Lenovo ThinkSmart View Plus Manual del propietario

ThinkSmart View Plus

Hardware Maintenance Manual

Read this first

Before using this documentation and the product it supports, ensure that you read and understand the

following:

• Safety and Warranty Guide

• Generic Safety and Compliance Notices

First Edition (May 2023)

IMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General Services

Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-

35F-05925.

Contents

Abo t this man al . . . . . . . . . . . . iii

Chapter 1. Prod ct Overview . . . . . . 1

Stylus Pen . . . . . . . . . . . . . . . . . . 1

Camera . . . . . . . . . . . . . . . . . . . 1

Soundbar . . . . . . . . . . . . . . . . . . 2

Monitor and stand . . . . . . . . . . . . . . . 3

Statement on USB transfer rate . . . . . . . . 5

Chapter 2. General checko t . . . . . . 7

Chapter 3. Hardware removal and

installation . . . . . . . . . . . . . . . . 9

Service tool kit . . . . . . . . . . . . . . . . 9

Major FRUs and CRUs . . . . . . . . . . . . 10

Board connectors . . . . . . . . . . . . . . 13

General Guidelines . . . . . . . . . . . . . 14

Remove the cable tie . . . . . . . . . . . . . 14

Remove the camera rubber . . . . . . . . . . 14

Remove the camera module . . . . . . . . . . 15

Remove the Soundbar . . . . . . . . . . . . 15

Remove the Stylus Pen . . . . . . . . . . . . 16

Remove the stand with base . . . . . . . . . . 16

Remove the heat sink . . . . . . . . . . . . 18

Remove the system board thermal pad . . . . . 19

Remove the Wi-Fi thermal pad . . . . . . . . . 20

Remove the back cover. . . . . . . . . . . . 20

Remove the power lens. . . . . . . . . . . . 21

Remove the power button board . . . . . . . . 22

Remove the shielding bracket with cover . . . . . 23

Remove the camera cable. . . . . . . . . . . 24

Remove the power button cable . . . . . . . . 25

Remove the system board panel cable . . . . . . 26

Remove the P sensor cable . . . . . . . . . . 27

Remove the system board touch cable. . . . . . 28

Remove the Wi-Fi antennas . . . . . . . . . . 29

Remove the system board. . . . . . . . . . . 30

Remove the back bracket . . . . . . . . . . . 31

Remove the VDS cable . . . . . . . . . . . 33

Remove the bezel . . . . . . . . . . . . . . 34

Remove the panel . . . . . . . . . . . . . . 34

Chapter 4. Help and s pport . . . . . 37

Help resources . . . . . . . . . . . . . . . 37

Appendix A. Serial N mber

Location . . . . . . . . . . . . . . . . 39

Appendix B. Notices and

trademarks . . . . . . . . . . . . . . . 41

ii ThinkSmart View Plus Hardware Maintenance Manual

Abo t this man al

• This guide applies to enovo product model(s) listed below. Illustrations in this guide may look slightly

different from your product model.

• This manual contains service and reference information for the following enovo products.

Model name Machine type

ThinkSmart View Plus 12CN, 12CQ, 12CR, 12CS, 12CT, 12CU, 12CV, 12CW

• Use this manual along with the advanced diagnostic tests to troubleshoot problems.

Important: This manual is intended only for trained service technicians who are familiar with these products.

Use this manual along with the advanced diagnostic tests to troubleshoot problems effectively. Before

servicing one of these products, be sure to read and understand the important safety information in Generic

Safety and Compliance Notices.

iv ThinkSmart View Plus Hardware Maintenance Manual

Chapter 1. Prod ct Overview

This chapter provides introductions to the connectors of ThinkSmart View Plus. For detailed technical

specifications, go to Product Specifications Reference at: psref.lenovo.com.

Styl s Pen

Camera

Description Description

1. Camera ED 2. Camera lens

3. Privacy shutter 4. Guide pins

5. USB-C® (3.2 Gen 1) connector 6. Do not Disturb (DND) ED

So ndbar

Description Description

1. Microphone-mute button 2. Speaker-mute button

3. Volume-down button 4. Volume-up button

5. Speaker-mute ED 6. Microphone-mute ED

7. Microphone-status ED 8. Guide tabs

9. Pogo pins

2ThinkSmart View Plus Hardware Maintenance Manual

Monitor and stand

Chapter 1.Product Overview 3

Description Description

1. Touch screen 2. VESA mount plate

3. Pen storage areas 4. Cable hole

5. Power button 6. Power ED

7. Recovery button 8. Phone slot

9. Pen slot

Description Description

1. USB-C (3.2 Gen 1) connector and camera pin holes 2. Security-lock slot

3. USB-C (3.2 Gen 1) connector 4. DisplayPort™ in connector

5. DisplayPort out connector (works only when there is

DisplayPort input from a computer) 6. Ethernet connector

7. USB-A (3.2 Gen 1) connectors 8. Power connector

4ThinkSmart View Plus Hardware Maintenance Manual
