair (Go to
"Settings" page → "+ Pair new device" → "IW1" → tap "Search
Devices").
● Once the watch is connected to your app, the watch will
automatically search and reconnect itself if the connection is
lost or when Bluetooth is restarted after manual disconnection.
● If you unpair the watch with the app, the information on the
watch will be reset and the watch will be restarted. Please do
not unpair the watch with the app unless there is an issue that
will require a reset.
● The watch can only pair with one smartphone at a time. When
pairing, please ensure the watch and your smartphone is
within 0.5 meters distance.
