Lenovo IdeaPad U530 Touch Manual de usuario

Lenovo IdeaPad

U530 Touch

Read the safety notices and important tips in the

included manuals before using your computer.

User Guide

First Edition (June 2013)

Before using the product, be sure to read Lenovo Safety and General

Information Guide ﬁrst.

The features described in this guide are common to most models.

Some features may not be available on your computer and/or your

computer may include features that are not described in this user

guide.

Some instructions in this guide may assume that you are using

Windows®8. If you are using other Windows operating systems, some

operations may be slightly diﬀerent. If you are using other operating

systems, some operations may not apply to you.

LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant a General

Services Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set

forth in Contract No. GS-35F-05925.

Notes

•

The illustrations in this manual may diﬀer from the actual product.

Please refer to the actual product.

•

The illustrations used in this manual are for Lenovo IdeaPad U530

Touch unless otherwise stated.

•

For details, refer to Guides & Manuals at hp://support.lenovo.com.

Regulatory Notice

•

Chapter 1. Getting to know your computer .......................................... 1

Topview.......................................................................................................................1

Left‐sideview ..............................................................................................................5

Right‐sideview............................................................................................................8

Bottomview ...............................................................................................................11

Chapter 2. Starting to use Windows 8 ................................................ 12

Configuringtheoperatingsystemforthefirsttime ............................................12

Operatingsysteminterfaces ....................................................................................12

Charmsandthecharmsbar.....................................................................................13

Puttingthecomputertosleeporshuttingitdown..............................................15

Touchscreenoperation...........................................................................................17

Connectingtoawirelessnetwork ..........................................................................20

Helpandsupport ......................................................................................................21

Chapter 3. Lenovo OneKey Recovery system ................................... 22

Chapter 4. Troubleshooting .................................................................24

Frequentlyaskedquestions .....................................................................................24

Troubleshooting ........................................................................................................27

Trademarks............................................................................................ 31

Contents

Chapter 1. Getting to know your computer

Top view ---------------------------------------------------------------------------------------------------

Note: Thedashedareasindicatepartsthatarenotvisiblefromoutside.

Attention:

Donotopenthedisplaypanelbeyond130degrees.Whenclosingthedisplaypanel,becareful

nottoleavepensoranyotherobjectsinbetweenthedisplaypanelandthekeyboard.

Otherwise,thedisplaypanelmaybedamaged.



Chapter 1. Getting to know your computer

Integrated

camera

Usethecameraforvideocommunication.

Built-in

microphone

Capturessound,whichcanbeusedforvideo

conferencing,voicenarration,oraudiorecordings.

Multi-touch

display

TheLCDdisplaywithLEDbacklightprovidesbrilliant

visualoutput.Multi‐touchfunctionisavailableonthis

display.

Power button

Pressthisbuttontoturnonthecomputer.

Touchpad

Thetouchpadfunctionsasaconventionalmouse.

TouchpadTomovethecursoronthescreen,slideyour

fingertipoverthepadinthedirectioninwhichyouwant

thecursortomove.

TouchpadbuttonsThefunctionsoftheleft/rightside

correspondtothoseoftheleft/rightmousebuttonona

conventionalmouse.

Notes:

•Youcanenable/disablethetouchpadbypressingF6().

•IfyouchangetheHotKeyModefromEnabledtoDisabledintheBIOSsetuputility,

youneedtopresstheFnkeyincombinationwiththeappropriatehotkey.

Ventilation slots

Dissipateinternalheat.

Attention:

Makesurethatnoneoftheventilationslotsareblockedotherwiseoverheatingofthe

computermayoccur.

Wireless

antennas

Connecttothewirelessadaptertoreceiveandsend

wirelesssignal.



Chapter 1. Getting to know your computer

Hotkeys

Youcanaccesscertainsystemsettingsquicklybypressingtheappropriate

hotkeys.

: Mutes/unmutesthesound. : Enables/disablesAirplane

mode.

: Decreasesthevolumelevel. : Switchestheactiveprogram.

: Increasesthevolumelevel. : TurnstheLCDscreenback‐

lighton/off.

: Closesthecurrentlyactive

window. : Projectstoaconnected

display.

: Refreshesthedesktoporthe

currentlyactivewindow. : Decreasesdisplay

brightness.

: Enables/disablesthe

touchpad. : Increasesdisplaybrightness.

Note: IfyouchangetheHotKeyModefromEnabledtoDisabledintheBIOSsetuputility,

youneedtopresstheFnkeyincombinationwiththeappropriatehotkey.

Chapter 1. Getting to know your computer

Function key combinations

Throughtheuseofthefunctionkeys,youcanchangeoperationalfeatures

instantly.Tousethisfunction,pressandholdFn;thenpressoneofthe

functionkeys.

Thefollowingdescribesthefeaturesofeachfunctionkey.

Fn + Home: Activatethepausefunction.

Fn + End: Activatethebreakfunction.

Fn + PgUp: Enable/disablethescrolllock.

Fn + PgDn: Activatetheinsertfunction.

Fn + Space : Turnthekeyboardbacklighton/off.

Insert PrtSc Delete Home End PgUp PgDn

Pause Break ScrLk SysRq

Chapter 1. Getting to know your computer

Left-side view --------------------------------------------------------------------------------------

Novo button

Whenthecomputerisofforinhibernationmode,press

thisbuttontostarttheLenovoOneKeyRecoverysystem

ortheBIOSsetuputility,ortoenterthebootmenu.

Notes:

•Fordetails,see“Chapter3.LenovoOneKeyRecoverysystem”onpage22.

•IfyourcomputerispreinstalledwithaLinpusoperatingsystem,OnekeyRecovery

systemisnotavailable.

RJ-45 port

ConnectsthecomputertoanEthernetnetwork.

HDMI port

ConnectstodeviceswithHDMIinputsuchasaTVora

display.

USB port

ConnectstoUSBdevices.

Notes:

•TheportsupportsUSB3.0.

•Fordetails,see“ConnectingUSBdevices”onpage6.

Combo audio

jack

Connectstoheadsets.

Notes:

•Atthedefaultsetting,thecomboaudiojackdoesnotsupportconventionalmicrophones.

•Therecordingfunctionmaynotbesupportedifthird‐partyheadphonesorheadsetsare

connected,duetodifferentindustrystandards.

1 2 3 4 5

Chapter 1. Getting to know your computer

Connecting USB devices

ConnectaUSBdevicetoyourcomputerbyinsertingtheUSBplug(TypeA)

intotheUSBportonyourcomputer.

ThefirsttimeyouplugaUSBdeviceintoaparticularUSBportonyour

computer,Windowsautomaticallyinstallsadriverforthatdevice.Afterthe

driverisinstalled,youcanreconnectthedevicewithoutperformingany

additionalsteps.

BeforedisconnectingaUSBstoragedevice,makesureyourcomputerhas

finishedtransferringdatatoorfromthatdevice.ClicktheSafelyRemove

HardwareandEjectMediaiconinthenotificationareaoftheWindows

desktopscreentoremovethedevicebeforedisconnecting.

Note: Typically,Windowsdetectsanewdeviceafterconnectingit,andtheninstallsthe

driverautomatically.However,somedevicesmayrequireyoutoinstallthedriver

beforeconnecting.Checkthedocumentationprovidedbythedevice’smanufacturer

beforeconnectingthedevice.

Notes:

•IfyourUSBdeviceusesapowercord,connectthedevicetoapowersourcebefore

connectingit.Otherwise,thedevicemaynotberecognized.

•ToconnectordisconnectaUSBdeviceinsleepmode,wakeupyourcomputerfirst.
