Lenovo TAB3 10 Plus Manual de usuario
Lenovo TAB3 10 Plus
User Guide
Lenovo TB3-X70F
Lenovo TB3-X70L
All information labeled with * in this guide only refers to the WLAN +
LTE model (Lenovo TB3-X70L).
Basics
Before using this information and the product it supports, be sure to read the
following:
Safety, Warranty & Quick Start Guide
Regulatory Notice
"Important safety and handling information" in "Appendix".
The
Safety, Warranty & Quick Start Guide
and the
Regulatory Notice
are available on
the website at http://support.lenovo.com.
Lenovo Companion
Looking for help? The Lenovo Companion app can offer you support for getting direct
access to Lenovo's web assistance and forums*, frequent Q&A*, system upgrades*,
hardware function tests, warranty status checks*, service requests**, and repair
status**.
Note:
* requires data network access.
** is not available in all countries.
You have two ways to get this app:
Search for and download the app from Google Play.
Scan the following QR code with a Lenovo Android device.
Technical specifications
Model Lenovo TB3-X70F Lenovo TB3-X70L
CPU MTK MT8161 MTK MT8735
Battery 7000 mAh 7000 mAh
Wireless
communication Bluetooth 4.0; GPS+GLONASS;
WLAN 802.11 a/b/g/n/ac;
Bluetooth 4.0; GPS+GLONASS;
WLAN 802.11 a/b/g/n/ac;
*LTE/TD-
SCDMA/WCDMA/CDMA2000/GSM
Note: Lenovo TB3-X70L supports LTE Band 1, 3, 7, 8, 20, 38, 39, 40 and 41. But in
some countries, LTE is not supported. To know whether your Lenovo TB3-X70L works
with LTE networks in your country, contact your carrier.
Home screen
The home screen is the starting point for using your device. For your convenience,
the home screen is already set up with some useful apps and widgets.
Note: Your device features and the home screen may be different, depending
on your location, language, carrier, and device model.
You can customize your own home screen at any time.
Home screen
On the first home screen, there is a Google Search bar.
Preview screen
Tap and hold anywhere on the home screen except the icons.
At the bottom of the screen appear Wallpapers, Lockscreen Wallpaper
and Widgets.
Add a widget to home screen
Tap at the bottom of the preview screen, tap and hold the widget you
want to add, then drag to where you want to place it and release.
Change the wallpaper
Go to Settings > Display > Wallpaper and choose the wallpaper that you
like.
Tap and hold anywhere on the home screen except the icons, select
Wallpapers at the bottom of the screen, and then choose the wallpaper that
you like.
Move an app to another screen
Tap and hold an app that you want to move, drag it to the left or right side
of the screen, then release it where you want to place it.
Uninstall an app
1. Tap , and then tap and hold an app that you want to uninstall.
2. Drag to at the top of the screen until the app turns red, and then
release and tap OK.
Note: Some of the system apps cannot be uninstalled.
Screen buttons
There are four buttons at the bottom of the home screen.
Multi-window button: Tap to open the multiple apps.
Back button: Tap to return to the previous page.
Home button: Tap to return to the default home screen.
Recent button: Tap to see the recent apps. Then you can do the
following:
Tap an app to open it.
Tap to lock the app or tap to unlock it.
Tap to stop running the app.
Tap to stop all the running apps except the locked ones.
Notifications and Quick Settings
Swipe down from the top of the screen to view system notification messages and
quick settings. By tapping on switch, you can quickly turn a number of frequently
used functions on or off.
Press and hold the On/Off button for more than 8 seconds until the screen goes
dark.
Force shutdown
Camera
To open the Camera app, go to Camera.
Taking photos and record videos
You can take photos and record videos with your device's built-in camera.
Tap to turn on/turn off the Smile mode.
Tap to turn on/turn off the HDR mode.
Tap to switch between the front and the back camera.
Tap to take a photo.
Tap to record a video.
Tap to configure other camera settings.
Tap to use the Normal mode.
Tap to use the Panorama mode.
Tap to set the shooting effect.
Taking screenshots
Press and hold the On/Off button and the Volume down button at the same time.
Viewing pictures and videos
Photos and videos are stored in your device's internal storage. You can view your
photos and videos by using the following methods:
Tap the photo review icon when using the Camera app.
Go to Gallery.
Screenshots are stored in your device's internal storage. You can view your
screenshots by Gallery.
Network
You need to set up a wireless network before connecting to the Internet.
Set up a WLAN network
*Set up a mobile network
Set up a VPN network
*You can also set up a hotspot to share your mobile network with others.
Setting up a WLAN network
Go to Settings > WLAN.
Turn on the WLAN and tap a WLAN hotspot in the list to connect to the Internet.
When you access a secure link, you need to enter your login name and password to
connect.
*Setting up a mobile network
Go to Settings > Data usage, tap CELLULAR and turn on Cellular data.
Note: You need a valid SIM card with a data service. If you don't have a SIM card,
contact your carrier.
Setting up a VPN network
VPNs used within organizations allow you to communicate private information
securely over a non-private network. You may need to configure a VPN, for example,
to access your work email. Ask the network’s administrator for the settings necessary
to configure a VPN for your network. When one or more VPN settings are defined
you can:
Note: You need to set a lock screen PIN or password before using VPN. Go to
Settings > Security > Screen lock to select a screen lock option and set up the
screen lock.
Go to Settings > More > VPN.
Tap to edit the VPN profile, including the server name, the type and the
server address, and then tap SAVE.
Tap the VPN server name, input the username and password, and then tap
CONNECT to connect to the VPN network.
Tap to edit or delete the VPN.
*Setting up a hotspot
You can use personal hotspot to share an Internet connection with a computer or
other device.
Go to Settings > More > Tethering & portable hotspot and do the following:
Turn on WLAN hotspot.
Tap Set up WLAN hotspot to configure the hotspot.
You can also use Bluetooth tethering and USB tethering.
Note: Tell your friends the Network SSID and password, and then they can share
your cellular network.
Internet
You can browse the web if your device is connected to a wireless network.
To open the browser app, go to Chrome.
Visiting websites
You can use the Chrome app to visit websites.
Type web address
You don't need to type the full web address of the "http://" website to access
it.
To visit "http://www.lenovo.com", simply type "www.lenovo.com" into the
address bar and tap .
Search keywords
You can also type keywords into the address bar to search for webpages.
You can set a search engine in > Settings > Search engine.
Add a new webpage
Tap the blank tab on the top, or tap > New tab to add a new webpage
tab.
Tap > New incognito tab to visit a website without leaving a trace.
