Lenovo TB-X705F Manual de usuario

Lenovo Tab P10

User Guide

Lenovo TB-X705F

Lenovo TB-X705L

All information labeled with * in this guide refers only to the WLAN+LTE model

(Lenovo TB-X705L).

Basics

Before using this information and the product it supports, be sure to read the following:

Safety, Warranty & Quick Start Guide

Regulatory Notice

“Important safety and handling information” in "Appendix".

The Safety, Warranty & Quick Start Guide and the Regulatory Notice are available on the

website at http://support.lenovo.com.

Note: All pictures and illustrations in this document are for your reference only and may

differ from the final product.

Lenovo Help

Looking for help? The Lenovo Companion app can offer you support for getting direct access to

Lenovo's web assistance and forums*, frequent Q&A*, system upgrades*, hardware function

tests, warranty status checks*, service requests**, and repair status**.

Note:

* requires data network access.

** is not available in some countries.

You have two ways to get this app:

Search for and download the app from Google Play.

Scan the following QR code with a Lenovo Android device.

Technical specifications

Model Lenovo TB-X705F Lenovo TB-X705L

CPU Qualcomm® Snapdragon™ 450 Qualcomm® Snapdragon™ 450

Battery 7000mAh 7000mAh

Wireless

communication

Bluetooth 4.2; WLAN 802.11

a/b/g/n/ac,2.4GHz & 5GHz;

GPS/GLONASS;

Bluetooth 4.2; WLAN 802.11

a/b/g/n/ac, 2.4GHz & 5GHz;

GPS/A-GPS/GLONASS; FDD-LTE,

TDD-LTE, WCDMA;

Note: Lenovo TB-X705L supports LTE Band 1, 3, 5, 7, 8, 19, 20, 38, and 40,but in some

countries, LTE band is not all supported. To know if your device works with LTE networks

in your country, contact your carrier.

Home screen

The home screen is the starting point for using your device. For your convenience, the home

screen is already set up with some useful apps and widgets.

Note: Your device's features and the home screen may be different depending on

your location, language, carrier, and device model.

You can customize your home screen at any time.

Home screen

On home screen, there is a Google search bar and some useful apps.

Preview screen

Press and hold anywhere on the home screen except the icons.

There are WALLPAPERS, WIDGETS, and HOME SETTINGS at the bottom of the screen.

Add a widget to a home screen

Tap at the bottom of the preview screen, press and hold the widget you want to add,

then drag it to where you want to place it, and then release it.

Change the wallpaper

Press and hold anywhere on the home screen except the icons, select WALLPAPERS at

the bottom of the screen, and then choose the wallpaper that you like.

Go to Settings > Display > Advanced > Wallpaper and choose the wallpaper that you

like.

Move an app to another screen

Press and hold the app that you want to move, drag it to the left or right side of the

screen, and then release it.

Uninstall an app

1. Press and hold an app that you want to uninstall.

2. Drag the app to , and then release it and tap OK.

Note: Some of the system apps cannot be uninstalled.

Buttons

There are three buttons in the taskbar.

Back button: Tap to return to the previous page.

Home button: Tap to return to the default home screen.

Recent button: Tap to see recent apps. Then you can do the following:

Tap an app to open it.

Slide the application to the left or right to close it.

Tap to lock the app or tap to unlock it.

Tap to stop running the app.

Tap to stop running all the apps.

Notifications and Quick Settings

The Notifications panel informs you of new messages, USB connection, and activities in

progress, such as file downloading. The Quick Settings panel allows you to access frequently-

used settings such as the WLAN switch.

You can do any of the following:

To see notifications, swipe down from the top of the screen.

To close the Notifications panel, swipe up from the bottom of the screen.

To dismiss a notification, swipe left or right across the notification.

To dismiss all notifications, tap CLEAR ALL at the bottom of the Notifications panel.

To open the Quick Settings panel, swipe down from the top of the screen; you can view all

Settings in the Quick Settings panel by swiping down twice.

To close the Quick Settings panel, swipe up from the bottom of the screen.

Shortcut

You can quickly start commonly used functions of applications by shortcut.

Note: only some applications support this function.

Quickly start commonly used functions of applications

Press and hold the icon of an application,and then tap the function you want to start in the

Commonly Used Application Functions list.

Add shortcuts to the home screen

1. Press and hold the icon of an application.

Note: press and hold the icon of an application and tap to view more commonly used

functions.

2. To create a shortcut, press and hold the commonly used function in the Commonly Used

Application Functions list, and then drag it to the home screen.

