Lenovo Fingerprint Biometric USB Mouse

User Guide

http://www.lenovo.com/safety

Note: Before using this information and the product it supports ensure that you read and understand the

warranty information in the documentation that comes with the product.

First Edition (December 2017)

LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General Services

Administration “GSA” contract use reproduction or disclosure is subject to restrictions set forth in Contract No. GS-

35F-05925.

Contents

Chapter 1 About the mouse 1

Features. . . . . . . . . . . . . . . . . . . 1

System requirement . . . . . . . . . . . . . . 1

In the box . . . . . . . . . . . . . . . . . . 1

Parts and locations . . . . . . . . . . . . . . 1

Chapter 2 Setting up the mouse 3

Connecting the mouse to your computer . . . . . . 3

Installing the device driver . . . . . . . . . . . . 3

Uninstalling the device driver . . . . . . . . . . 3

Chapter 3 Using the fingerprint

reader 5

Enrolling your fingerprints . . . . . . . . . . . . 5

Scanning your finger . . . . . . . . . . . . . . 5

Maintaining the fingerprint reader . . . . . . . . . 6

Chapter 4 Troubleshooting 7

Appendix A Accessibility

information 9

Appendix B Trademarks 11

ii Lenovo Fingerprint Biometric USB Mouse User Guide

Chapter 1 About the mouse

This chapter provides product information about the Lenovo Fingerprint Biometric USB Mouse (referred to as

mouse).

Features

The Lenovo Fingerprint Biometric USB Mouse is a Universal Serial Bus (USB) mouse with a fingerprint reader

on the top of the mouse. After enrolling your fingerprints you can log in to your Windows operating system

by a simple touch on the fingerprint reader of the mouse without typing your Windows password.

Note: The fingerprint reader of the mouse does not interfere with that of the computer. They work

independently from each other.

System requirement

The mouse is supported on the Microsoft® Windows® 10 operating system.

In the box

Your option package includes the following:

• Lenovo Fingerprint Biometric USB Mouse

• Documentation

Contact your place of purchase if any item is missing or damaged. Ensure that you retain your proof of

purchase and packing material. They might be required to receive warranty service.

Parts and locations

1 Left button 2 Right button

3 Scrolling wheel 4 Fingerprint reader

2Lenovo Fingerprint Biometric USB Mouse User Guide

Chapter 2 Setting up the mouse

This chapter provides information about setting up the mouse.

Connecting the mouse to your computer

Connect the mouse cable to an available USB connector (Always On USB connector not recommended) on

your computer. You might need to wait for several seconds for your computer to detect the mouse. Then the

mouse is ready for use.

Installing the device driver

Ensure that the device driver for the mouse is installed on your computer before using the mouse.

If you have connected your computer to the Internet and Windows Update is enabled the device driver will

be automatically installed when you connect the mouse to the computer.

You also can download the latest device driver from the Lenovo® Web site. Go to http://www.lenovo.com/

support/mice. Select the entry for the mouse. Then follow the instructions on the screen to download and

install the device driver.

Uninstalling the device driver

To uninstall the device driver do one of the following:

• If the device driver is automatically downloaded from Windows Update:

1. Click the Start button to open the Start menu. Click Windows System ➙ Control Panel. Then view

Control Panel by Category.

2. Click Hardware and Sound ➙ Device Manager. If you are prompted for an administrator password

or confirmation type the password or provide confirmation.

3. Double-click Biometric devices to view all fingerprint devices.

4. Right-click Synaptics WBDI Fingerprint Reader - USB 061 to select Uninstall.

5. Follow the instructions on the screen to uninstall the device driver.

• If the device driver is downloaded from the Lenovo Web site:

1. Click the Start button to open the Start menu. Click Windows System ➙ Control Panel. Then view

Control Panel by Category.

2. Click Uninstall a program.

3. Right-click Synaptics WBF FP Reader to select Uninstall.

4. Follow the instructions on the screen to uninstall the device driver.

4Lenovo Fingerprint Biometric USB Mouse User Guide

Chapter 3 Using the fingerprint reader

Your mouse has a fingerprint reader. Fingerprint authentication can replace your Windows password. In this

way you can log in to your Windows operating system simply and securely.

Enrolling your fingerprints

To enable fingerprint authentication of the mouse enroll your fingerprints first. During the enrollment the

fingerprints are associated with the Windows password automatically. It is recommended that you enroll

more than one fingerprint in case of any injury to your fingers.

To enroll your fingerprints do the following:

1. Connect the mouse to your computer.

2. Open the Start menu and click Settings ➙ Accounts ➙ Sign-in options.

3. Scroll down to the Password section and click Add to create a Windows password.

4. Follow the instructions on the screen to create a Personal Identification Number (PIN).

5. Locate the Windows Hello section and click Set up under Fingerprint. Then click Get Started.

6. Enter the PIN you have set earlier.

7. Follow the instructions on the screen to finish the enrollment.

After the enrollment fingerprint authentication of the mouse is enabled. During the initial fingerprint

authentication if you are prompted for a PIN enter the PIN.

Scanning your finger

To scan your finger do the following:

1. Tap the fingerprint reader with the top joint of your finger and hold your finger there for one or two

seconds with a little pressure. Follow the instructions on the screen to lift the finger to complete one

scan.

2. Follow the instructions on the screen to complete several scans until the enrollment is completed.

Maintaining the fingerprint reader

Do not scratch the surface of the fingerprint reader with a hard pointed object or scrap it with your fingernail

or anything hard. Otherwise the reader could get damaged.

You might not be able to register or authenticate your finger if:

• The surface of the reader is wet dirty or stained.

• Your finger is wet stained with dirt mud or oil wrinkled rough dry or injured.

• The surface of your finger is different from the one when you enrolled your fingerprint.

• Your finger that you are currently using has not been enrolled before.

To improve the situation try the following:

• Gently clean the surface of the reader with a dry soft lint-free cloth.

• Clean or wipe your hands to remove any excess dirt or moisture from the fingers.

• Enroll and use a different finger for authentication.

6Lenovo Fingerprint Biometric USB Mouse User Guide
