Preface and general information
1 Preface and general information
The EEPM1RA EPM programmer enables you to easily duplicate and archive the memory and configuration of inverter
drives and servo controllers that utilize the EPM feature.
The EEPM1RA EPM programmer enables you to:
• copy the contents of one EPM to another EPM,
• read out contents of EPMs and save them to a PC or the EPM programmer as files,
• edit files stored in the EPM programmer,
• store edited files under another file name and create new files,
• copy files stored in the EPM programmer into EPMs.
1.1 About these Operating Instructions
This documentation applies to the EPM Programmer as of version:
Type: EEPM1RA
For detailed nformation refer
to instruction manual EP01x
EEMP1RA 1A 10
Made in USA
EPM Programmer
L
LISTED
ND
CONT EQ
5D81
xxxxx xx xx
6VDC 150mA min
Power Supp y
(FRIWO 7207/06 15 0791 MPP15)
A B C
epm010
AType EEPM1RA
BHardware version 1A
CSoftware version 10
• These Operating Instructions are designed to ensure safe and trouble-free working with the EEPM1RA EPM
programmer.
• Before you start working with the EEPM1RA EPM programmer, please read the Operating Instructions carefully and
follow the notes.
• These Operating Instructions must always be kept as a complete legible document.
1.2 Terminology used
Term Meaning in this document
Drive controller Lenze - AC Tech submicro frequency inverter
Servo controller Lenze - AC Tech SimpleServo, PositionServo
3
ENGLISH
Preface and general information
1.3 EPM Technology and Operation
The EPM uses EEPROM technology housed in a removable plastic
casing for protection and ruggedness. A removable memory
structure, as provided by an EPM include:
• Programming a drive without power.
• Easily duplicate proven programs using the EPM Programmer.
• Reduce down-time and troubleshooting.
The EPM feature is included with several Lenze and AC Tech inverter
drive controllers and in the new SimpleServo products. Operation and
some functionality differ between the Drive and Servo product lines.
epm011
Drive Controllers EPM Color: Blue
EPM files can be stored in EPM Programmer
Servo Controllers EPM Color: Blue (Model 94)
EPM files cannot be stored in EPM Programmer
OEM Defaults
The EPM, when used in Inverter Drive Controllers, actually contains two sets of drive parameters. The USER memory is
the memory the drive typically uses for operation and is actually the drives operating memory that can be accessed and
changed from the front of the drive, a remote keypad or serial communications. The OEM Default values can only be written
by the EPM Programmer and cannot be altered through normal drive operation or programming. This provides a benefit
in that an OEM using the EPM Programmer to quickly copy the drive configuration, actually ships the drive with their own
“Factory Defaults”.
Lenze Servo Controllers are programmed using MotionView94 Software via serial link with a PC. Field reprogramming from the
front of the controller is not possible. As such, resetting to OEM defaults is impossible and this second memory set is not used.
1.4 Pictographs used in these Operating Instructions
Pictograph used Signal words
Stop! Warns of possible malfunctions of the EPM Programmer due to
electrostatic discharge (ESD)
Tip! Designates a general and useful note. If observed, it will make using the
EPM Programmer easier.
1.5 Scope of delivery
Scope of delivery Important
• 1 EEPM1RA EPM programmer with 4 batteries (already
installed)
•1 Operating Instructions
After receipt of the delivery, check immediately whether
the items delivered match the accompanying papers.
Lenze does not accept any liability for deficiencies claimed
subsequently.
Claim
•visible transport damage immediately to the forwarder.
• visible deficiencies / incompleteness immediately to
your Lenze representative.
4ENGLISH
Technical data
2 Technical data
2.1 General data and application conditions
Field Values
Type of Protection IP20
Permissible temperature ratings Operation 0 … +50 °C
Transport -20 … +60 °C
Storage -20 … +60 °C
Humidity <85 %, without condensation
Weight 1.3 kg with batteries
Applied Standards Noise emission to EN 50081-2: 1993
Noise immunity to EN 61000-6-2 : 1999
Approvals UL 508C Underwriters Laboratories
Power Conversion Equipment
Conformity CE EMC Directive (89/336/CEE)
2.2 Electrical Data
Field Values
DC Voltage Supply + 6 VDC, min. 150 mA
Internal Batteries 4 mono-cells (type D), 1.5 VDC each
External power supply unit + 6 VDC, 300 mA
Display Type LCD
Display format Text
Lines x characters 1 x 16
Contrast setting Via menu
Memory Data Memory up to 120 parameter files for inverter
drive controllers
Serial Interface DB9 Connector RS232
5
ENGLISH
Technical data
2.3 Dimensions
COPY
105
76
155
4
epm001
Dimensions in mm
6ENGLISH
Commissioning
3 Commissioning
3.1 Battery Operation
The EPM programmer is immediately ready for operation. It is delivered with 4 batteries
(1.5 V mono-cells).
3.2 Changing Batteries
For battery operation you need four mono-cell (D size) with 1.5V each. In order to access the battery compartment, you
must open the housing of the EPM programmer.
epm007
Open the battery compartment of the EPM programmer
1. Remove the 5 screws on the bottom of the EPM programmer
2. Remove the EPM Programmer base plate carefully.
epm004
Insert the batteries into the battery compartment
1. Insert the batteries into the battery compartment as shown in figure above.
- Pay attention to the correct polarity of the batteries!
2. Replace the base plate carefully and secure the housing with the 5 screws.
7
ENGLISH
Commissioning
3.3 Operation with external power supply
Stop!
• Avoid electrostatic discharges (ESD) at the connector for the voltage supply. EPM programmer malfunction
may occur.
• Take appropriate measures to avoid electrostatic conditions.
• Occasionally occurring malfunctions can normally be remedied by switching the EPM Programmer off and then
on again.
It is also possible to operate the EPM programmer with an external power supply.
Power supply output data:
• Output voltage: 6 VDC, stabilized
• Output current: 300 mA
Power supply connector plug details
For connections to the EPM programmer the power supply
unit requires an extra-low voltage plug with the following
dimensions: 2.1 × 5.5 × 9.5 mm.
Connect the power supply unit
A
Type EEPM1RA
For deta led nformation refer
to nstruction manual EP01x
EEMP1RA 1A 10
Made in USA
EPM Programmer
L
L STED
IND
CONT EQ
5D81
xxxxx xx xx
6VDC 150mA min
Power Supply
FRIWO 7207 06 15 0791 MPP15)
epm006
Plug the extra-low voltage plug of the power supply into the Aconnector at the back of the EPM Programmer
+6 VDC
–
epm005
8ENGLISH
Operation
4 Operation
4.1 Overview of operating elements
epm001
COPY
Display
MASTER PORT
Plug-in-station for EPM from which the data is to be read.
EPM Port
Plug-in-station for EPM memory chip on which the data is to
be written.
Operator Keypad
4.2 Key Functions
Key Level Function
ON
Switch on EPM programmer
OFF
Switch off EPM programmer
MENU
Menu level: Select menu, quit submenu
Parameter level: Return to the main menu without saving changes
ENTER
Menu level: Select submenu, execute menu command
Parameter level: Select parameter to enter a value, accept a value entered
Menu level: Select submenu/file
Parameter level: Enter a higher value
Menu level: Select submenu/file
Parameter level: Enter a lower value
BACK
LIGHT
Switch on/off background illumination for the display
COPY
TO EPM
Copy data to EPM PORT