Remove shortcuts

Press and hold the shortcut that you want to delete, and then drag it to X.

Force shutdown/restart

Press and hold the power button for about 10 seconds until the device turns off. Then turn it on

again in the normal way.

Productivity Mode

Go to Settings > Productivity mode to turn it on.

Navigation bar

Recent app icons are displayed in the navigation bar. You can do any of the following:

To open an app, tap its icon.

To display all the recent apps , you can click on the left or right of the navigation

bar.

To adjust the order of the icons in the navigation bar, press and hold an app icon until it

enlarges slightly, drag it to where you want to place it, and then release it.

To close an app, press and hold the app until its icon enlarges slightly, drag it upwards,

and then release it.

Split screen mode

Using split screen mode

Method 1:

1. Open an app and then tap .

2. Press and hold the first app, drag it to "Drag here to use split screen" , and then

release it. The app will be locked into position.

3. Choose the second app you want to open. The two apps will then be displayed in split

screen mode.

Method 2:

1. Open an app and then press and hold . This app will be locked into position in split

screen mode.

2. Choose the second app you want to open. The two apps will be displayed in split

screen mode.

Note: Not all applications support split screen mode.

Split screen settings

In split screen mode you can do the following:

Replace the second app:

Tap to choose another app in the application list, or tap an app icon in the navigation

bar.

Close the first app:

Press and hold the app icon in the navigation bar until it enlarges slightly, and then drag it

upwards and release it.

Adjust the split screen size:

Slide the in the middle of the two screens to adjust the split screen size.

Exiting split screen mode

You can exit split screen mode by:

Pressing and holding to enter full screen mode.

Choosing an app that doesn't support split screen mode.

Multi-User

There are three user types:

Owner: An owner has full control over all user permissions and manages all user

accounts.

Guest: There is only one Guest account. A guest has restricted access to the device.

New User: There can be multiple user accounts, including standard users and child users.

A standard user can manage child user accounts. In child user accounts, there are many

child-friendly apps available, including videos, games, music, and more. Content can be

managed in Parental Control.

Creating new user accounts

Tap Settings > Users & accounts > Users > ADD USER to create user accounts.

Tap to create a standard user account.

Tap ,or tap on the first home screen to create a child user account.

Note: Before you add a child user account, you need to set up a screen lock to

protect your apps and personal data.

Switching between user accounts

On the home screen, swipe down from the top of the screen and tap , and then tap

, and tap user photos to switch between different user accounts.

On the lock screen interface, select the user photos of the accounts you want to

switch, and then tap and swipe up to switch the user accounts.

Note: If users have set fingerprints for lock screen security, the fingerprints of

these users can be used to switch between accounts.

Deleting a user account

Tap Settings > Users & accounts >Users，and tap the icon located beside the

account you would like to delete, then tap DELETE USER > DELETE.

Network

You need to set up a wireless network before connecting to the Internet.

Set up a WLAN network.

*Set up a mobile network.

Set up a VPN network.

*Set up a hotspot.

Setting up a WLAN network

1. Tap Settings > Network & Internet >WLAN.

2. Turn on the WLAN switch and tap a hotspot in the list to connect to the Internet.

When you are connecting to a secure hotspot, you need to enter your login name and

password to connect.

*Setting up a mobile network

Tap Settings > Network & Internet >Data usage.

Note: You need a valid SIM card with data service. If you don't have a SIM card, contact

your carrier.

Setting up a VPN network

VPNs are used within organizations to allow you to communicate private information securely

over a non-private network. You may need to configure a VPN, for example, to access your

work email. Ask the network's administrator for the settings necessary to configure a VPN for

your network:

1. Tap Settings > Network & Internet >VPN.

2. Tap to edit the VPN profile, including the server name, type, and the server address,

and then tap SAVE.

3. Tap the VPN server name, enter the username and password, and then tap CONNECT to

connect to the VPN network.

4. Tap to edit or delete the VPN.

Note: You need to set a lock screen pattern, PIN or password before using a VPN. Go to

Settings > Security & Location > Screen lock to select a screen lock option and set up the

screen lock.

*Setting up a hotspot

You can use a personal hotspot to share an Internet connection with a computer or other

device.

Tap Settings > Network & Internet >Hotspot & tethering.

Turn on WLAN hotspot.

Tap Set up WLAN hotspot to configure the hotspot.

You can also use Bluetooth tethering or USB tethering.

Note: Tell your friends the Network name and password, and then they can share your

mobile network.
