Lenovo ThinkPad L490 Manual de usuario

L490/L590

Setup Guide

Unpack

*Lenovo USB-C to *Lenovo HDMI to VGA *Lenovo USB-C to

VGA Adapter Adapter DisplayPort Adapter

* For selected models

Initial Setup

L490

L590

Overview

L490

HDMI

4 1 2 3 4 4 2 3 4

1213

Overview

L590

4 1 2 3 4 4 2 3 4

HDMI

111213

*1. Infrared camera *14. Smart-card slot

*2. ThinkShutter 15. Ethernet connector

*3. Camera *16. Nano-SIM card slot

4. Microphones 17. microSD card slot

5. Power button 18. HDMI™ connector

6. Security-lock slot 19. Always On USB 3.1 connector

7. USB 3.1 connector Gen 1 Gen 1

8. Audio connector 20.Docking-station connector

9. Numeric keypad

*10. Fingerprint reader

*11. NFC mark

12. Trackpad

13. TrackPoint® buttons

21. USB-C connector (USB 3.1 Gen

22. USB-C™ connector (USB 3.1 Gen

23. TrackPoint pointing stick

*24. Multi-touch screen

*For selected models

Read the statement on USB transfer rate in the User Guide. Refer to the Safety and

Warranty Guide for accessing the User Guide.

Additional information

European Union — compliance with the

adio Equipment Directive

Hereby, Lenovo (Singapore) Pte. Ltd., declares that

the radio equipment type ThinkPad L490/L590 is

in compliance with Directive 2014/53/EU.

The full text of the system EU declaration of

conformity and the EU wireless module

declarations are available at the following Internet

addresses:

•For notebook computers:

https://www.lenovo.com/eu-doc-notebooks

For tablets:

https://www.lenovo.com/eu-doc-tablets

his radio equipment operates with the following

requency bands and maximum radio-frequency

ower:

•

Technology

Frequency

band [MHz]

Maximum

transmit

power

WLAN

802.11b/g/n

2400 - 2483.5 < 20 dBm

WLAN

802.11a/n/ac

5150 - 5725 < 23 dBm

WLAN

802.11a/n/ac

5725 - 5875

< 13.98

dBm

Bluetooth

BR/EDR/LE

2400 - 2483.5 < 20 dBm

WWAN

UMTS

1/8

< 24.5

dBm

WWAN LTE

1/3/7/8/20/28

< 24 dBm

NFC 13.56

< -5.31

dBμA/m

@10m

First Edition (April 2019)

LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a

General Services Administration “GSA” contract, use, reproduction, or disclosure is subject to

restrictions set forth in Contract No. GS-35F-05925.

Reduce I Reuse I Recycle
